- Page 1 156998841.qxp 12/13/2006 3:33 PM Page 1 User manual Dishwasher 52C850...
-
Page 2: Table Of Contents
156998841.qxp 12/13/2006 3:33 PM Page 2 Content Safety information - - - - - - - - - - - - - - - - - - -3 Control panel and functions - - - - - - - - - - - -5 Programme table - - - - - - - - - - - - - - - - - - -6 Before the first use - - - - - - - - - - - - - - - - - -7 Filling with rinse aid - - - - - - - - - - - - - - - - - -7... -
Page 3: Safety Information
156998841.qxp 12/13/2006 3:33 PM Page 3 Safety information In the interest of your safety and to ensure correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to ensure that all people using the appliance are thoroughly familiar with its operation and safety features. - Page 4 156998841.qxp 12/13/2006 3:33 PM Page 4 Installation Check your dishwasher for any transport ● damage. Never connect a damaged machine. If your dishwasher is damaged contact your supplier. All packaging must be removed before use. ● Any electrical and plumbing work required to ●...
-
Page 5: Control Panel And Functions
156998841.qxp 12/13/2006 3:34 PM Page 5 Control panel and functions Finished light Program selector dial and Start/Cancel button On/Off switch when in this position, the machine is switched off (corresponding light off), ● Program selector dial when the marker on the dial corresponds with a program, the machine ●... -
Page 6: Program Table
156998841.qxp 12/13/2006 3:34 PM Page 6 Program table Program Cycle description Pots Heavy soil. Prewash - Main wash Crockery, cutlery, 2 intermediate rinses - pots and pans Final rinse - Dry Regular Plus Normal soil. Prewash - Main wash Crockery and cutlery 2 intermediate rinses - Use this program for maximum performance Final rinse - Dry... -
Page 7: Before The First Use
156998841.qxp 12/13/2006 3:34 PM Page 7 Before the first use When using separately rinse aid and detergent: - fill up the rinse aid dispenser with rinse aid - fill up the detergent dispenser with detergent When using tablets that integrate rinse aid and detergent: - there is no need to fill up with rinse aid: place the tablets in the detergent dispenser. -
Page 8: Adjusting The Dosage Of Rinse Aid
156998841.qxp 12/13/2006 3:34 PM Page 8 Adjusting the dosage of rinse aid Increase the dose if there are drops of water or Reduce the dose if there are whitish streaks lime spots on the dishes after washing. on the dishes or a bluish film on glassware or knife blades. - Page 9 156998841.qxp 12/13/2006 3:34 PM Page 9 Load cutlery. Place knives and other Load the lower basket. For best results we items of cutlery with Arrange serving dishes and large lids around the recommend you to use sharp points or edges edge of the basket.
-
Page 10: Adjusting The Height Of The Upper Basket
156998841.qxp 12/13/2006 3:34 PM Page 10 Adjusting the height of the upper basket If washing very large Maximum height of the dishes in: plates you can load them upper basket lower basket in the lower basket after With upper basket raised 20 cm 31 cm moving the upper basket... -
Page 11: Filling With Detergent
156998841.qxp 12/13/2006 3:34 PM Page 11 Filling with detergent IMPORTANT! Only use detergents suitable for dishwashers. Observe the manufacturer’s dosing and storage recommendations. Open the lid. Observe the dosing Fill in the detergent in levels. compartment A. For programmes with When using detergent Close the lid. -
Page 12: Cleaning And Care
156998841.qxp 12/13/2006 3:34 PM Page 12 Cleaning and Care Cleaning the filters IMPORTANT! NEVER use the dishwasher without filters as this may result in damage to the appliance. Incorrect repositioning and fitting of the filters will produce poor washing results. The dishwasher must Clean filters A, B and C Turn the handle about... -
Page 13: Environmental Concerns
156998841.qxp 12/13/2006 3:34 PM Page 13 External cleaning Frost precautions Clean the external surfaces of the machine and Avoid placing the machine in a location where control panel with a damp soft cloth. If the temperature is below 0°C. If this is necessary use only neutral detergents. -
Page 14: Something Not Working
156998841.qxp 12/13/2006 3:34 PM Page 14 Something not working IMPORTANT! The dishwasher will not start or stops during operation. Certain problems are due to the lack of simple maintenance or oversights, which can be solved with the help of the indications described in the chart, without calling out a service technician. Switch off the dishwasher, open the door and carry out the following suggested corrective actions. - Page 15 156998841.qxp 12/13/2006 3:34 PM Page 15 The wash results are not satisfactory The wrong washing program has been selected. ● The dishes are not clean The dishes were arranged in such a way as to stop water reaching all parts ●...
-
Page 16: Technical Data
156998841.qxp 12/13/2006 3:34 PM Page 16 Technical data Dimensions Width 60 cm Height 85 cm Depth (including control panel) 61 cm Electrical connection Information on the electrical connection is given on the rating plate on Voltage - Overall power - Fuse the inner edge of the dishwasher’s door. -
Page 17: Hints For Test Institutes
156998841.qxp 12/13/2006 3:34 PM Page 17 Hints for test institutes Testing in accordance with AS/NZS 2007 must be carried out with the appliance fully loaded and using the test programme (see "Consumption values"). The rinse aid dispenser must be filled and the door must be opened at the end of cycle for 30 minutes for drying assessment. -
Page 18: Installation
156998841.qxp 12/13/2006 3:34 PM Page 18 Installation WARNING! Any electrical and/or plumbing work required to install this appliance should be carried out by a qualified electrician and/or plumber or competent person. Water connection WARNING! WARNING! This dishwasher may be fed with either hot Always use a new hose-set when connecting (max. -
Page 19: Electrical Connection
156998841.qxp 12/13/2006 3:34 PM Page 19 Remove internal membrane from drain spigot. Ensure that the hoses When connecting the drain hose to an under sink are not kinked, crushed trap spigot, the entire plastic membrane must be or entangled. removed. Failure to remove all the membrane will result in food particles building up over time eventually blocking the dishwasher drain hose spigot. -
Page 20: Fitting Under A Counter
156998841.qxp 12/13/2006 3:34 PM Page 20 Fitting under a counter By removing the dishwasher’s worktop, you Be sure that once the appliance has been can install it under a close fitting sink unit or a installed, it is easily accessible for the service pre-existing top. -
Page 21: Warranty
156998841.qxp 12/13/2006 3:34 PM Page 21 Warranty 5. Parts and Appliances not supplied by Electrolux are not FOR SALES IN AUSTRALIA AND NEW ZEALAND covered by this warranty. APPLIANCE: Dishwasher This document sets out the terms and conditions of 6. Where you are within an Electrolux service area, this product warranties for Electrolux branded appliances. - Page 22 156998841.qxp 12/13/2006 3:34 PM Page 22 Limitation of Liability (a) in the case of Appliances, at its option, to the replacement or repair of the Appliances or the 10. To the extent permitted by law: supply of equivalent products or the (a) Electrolux excludes all warranties other than as payment of the cost of replacing the Appliances or contained in this document;...
- Page 23 156998841.qxp 12/13/2006 3:34 PM Page 23...
- Page 24 156998841.qxp 12/13/2006 3:34 PM Page 24 www.electrolux.com www.simpson.com.au Subject to change without notice 156 998 841 13/12...
