Summary of Contents for Panasonic Viera TH-L24X5A
-
Page 2: Table Of Contents
Contents SAFETY PRECAUTIONS ....................3 Warning ........................................3 Caution ..........................4 Maintenance ........................4 Display panel, Cabinet, Pedestal ..............................4 Mains plug ......................................4 IMPORTANT INFORMATION .................... 4 Standard Accessories ...................... 5 Attaching the Stand Base ....................5 Installing Stand Base ................................... 6 Uninstalling Stand Base .................................. -
Page 3: Safety Precautions
TV unstable, risking injury. Be sure to ask your local − Do not move the TV with the lead plugged in to a socket Panasonic dealer to perform the set up or installation. outlet. •... -
Page 4: Caution
Caution Maintenance When cleaning the TV remove the mains First, remove the mains plug from the socket plug outlet. • C leaning an energised TV may cause electrical shock. Display panel, Cabinet, Pedestal Remove the mains plug from the wall socket when TV is not in use for a prolonged period Regular care : of time... -
Page 5: Standard Accessories
Do not use the pedestal if it becomes warped or physically damaged. • I f you use the pedestal while it is physically damaged, personal injury may result. Contact your nearest Panasonic dealer immediately. During assembly, use only screws supplied and make sure ... -
Page 6: Installing Stand Base
M4 Diameter, Length - 10 cm 6mm (min.); 7mm (max.) Wall-hanging bracket (Optional) Please contact your nearest Panasonic dealer to purchase the recommended optional accessories. For additional details, please refer to the manual of the optional accessories. •... -
Page 7: Part Names And Functions
PART NAMES AND FUNCTIONS TV Controls/ Indicators Remote Control Signal Receiver • D o not place any objects between the TV remote control signal receiver and remote control. Power Indicator Red: Standby Green: On Green blink: Receiving a command from the remote control VOL +/- •... -
Page 8: Connections
Connections Computer Connection Cable used for connection (This cable is not supplied with this LCD Note: TV.) When connecting the cable, AC Power Cords of both • P C/VGA Cable (D-SUB 15pin) LCD TV and external equipment should be disconnected •... -
Page 9: Ac Power Cord Connection
AC Power Cord Connection Remote Control Batteries Installation This LCD TV uses nominal input voltages of 220-240V AC. 1. Remove the battery compartment cover. It is designed to work with single-phase power systems. To reduce risk of electrical shock, do not plug into any other type of power system. -
Page 10: Remote Control
Remote Control • S elect a sound multiplex mode. 10 MENU • O pen or close the On-Screen Menu. 11 R/G/Y/B (COLOUR BUTTON) • U sed for the selection, navigation and operation of various functions. 12 F.P. (Favourite Page) • O pens the favourite page list in teletext mode. -
Page 11: Turning On/Off Lcd Tv
Turning On/Off LCD TV Initial Setup 1. Complete the peripheral connections before turning on Initial Setup LCD TV. 2. Connect LCD TV’s AC Power Cord into an AC outlet. Initial Setup 3. Press POWER button on Side Control of LCD TV or use Remote Control to turn it ON. -
Page 12: Using The Freeview Guide (Digital Tv Mode)
Using the Freeview Guide (Digital TV mode) Search for channels Initial Setup Channel Scan Using the Freeview Guide enables you to select a programme easily, view programme information, etc. The channel scan may take a while to complete. The Freeview Guide - Electronic Programme Guide (EPG) Status: Scanning... -
Page 13: On-Screen Display
On-Screen Display Brightness • I ncreases or decreases the levels of brightness according to Picture your personal preference. (0~100) Colour Main Menu • I ncreases or decreases the levels of colour according to your Viewing Mode Normal personal preference. (0~100) Back Light Contrast Sharpness... -
Page 14: Sound
Adaptive Brightness Balance • A utomatically adjusts the brightness and contrast after • analysing the input signal. This function enriches the A djusts volume level of right and left speakers. (-50~50) colours and the depth of the picture. Headphone Volume Dynamic Back Light •... -
Page 15: Timer
Timer Setup Main Menu Main Menu Off Timer Channels Auto Standby Language Display Settings HDMI Control System Menu Child Lock Other Setting Select Select Access Access EXIT EXIT RETURN RETURN 1. Press MENU button and 1. Press MENU button and buttons to select “Timer”, the buttons to select “Setup”, the Timer menu will be displayed. -
Page 16: Fine Tuning
Channel Skip Software License • • S kips one or more channels when using remote control to D isplays the software license information of this TV. switch between channels. Child Lock Channel Sort • • R eorders the channels in the programme list. L ocks a channel/AV input to prevent access to it. -
Page 17: Multi-Media
Multi-Media Option List • I n multi- media menu, you can press Blue colour key to Media Player select one of following options. Viewing photos • T ransition Effect • P hoto Size • I nterval • Contents Select R epeat Playing music Select •... -
Page 18: Troubleshooting
• A dedicated remote control is required for this model. Basically, the remote control of other brands (including Panasonic other models) cannot be used. • No image C heck the connection between the external equipment and LCD TV. -
Page 19: Specifications
SPECIFICATIONS TH-L24X5A TH-L24X5Z Power Source AC 220-240 V, 50Hz Rated Power 0.4 A 0.4 A Consumption Standby Power 0.5 W 0.5 W Consumption With Pedestal: With Pedestal: 567 mm × 406 mm × 170 mm 567 mm × 406 mm × 170 mm Dimensions (W ×... -
Page 20: Input Signal Compatibility Chart
Input Signal Compatibility Chart COMPONENT (Y, PB, PR), HDMI Signal name COMPONENT HDMI 525 (480) / 60i, 60p 625 (576) / 50i, 50p 750 (720) / 60p, 50p 1,125 (1,080) / 60i, 50i 1,125 (1,080) / 60p, 50p, 24p Mark : Applicable input signal PC (from D-sub terminal/ HDMI terminal) Signal name Horizontal frequency (kHz) -
Page 21: Multi-Media Supported Specification
Multi-media Supported Specification Photo Image resolution Format File extension Details / Restrictions (pixel) Baseline jpeg: DCF * and EXIF * 4x4 to 17000 x 10000 standards JPEG .jpeg Progressive jpeg: Sub-sampling : 4:4:4, 4:2:2, 4:2:0 4x4 to 4000 x 4000 * 1 : Design rule for Camera File system - unified standard established by Japan Electronics and Information Technology Industries Association (JEITA) * 2 : Exchangeable Image File - image file format used by digital cameras... -
Page 22: License
LICENSE This product incorporates the following software or technology: (1) the software based in part on the work of the Independent JPEG Group, (2) the software developed by the Free Type Project. Dolby • M anufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. - Page 23 If there is a major failure in regard to the product which cannot be remedied then you must notify us within a reasonable period by contacting the Panasonic Customer Care Centre. If the failure in the product is not a major failure then Panasonic may choose to repair or replace the product and will do so in a reasonable period of time from receiving notice from you.
- Page 24 WARRANTY - New Zealand only NEW ZEALAND Distributed in New Zealand by Panasonic New Zealand Limited 350 Te Irirangi Drive East Tamaki, Private Bag 14911, Panmure Auckland Tel. 09 272 0100 Customer Care Center Email: Customerservice@nz.panasonic.com www.panasonic.co.nz Warranty Customer’s Record The model number and serial number of this product may be found on its rear panel.
