PARTS REFERENCE LIST
MODEL: DP-525CJ/LW-800ic/LW-800icPLUS
REVISED EDITION

Advertisement

Table of Contents
loading

Related Manuals for Brother DP-525CJ

Summary of Contents for Brother DP-525CJ

  • Page 1 PARTS REFERENCE LIST MODEL: DP-525CJ/LW-800ic/LW-800icPLUS REVISED EDITION...
  • Page 2 NOTES FOR USING THIS PARTS REFERENCE LIST 1. In the case of ordering parts, it needs mentioning the following items: (1) Code (2) Q'ty (3) Description (4) Symbol (PCB No., Revision , and Parts location mounted on the PCB.) Note : No orders without Parts Code or Tool No. can be accepted. [ Example ] REF.

  • Page 3: Table Of Contents

    CONTENTS 1 . PRINT HEAD ASSEMBLY................1 2 . CHASSIS ATTACHMENTS................3 3 . COVERS....................... 7 4 . DETECTOR SWITCH .................. 9 5 . AC ADAPTER..................... 11 6 . MAIN PCB ....................13 7 . POWER SUPPLY PCB ................17 8 .

  • Page 4: Printhead Assembly

    1 . PRINTHEAD ASSEMBLY MODEL DP-525CJ,LW-800ic ,LW-800icPLUS 53T-400-017...
  • Page 5 1 . PRINT HEAD ASSEMBLY REF.NO. CODE Q'TY DESCRIPTION REMARKS US3362001 1 PRINT HEAD ASSY 2, MONO US3363001 1 PRINT HEAD ASSY 2, COLOR MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-017...

  • Page 6: Chassis Attachments

    2 . CHASSIS ATTACHMENTS MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-033...
  • Page 7 2 . CHASSIS ATTACHMENTS MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-033...
  • Page 8 2 . CHASSIS ATTACHMENTS REF.NO. CODE Q'TY DESCRIPTION REMARKS 1-54 US2886001 1 PF UNIT US2887001 1 PF BASE ASSY US2970001 1 PE SENSOR US2971001 1 SENSOR HARNESS US2890001 1 PF STOPPER US2891001 1 STOPPER SPRING US2892001 1 PF MOTOR FRAME ASSY US3198001 1 PF MOTOR 000300515...
  • Page 9 2 . CHASSIS ATTACHMENTS REF.NO. CODE Q'TY DESCRIPTION REMARKS US0468001 1 TAPPING SCREW, PAN S M3X6 US2959000 1 IDLE PULLEY HOLDER US2960000 1 IDLE PULLEY US2961001 1 PULLEY HOLDER SPRING U22702001 1 SCREW, PAN (S/P WASHER) M3X10 US2962000 1 FPC LOCKER US2963001 1 MS HOLDER ASSY US0468001...

  • Page 10: Covers

    3 . COVERS MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-061...
  • Page 11 3 . COVERS REF.NO. CODE Q'TY DESCRIPTION REMARKS US2974020 1 UPPER COVER ASSY, WHITE1250 US2976020 1 LCD UPPER COVER 7 ASSY, W1250 (USA,CAN,AUS) US3180020 1 LCD U COVER 7E ASSY, W1250 (GER,FRA,NLD,AUT) US2977020 1 LCD UPPER COVER 7, WHITE1250 US2978001 1 LCD PANEL 7 (USA,CAN,AUS) US3181001 1 LCD PANEL 7E (GER,FRA,NLD,AUT)

  • Page 12: Detector Switch

    4 . DETECTOR SWITCH MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-100...
  • Page 13 4 . DETECTOR SWITCH REF.NO. CODE Q'TY DESCRIPTION REMARKS U11409001 1 KB SWITCH ASSY 002020305 2 SCREW, PAN M2X3 MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-100...

  • Page 14: Ac Adapter

    5 . AC ADAPTER MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-101...
  • Page 15 5 . AC ADAPTER REF.NO. CODE Q'TY DESCRIPTION REMARKS US3593001 1 AC ADAPTOR ASSY AXIS-120 (SP) US3594001 1 AC ADAPTOR ASSY AXIS-230 (SP) US3595001 1 AC ADAPTOR ASSY AXIS-UK (SP) US3610001 1 AC ADAPTER ASSY AXIS-SAA(SP) US3611001 1 AC ADAPTER ASSY AXIS-MEX(SP) US3681001 1 AC ADAPTER ASSY AXIS-230S(SP) MODEL...

  • Page 16: Main Pcb

    6 . MAIN PCB MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-102...
  • Page 17 6 . MAIN PCB MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-102...
  • Page 18 6 . MAIN PCB TW99011 REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS 1-74 B48J300-201A US3588001 1 PCB B48J300 ASSY 7 (SP) USA.ENG CHNG#A 1-74 B48J300-202A US3588002 1 PCB B48J300 ASSY 7 (SP) AUS.ENG CHNG#A 1-74 B48J300-204 US3588004 1 PCB B48J300 ASSY 7 (SP) CAN.ENG CHNG#A 1-74 B48J300-211A...
  • Page 19 6 . MAIN PCB REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS C12,16,17,19,26, Y81042407 21 CAPACITOR, CERAMIC 25C104F 28,29,32-36,39,46- 52,58 Y81030017 1 CAPACITOR, CERAMIC 50C103CH C20,22-25 Y81020017 5 CAPACITOR, CERAMIC 50C102B C13,15,18 Y74712117 3 CAPACITOR, CERAMIC 50C471CH C37,38,53,54 Y73002117 4 CAPACITOR, CERAMIC 50C300CH C44,45 Y71004117 2 CAPACITOR, CERAMIC 50C100CH...

