Black Widow Security BW FM 5 User Manual

1-
Arm/
2 - Remote Start/Off
Disarm
Transmitter Indications
2 &3 - Clock Set
2 &3
- Alarm Clock Set
2 &3
- Remote Start
2 &3 Timer Set
3 - Trunk Aux.
4 - Aux. 2
5 - Confirm Status
5
- Illuminate
5 - Display
Arm -
The display will show
and the animated icon to
confirm arming. Lights will
flash once.
Disarm -
The display will show
the animated to confirm
disarming. Lights will flash twice.
Trunk -
The display will show
flash this icon opening to
confirm.
Warn Away -
If the warning stage is triggered,
the icon will flash.
FM 2-WAY TRANSMITTER

Transmitter Operation

- ARM/DISARM/PANIC Button
1
the system, press button 1. To activate the panic feature, press
button 1 and hold for three seconds.
2 - START Button
2 for two seconds.To shut down the vehicle, press and hold button
2 for two seconds.
3 - TRUNK Button
button 3 for two seconds.
AUXILIARY 2 Output
4 -
press and hold button 4 for two seconds.
5 - CONFIRMATION Button
the system, press button 5. The current status of the system will
be displayed & illuminated on the transmitter.
icon
and
and
- To arm or disarm
- To start the vehicle, press and hold button
- To activate the trunk output, press and
- To activate the Aux. 2 output,
- To check current status of
Shock Sensor -
The display will show Shock and
flash the animated
indicate shock sensor triggering.
Door -
If a door is opened while the
system is armed, the display will
show .
Hood -
If the hood or trunk is opened while
the system is armed, the
will show and the lights will flash.
Panic -
The display will show
when the Arm/Disarm button is
held to enter the Panic mode.
icon to
icon
