Beckett AquaSmart 7600WTM Manual

PARTS & ACCESSORIES
AquaSmart
Wireless Temperature Module
Model 7600WTM
Wireless Outdoor Temperature Reset
Description / Applications
(OTR) settings like reset ratio and boost have been made easier
to adjust and are accessible through the AquaSmart control's
backlit LCD digital display. The WTM is backwards-compatible
with all existing AquaSmart controls. The WTM may provide
additional fuel savings over the built-in HeatManager algorithm
with the addition of a warm weather shutdown feature that can
disable the low limit. It is ideal for installations with high indirect
domestic hot water demands or a large water mass (such as
radiant in-fl oor heating).
NOTICE
Non-intended usage can cause damage to the WTM or the control
being connected to and potentially alter control or system operation.
○
This device is only for use in the United States and Canada.
○
For information regarding installation and operation of the
AquaSmart control, consult the latest revision of Beckett form
no. 61738 available at www.beckettcorp.com.
The
Wireless Temperature Module
(WTM) is a 2-part accessory
for
control. It adds outdoor reset
capability to the AquaSmart
control
control's built-in HeatManager
algorithm
The wireless feature makes
installation easy by eliminating
mounting location limitations
for the outdoor sensor and
the need to run wires outside.
Outdoor Temperature Reset
This accessory is NOT intended for use on any
other Non-AquaSmart Control or Equipment.
®
Beckett AquaSmart
the AquaSmart
by overriding
when installed.
®
boiler
the
