Gigabyte GC-WB300D User Manual

Gigabyte GC-WB300D User Manual

Wi-fi/bluetooth card
Hide thumbs

Advertisement

Quick Links

Download this manual
GC-WB300D
GC-WB150
User's Manual
12WE6-WIFIBT-30AR

Advertisement

loading
Need help?

Need help?

Do you have a question about the GC-WB300D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gigabyte GC-WB300D

Summary of Contents for Gigabyte GC-WB300D

  • Page 1 GC-WB300D GC-WB150 User’s Manual 12WE6-WIFIBT-30AR...

  • Page 2: Usb Cable

    Chapter 1 Installing the Wi-Fi/Bluetooth Card Wi-Fi/Bluetooth Card USB Connector Antenna Connector Antenna Antenna Connector USB Cable Step 1: Install the Wi-Fi/Bluetooth card in a PCI Express x1 slot. Connect one end of the USB cable to the USB connector on the Wi-Fi/ Bluetooth card.
  • Page 3 Step 3: Tighten the two antenna cables to the antenna connectors on the Wi-Fi/Bluetooth card respectively. Step 4: Then move the antennas to a place where the signal is good. - 3 -...

  • Page 4: Installing The Drivers And Utilities

    Chapter 2 Installing the Drivers and Utilities Installing the Drivers and Utilities After installing the Wi-Fi/Bluetooth card, install the drivers and utilities in the operating system. Insert the included driver disk and when the autorun screen appears, install all of the items that are listed. Follow the on-screen instructions to install the drivers and utilities in sequence.
  • Page 5 Mode Selection Wi-Fi Share provides three modes for users to select as follows: A. Virtual Router Mode The Virtual Router Mode turns your computer into a virtual wireless access point (WAP). Refer to the steps below for detailed configurations. Configuring your computer: Step 1: Right-click the Wi-Fi Share icon in the notification...
  • Page 6 Step 2: When the Connect to a Network dialog box appears, enter the security key of the network connection the virtual wireless AP is sharing and click OK. Step 3: After the connection, the Currently connected to list shows that this computer is currently using the network connection shared by the virtual wireless B.
  • Page 7 Step 2: The Wi-Fi Share Manager will display the other computer with Wi-Fi Share Mode enabled (the target computer). Step 3: Go the directory where the file/folder that you want to share is located. Drag the file/folder to the target computer displayed on the Wi-Fi Share Manager.
  • Page 8 Step 5: The confirmation message will also appear on the target computer, asking whether to accept the file/folder from the source computer. Click Yes to confirm. You must respond in 15 seconds. The RX light will be on when the file/data is being received. Step 6: The data will be automatically stored to a folder in the My Documents\AirFileDownloads directory in...

  • Page 9: System Requirements

    Using the Cloud Station Utility The Cloud Station utility allows GIGABYTE’s iOS APPs to communicate, share resources, and control your desktop PC systems. Two GIGABYTE’s unique iOS APPs are available now: EasyTune Touch and PictureView, both of which can be downloaded from the Apple store for free.
  • Page 10 Using the Cloud Station: After the Cloud Station utility is installed, the Cloud Station icon will appear in the notification area. You can right-click this icon and select Always run on next reboot to launch this utility each time you reboot the computer.
  • Page 11 Using EasyTune Touch Step 1: Go to the main menu of the EasyTune Touch application on your iPhone. Select Connection. Step 2: On the Connection page, select Wifi. iPhone will begin to search for the computer using the same network connection. When the computer is displayed, select it.
  • Page 12 Step 3: Click the photo you want to share and your photo will be shown instantly on the desktop of the target computer. B. BlueTooth Connection: Step 1: On your iPhone, go to Settings > Personal Hotspot and turn on this function. Then go to Settings > General >...
  • Page 13 Step 3: A pairing code will appear on the screen. Click Next. You iPhone will display a message with the pairing code for you to confirm as well (refer to the next screenshot). Step 4: When the iPhone displays the pairing code, press Pair to confirm.
  • Page 14 C. USB Connection: Step 1: On your iPhone, go to Settings > Personal Hotspot to turn on this function. Step 2: Connect your iPhone to your computer using the iPhone USB cable. Step 3: After the iPhone is connected to your computer, go to Control Panel >...

This manual is also suitable for:

Gc-wb150
