Universal WiFi Internet Adapter (WNCE2001)

Package Contents

Power
adapter
WNCE2001
Ethernet cable
Top and Back Views
Reset WPS
Power
WLAN
button
LED button
LAN
LED
LED
What is WPS?
If you have a NETGEAR router, this feature is called Push 'N' Connect. Look for the
the NETGEAR router supports WPS. For non-NETGEAR routers, please refer to the user manual to determine if the router supports WPS.
Once you know whether your router supports WPS, choose the appropriate installation method below.
Installation with WPS
Step 1:
Step 2:
USB power
cable
Step 3:
Step 4:
Power
Ethernet
Port
WPS (WiFi Protected Setup) is a simple and secured way to connect a device to an existing network.
Connect the WNCE2001
to your TV, XBox, or Blu-ray
player using the Ethernet
cable (included) and one
of the power connection
options. For more information
on power-up methods,
see "Power Connection
Options" on the reverse side.
Wait until the Power LED on
the WNCE2001 is solid
green. Push the WPS button on
the WNCE2001. The WLAN
LED will blink amber and
green, showing that the WPS is
running.
Push the WPS button on your router. The WLAN LED
on the WNCE2001 will stay green for
5 seconds when the wireless connection has been
established.
Congratulations! Your installation is complete.
NOTE: Make sure you go through the connection settings on your TV, XBox, or Blu-ray player after the
WNCE2001 is configured and connected. If asked for the type of connection, make sure WIRED is selected.
or symbols on the router to make sure
Installation without WPS
Step 1:
Please disconnect any wireless connection to the router and/or
remove the Ethernet cable currently connected to the computer.
You may restore the connection after the WNCE2001 installation
is complete.
Step 2 : Connect the WNCE2001 to your computer, using the Ethernet
cable (included) and one of the power connection options.
For more information on power-up methods, see "Power
Connection Options" on the reverse side.
Step 3: Wait until both the Power and LAN LEDs are solid green.
Make sure the computer gets the IP address. Then, open
your Internet browser and it will automatically take you
to the setup page. Follow the instructions on the setup page,
then return to this guide and continue to Step 4.
Step 4:
Disconnect the Ethernet and USB cables from your computer.
Step 5:
Connect the WNCE2001 to your TV, Box, or Blu-ray player.
If your device doesn't have a USB port, see "Power
Connection Options" on the reverse side.
WPS
button
Step 6:
Congratulations! Your installation is complete.
