Fitting the 78 r.p.m. pulley

Before beginning work fit the cartridge's needle protection cover.

Remove the platter and drive belt. Please remember that sweat or sticky fingers will impair the function of the

belt. Use a piece of kitchen paper or a cloth to remove the belt.

Measure the height of the pulley above the plinth in order to ease correct refitting.

Using a small screwdriver loosen the grub screw in the neck of the pulley just enough to remove the pulley

vertically without using force. Refit the pulley in the opposite order. Tighten the grub screw carefully making

sure you do not overtighten it.

Fit the drive belt around the subplatter and the pulley. Again, use a piece of paper or cloth to avoid soiling

the belt. Replace the platter.

** 78 r.p.m. is not available with the Essential, Debut III E, Xperience Basic +, 2 Xperience Comfort,

2 Xperience Acryl, 2 Xperience Classic, 2 Xperience SuperPack, 6 PerspeX, 6

RPM 1.3 Genie,RPM 9.1, RPM 9.1 SuperPack, RPM 9.1 Acryl, RPM 9.2 Evolution and

RPM 10.1 Evolution.

The models Debut III/Phono SB, 1 Xpression III Comfort, RPM 5 SuperPack, RPM 5.1 SuperPack,

RPM 6.1 SB, RPM 6.1 SB SuperPack and Xtension are equipped with the 78 r.p.m. pulley as a

standard.

Technical specifications Pro-Ject Speed Box II

Nominal speeds:

Quartz oscillator:

*** Length power cable:

Turntable connection:

Outboard power supply:

Dimensions W x H x D (D with sockets): 103 x 36 x 103 (103)mm

Weight:

Service

Should you encounter a problem which you are not able to alleviate or identify, please contact your dealer for

further advice. Only when the problem cannot be resolved there should the unit be sent to the responsible

distributor in your country.

Warranty

The manufacturer accepts no responsibility for damage caused by not adhering to these instructions

for use. Modification or change to any part of the product by unauthorized persons release the

manufacturer from any liability over and above the lawful rights of the customer.

PRO-JECT is a Registered Trademark of H. Lichtenegger.

This guide was produced by: Audio Trade GmbH

* 33 and 45 r.p.m. ** Optional 78 r.p.m.

Speed stability +/- 0,001%

approximately 40cm

16V/AC 190mA max. (3W power consumption max.)

16V/500mA AC, suitable for your country's mains supply

540g without power supply

The information was correct at the time of going to

press. The manufacturer reserves the right to make

changes to the technical specification without prior

notice as deemed necessary to uphold the ongoing

process of technical development.
