Bogen Model FMR
The
background music in paging systems and for music-on-hold applications.
It operates from a 12V DC or 24V DC power source and has a line-level
output for connection to a paging amplifier or paging control device. A separate
1-watt output is provided to drive an external amplifier speaker.
A tuning dial selects the desired frequency. A built-in speaker facilitates
tuning and AFC circuitry prevents signal drift. A screwdriver-adjustable tone
control and separate volume controls are provided for the outputs. Switches
select power ON/OFF, internal or external antenna (telescoping antenna or
external 300-ohm), AFC ON/OFF, and internal or external speaker (1-watt
output). Screw terminals are included for connection of external antenna,
24V DC power supply, and outputs. A jack is provided to connect a receptacle-
mount 12V DC power supply (not included - PRS40C recommended).

SPECIFICATIONS

Tuning Range: ............................87.5 MHz to 108.5 MHz
FM Sensitivity: ............................8mV
Frequency Response: ................90 Hz to 16 kHz, +2dB
Power Output: ............................1-watt @ 8-ohms; 100 mW (Line Out)
Signal-to-Noise Ratio: ................-65dB
Distortion: ..................................Less than 2% at rated power output
Power Requirements: ................12V DC or 24V DC; 250 mA
Dimensions: ................................3-3/8" W x 6" H x 1-1/2" D
Product Weight: ........................1 lb.
FMR
FM Radio Receiver
is a wall-mounting FM radio designed to furnish
© 2011 Bogen Communications, Inc. All rights reserved.
Specifications subject to change without notice.
54-5893-01B 1109
