EURORACK UB1622FX-PRO Technical Specifications
UB1622 -PRO
Ultra-Low Noise Design 16-Input 2/2-Bus Mic/Line Mixer with
Premium Mic Preamplifiers and Multi-FX Processor
Ultra low-noise ULN design, highest possible headroom, ultra-transparent audio
4 new state-of-the-art, studio-grade IMP "Invisible" Mic Preamps with 130 dB dynamic range for 24-bit, 192 kHz sampling rate inputs
Studio-grade 24-bit stereo FX processor with 100 awesome presets including reverb, chorus, flanger, delay, pitch shifter and various multi-effects
Effective, extremely musical 3-band EQ with semi-parametric mid band plus switchable low-cut filter on all mono channels
Inserts on each mono channel for flexible connection of outboard equipment
12 balanced high-headroom line inputs with +4/-10 level selection on stereo channels
2 aux sends per channel: 1 pre/post fader switchable for monitoring/FX applications, 1 post fader (for internal FX or as external send)
Clip LEDs, mute, main mix and subgroup routing switches plus solo and PFL functions on all channels
2 subgroups with separate outputs for added routing flexibility
2 multi-functional stereo aux returns with flexible routing
Main mix outputs with jack and gold-plated XLR connectors, separate control room, headphone and 2-track outputs
Control room/headphone outputs with multi-input source matrix
2-track inputs assignable to main mix or control room/headphone outputs
Switchable +48 V phantom power for condenser microphones
Rack mount brackets included
Internal switch-mode power supply for maximum flexibility (100 – 240 V~), noise-free audio, superior transient response plus lowest possible
power consumption for energy saving
High-quality component components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany

Specifications

Microphone Inputs (IMP Invisible Mic Preamp)
Type
Mic E.I.N. (20 Hz - 20 kHz)
@ 0 Ω source resistance
@ 50 Ω source resistance
@ 150 Ω source resistance
Frequency response
Gain range
Max. input level
Impedance
Signal-to-noise ratio
Distortion (THD+N)
XLR, electronically balanced,
discrete input circuit
-134 dB / 135.7 dB A-weighted
-131 dB / 133.3 dB A-weighted
-129 dB / 130.5 dB A-weighted
<10 Hz - 150 kHz (-1 dB),
<10 Hz - 200 kHz (-3 dB)
+10 to +60 dB
+12 dBu @ +10 dB Gain
approx. 2.6 kΩ balanced
110 dB / 112 dB A-weighted
(0 dBu In @ +22 dB gain)
0.005% / 0.004% A-weighted
Line Input
Type
Impedance
Gain range
Max. input level
Fade-Out Attenuation (Crosstalk Attenuation)
1
Main fader closed
Channel muted
Channel fader closed
1/4" TRS connector
electronically balanced
approx. 20 kΩ balanced
10 kΩ unbalanced
-10 to +40 dB
+22 dBu @ 0dB Gain
90 dB
89 dB
89 dB
