- Page 1 Micro System with iPod Dock Instruction Manual MODEL: CM-200 READ THIS INSTRUCTION MANUAL BEFORE OPERATING THE APPLIANCE. SAVE THIS MANUAL FOR FUTURE REFERENCE.
- Page 2 Contents...
- Page 3 Warnings The exclamation point within the triangle is a warning sign alerting the user of important instructions accompanying the product. The lightening flash with arrowhead symbol within the triargle is a warning sign alerting the user of “dangerous voltage” inside the unit. To reduce the risk of electric shock, do not remove the cover.
-
Page 4: Important Safety Instructions
Caution TO PREVENT FIRE OR SHOCK HAZARD,DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. THE LIGHTNING FLASH WITH WARNING: TO REDUCE THE RISK THE EXCLAMATION POINT WITHIN... - Page 5 7.) Do not install near any heat sources such as radiators, heat registers, stoves,or other apparatus (including amplifiers) that produce heat. 8.) Do not defeat the safety purpose of the plug. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
-
Page 6: Preparation For Use
Preparation For Use UNPACKING AND SETUP Carefully remove all the components from the display carton and verify that you have all the necessary components before you dispose of the display carton. Remove all packing materials from the individual components.Remove any descriptive labels that may be attached to the front panel of the main unit.Do not remove any labels or stickers on the back panels of the main unit or the speakers. -
Page 7: Front Panel
CM-200 FRONT PANEL 9 10 TOP PANEL... -
Page 8: Location Of Controls And Indicators
Location Of Controls And Indicators STANDBY Button FUNCTION Button C.ADJ / MEMORY Button SKIP / TUNE Button VOLUME CONTROL SKIP / TUNE Button STOP/BAND Button PLAY/PAUSE Button OPEN / CLOSE Button 10) iPod Compartment 11) SPEAKER UNIT 12) CD Door 13) IR Sensor 14) LCD Display 15) SPEAKER Output L... - Page 9 Set Up Method Of Holding Stand When you are placing the unit on the desk,extend the holding stand which located at the back cabinet of the unit in order to hold the unit firmly. When the unit is mounting on the wall,return the holding stand back to its original position.
-
Page 10: Remote Control
Remote Control STOP/BAND Button STANDBY Button OPEN / CLOSE Button FILE +10 /iPod UP Button PLAY/PAUSE Button MENU / INFO Button SKIP / TUNE Button SKIP / TUNE Button FILE-10 /iPod DOWN Button 10) FUNCTION Button 11) ENTER / FOLDER + Button 12) CLK-ADJ. -
Page 11: Remote Control Battery
Remote Control Battery The remote control requires one“ button-type ”3-volt lithium battery, included. To extend the life of the original battery,we have inserted a small clear plastic spacer tab between the lithium battery and the battery terminal. You must remove this battery spacer tab before you can use the remote control . -
Page 12: Connecting To Power
Connecting To Power Before switching on make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. For your own safety read the following instructions carefully before attempting to connect this unit to the mains. MAINS (AC) OPERATION This unit is designed to operate on AC 240V 50Hz current only.Connecting it to other power sources may damage the unit. -
Page 13: Operation
Listen To AM / FM Radio OPERATION Press the STANDBY Button on the main unit or remote control to power on the unit. Select FUNCTION Button on the unit or on the remote control to choose the Tuner mode. Select the desired frequency band by pressing the STOP/BAND Button. Tune to the desired radio station by pressing the SKIP/TUNE &... - Page 14 Press the MEMORY button on the remote control,“ MEMORY ”will flash in the display and a preset number “ 1 ” will also appear on the display. Press the M-UP & M-DOWN buttons on the remote control to select the desired preset station number.
-
Page 15: Fm & Fm-Stereo Reception
FM & FM-STEREO RECEPTION When in FM mode and the station is preset to broadcasting in Stereo, “ STEREO ”appears on the LCD display. When FM stations are weak and are disturbed,listening can be improved by selecting the FM Mono with the ST./MO Button on the remote control. Reception will then be in MONO. - Page 16 Compact Disc / MP3 Operation LOADING AND UNLOADING COMPACT DISCS - Press the STANDBY button to turn on the unit. - Select CD with the Function Button on the unit or on the remote control to choose the CD/MP3 mode. - Open the disc compartment by pressing the OPEN/CLOSE button on the main unit or remote control.
- Page 17 LISTENING TO COMPACT DISC AND MP3 DISC (CD) - Select CD with the Function Button on the unit or on the remote control to choose the CD/MP3 mode. A) In the CD mode This unit can read CD, CD-R, CD-RW. B) In the MP3 mode This unit can also read as below: 1.
- Page 18 - Press the PLAY/PAUSE button on the unit or remote control once to start playing the MP3 from the first track,the track no & counter will appear on the display. - Press the PLAY/PAUSE button again to pause playing the MP3,and the counter no will flash on the display.
-
Page 19: Programmed Disc Play
REPEAT PLAY IN MP3 DISC (For Remote Control Only) When playing the MP3, if you desire to repeat the same track only, press the REPEAT button on the remote control once and the " REPEAT " display will light up. To repeat all disc, press the REPEAT button twice and the "... - Page 20 Press the SKIP/TUNE & SKIP/TUNE buttons to select the track to be stored in location “ 01 ” (i.e. track 03). Press the C-ADJ/MEMORY button on the main unit or MEMORY button on the remote control, the first program selection is now stored in the program memory.
-
Page 21: Clock / Timer Function
Note: If the PLAY/PAUSE button is pressed before the C-ADJ/MEMORY button is pressed to store a track, that track will not be programmed, and the disc will start playing from the first selected track. Any track can be programmed to play more than once. Listening to Programmed Tracks Press the PLAY/PAUSE button. - Page 22 Press the C-ADJ/MEMORY button again, the minutes will start flashing. Adjust the minutes by pressing the SKIP/TUNE & SKIP/TUNE buttons. Press the C-ADJ/MEMORY button again, the TIMER OFF will display. Repeat the TIMER ON process again. Press C-ADJ/MEMORY button again, the “ TIMER OFF ” will flashing. Select “...
- Page 23 To decrease the sleep time in steps of 10 minutes,press SLEEP button until number 10 appears. After a few seconds,the previous display is shown again (e.g. with Tuner or CD information). To switch off the system before the SLEEP time has elapsed, press the STANDBY button on the main unit or on the remote control.
- Page 24 The auxiliary function will only activate when the aux in jack is fitted with connection cable. Note: The connection cables are not included. Press the STANDBY button on the main unit or remote control to power on the unit. Press the FUNCTION button on the main unit or remote control to select AUX function.
-
Page 25: Care And Maintenance
Important Since movement of the CD mechanism and the sensitive circuitry may cause interference to a radio tuner nearby switch this unit off while operating other radio devices. This product utilizes a laser. Danger - Invisible laser radiation when opened and interlock failed or defeated. -
Page 26: Specification
Specification Power Supply AC: 240V ~ 50Hz Radio Frequency Coverage FM: 87.5 – 108 MHz AM: 522 – 1620 kHz Speaker System Impedance: 4 Ohm Maximum Input: 8 W iPod Accessories Supports: iPod mini,nano,photo and video(Except shuffle) Design and specifications are subject to change without notice.
