- Page 1 ProSeries .5 Component Speaker Systems Installation Manual...
-
Page 2: Table Of Contents
This manual explains only the assembly and placement of the various components, not the techniques required to perform the installation. If you do not have the experience these procedures require, we strongly recommend you consult your Boston Acoustics dealer about professional installation. -
Page 3: System Contents
System Contents Here’s what comes with this system (two each): System 6.5 System 5.5 System 4.5 System 6.5LF woofer 5.5LF woofer 4.5MR midrange Neo 5t tweeter Flush- mount kit Angle- mount kit Surface- mount kit Axis- mount kit crossover 6.5x crossover 5.5x crossover... -
Page 4: System Placement
System Placement Best imaging is obtained when the tweeter and the woofer or midrange are placed out to the sides and far forward. Woofer in door, tweeter in door Woofer in kick panel, tweeter in kick panel... - Page 5 Woofer in door, tweeter in dashboard Woofer in door, midrange in kick panel, tweeter in kick panel...
-
Page 6: Tweeter Installation
Tweeter Installation There are several different installation kits for the Neo 5t tweeter. Surface-mount kit Flush-mount kit Angle-mount kit Angle-mount installation... - Page 7 Flush-mount installation Surface-mount installation...
- Page 8 Tweeter Installation—Axis Mount (6.5 & 5.5 systems only) Axis-mount kit Axis-mount installation Axis-mount crossover setting...
-
Page 9: Woofer Installation
Woofer Installation Mount the woofer rigidly to a surface that provides a complete air seal from front to rear. 6.5LF installation 6.5LF 165mm 160mm... - Page 10 6.5LF installation with spacer 6.5LF 5.5LF installation Spacer 5.5LF...
- Page 11 4.5MR installation 4.5MR 4.5MR...
-
Page 12: Crossover Installation
Crossover Installation Crossover lid removal Crossover installation... -
Page 13: System Wiring
System Wiring (6.5, 5.5, 4.5 systems) tweeter level -4db -2db normal axis-mount amplifier " Strip -inch (6mm) from one end of each wire. Connect the marked side of each wire to positive (+) terminals. 6.5LF woofer/midrange tweeter Two-way wiring diagram 6.5/5.5/4.5 systems... - Page 14 System Wiring—Axis Mount (6.5 & 5.5 systems only) tweeter level -4db -2db normal axis-mount amplifier " Strip -inch (6mm) from one end of each wire. 6.5LF woofer axis-mount Two-way wiring diagram 6.5/5.5 systems (axis-mount)
- Page 15 System Wiring—6.5 system Three-way bi-amp wiring diagram input system bi-amp normal amplifier amplifier " input bi-amp normal amplifier " tweeter level -4db Strip -inch (6mm) from -2db crossover one end of each wire. Connect the marked side of each wire to positive (+) terminals.
-
Page 16: Specifications
4Ω Sensitivity (1watt/1 meter) 90dB 90dB 90dB 87dB Specifications subject to change without notice. 300 Jubilee Drive Peabody, MA 01960 978-538-5000 Boston and Boston Acoustics are registered trademarks of Boston Acoustics, Inc. ©1998 Covered by patents issued and/or pending. 42-789-0...