  • Page 20: Power Supply Pcb

    7 . POWER SUPPLY PCB MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-104...
  • Page 21 7 . POWER SUPPLY PCB REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS B48J295-3 US3596001 1 SWITCH PCB ASSY AXIS (SP) US0782000 1 DIODE, 1N5400 Y42223092 1 CAPACITOR, ALUM-ELEC 25B222 U17200000 1 POWER SWITCH:WK-837 W00325001 1 JACK:HEC0470 US3413000 1 GLASS FUSE, 4A-235 US0589000 2 FUSE CLIP:HTC-200M US3108001...

  • Page 22: Lcd

    8 . LCD MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-108...
  • Page 23 8 . LCD REF.NO. CODE Q'TY DESCRIPTION REMARKS US3597001 1 LCD:480X64 UG48B085NBR4-A (SP) US3114001 1 LCD HARNESS ASSY AXIS1 UL8212000 1 FERRITE CORE:19X10X10 MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-108...

  • Page 24: Floppy Disk Drive

    9 . FLOPPY DISK DRIVE MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-302...
  • Page 25 9 . FLOPPY DISK DRIVE TW2000008 REF.NO. CODE Q'TY DESCRIPTION REMARKS LC0132020 1 FDD STD ASSY (SP) US4792020 1 FDD BODY MI2HD M3STD UC9813020 1 FRONT BEZEL MIM3 UC9814020 1 EJECT BUTTON MIM3 US3024000 1 PLATE AL US3025000 1 PLATE AR 000300515 3 SCREW, BIND M3X5 US3026000...
  • Page 26 10 . ACCESSORIES MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-910...

  • Page 27: Accessary

    10 . ACCESSORY REF.NO. CODE Q'TY DESCRIPTION REMARKS US3056020 1 CARTRIDGE CASE ASSY, WHITE1250 MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-910...

  • Page 28: Printed Matters

    11 . PRINTED MATTERS TW2000010 MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-920...
  • Page 29 11 . PRINTED MATTERS TW2000010 REF.NO. CODE Q'TY DESCRIPTION REMARKS US3059001 USER'S MANUAL, US US3217001 USER'S MANUAL, UK US3219001 USER'S MANUAL, GERMAN US3403001 USER'S MANUAL, FRENCH US3710001 USER'S MANUAL, DUTCH US3226001 USER'S MANUAL, BILINGUAL-F2 US3404001 USER'S MANUAL, BILINGUAL-E US1700001 ACCESSORY ORDER FORM 595110080 WARRANTY CARD, ENGLISH UC9800001...

  • Page 30: Packing Materials

    12 . PACKING MATERIALS MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-930...
  • Page 31 12 . PACKING MATERIALS TW99007 REF.NO. CODE Q'TY DESCRIPTION REMARKS US3070021 1 CARTON, NOBRO US3071022 1 CARTON 525CJ ASSY, USA US3234054 1 CARTON, LW-800IC LC0019054 1 CARTON, LW-800icPLUS US3712054 1 CARTON ASSY, DP-525CJ (AUS) UC9795054 1 CARTON ASSY, 525CJ CANADA US3081000 1 STYROFOAM PAD L US3082000...
  • Page 32 13 . KEYBOARD UNIT REF.NO. CODE Q'TY DESCRIPTION REMARKS 13-1 US3019020 1 KB ASSY 02 13-2 US3149020 1 KB ASSY 08 13-3 US3147020 1 KB ASSY 14 13-4 US3519020 1 KB ASSY 16 13-5 US3151020 1 KB ASSY 20 13-6 US3711020 1 KB ASSY 32 MODEL...

  • Page 33: Keyboard Unit/Usa

    13-1 . KEYBOARD UNIT/USA MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-402...

  • Page 34: Keyboard Unit/German

    13-2 . KEYBOARD UNIT/GERMAN MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-408...

  • Page 35: Keyboard Unit/Uk

    13-3 . KEYBOARD UNIT/UK MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-414...

  • Page 36: Keyboard Unit/Canada

    13-4 . KEYBOARD UNIT/CANADA MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-416...

  • Page 37: Keyboard Unit/French

    13-5 . KEYBOARD UNIT/FRENCH MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-420...

  • Page 38: Keyboard Unit/Holland

    13-6 . KEYBOARD UNIT/HOLLAND MODEL DP-525CJ,LW800ic,LW-800icPLUS 53T-400-432...
  • Page 39 Aug, `98 53T005BE1 Printed in Japan...
