- Page 1 ALPHASONIK Owner's Manual HIGH CURRENT POWER AMPLIFIERS PMA600HCE / PMA640HCE / PMA1000HCE...
- Page 2 Today, the new Alphasonik is committed to pushing the envelope with regard to technology, quality and value. Our electronics fea- ture audiophile parts and circuit topology designed to let the full musical experience come through, loud and clear.
- Page 3 Introduction...3 Features and Specifications...4-5 Controls & Funtions...6-9 Planning & Mounting Your System...10 Wiring Diagrams...11-13 Adjusting & Tuning...14 Troubleshooting...15 Warning / Disclaimer...16 Warranty...17-18...
- Page 4 This manual contains important information about installation, set-up procedures and integrating your new Alphasonik product into your vehicle. With proper care and installation, your new product will provide you with many years of high performance listening enjoyment. We recommend having...
- Page 5 High Current Power Amplifier 1 Ohm Mono (PMA 600HCE / 640HCE / 1000HCE) Hour Meter Cooling Fan Remote Control For Digital Voltmeter Beveled Clear Acrylic Protective Cover Tiffany-Style Input and Output RCA Jacks Heavy-Duty Heat Sink High Speed Switching Power Supply Double Sided Glass Epoxy Circuit Board 4-Way Protection Circuitry: Thermal, short Circuit,Overload and DC Offset...
- Page 7 PMA600HCE / PMA640HCE / PMA1000HCE &...
- Page 8 PMA640HCE &...
- Page 9 1. Speaker Terminals: These nickel plated connectors can accept from 10 to 8 gauge wire. Be careful to observe proper polarity when connecting the cables. 2. To avoid unwanted ignition noise caused by ground loops, it is essential that the amplifier be grounded to a clean, bare, metal surface of the vehicle’s chas- sis.
- Page 10 9. Variable Low-Pass filter (50Hz – 250Hz): For use as a dedicated subwoofer channel, set filter switch to “LPF”. Adjust variable crossover frequency with control as desired. The amplifier input circuit filters out everything above 50Hz… ..250Hz (dependent on the adjustment of the frequency control), so only the deepest bass notes are amplified.
- Page 11 Planning Your System Before beginning the installation, consider the following: A. If you plan to expand your system by adding other components sometimes in the future, ensure that adequate is left, and cooling requirements are met. B. Are your components matched? The peak power rating of your speakers must be equal or greater than the amplifier’s.
- Page 12 PMA600HCE / PMA1000HCE MONO MODE STEREO MODE TRI MODE BRIDGED...
- Page 13 PMA640HCE 2 CHANNEL MODE 3 CHANNEL MODE 4 CHANNEL MODE...
- Page 14 PMA640HCE 6 CHANNEL MODE...
- Page 15 Turning On The Amplifier The amplifier automatically turns on a few seconds after you turn vehicle’s igni- tion switch to ACC ON or turn on your auto sound system, depending upon how you wired the system. The POWER indicator on the top of the amplifier illumi- nates when the amplifier is on.
- Page 16 SYMPTOMS NO SOUND AMP. NOT SWITCHING NO SOUND CHANNEL AMP. TURNING OFF MEDIUM / HIGH VOLUME PROTECTION LAMP CHECK Is the power LED illuminator? (NO) Is the Diagnostic LED illuminated? (YES) No power to power wire No power to remote wire with receiver on Burnt or broken fuse IN ONE...
- Page 17 IMPORTANT: Never cut any metal that is an integral part of the vehi- cle’s safety or structural support system. If you are unsure, it is best to have the product professionally installed by an Authorized Alphasonik Dealer. Never sacrifice your safety for sound.
- Page 18 SERVICE OF THIS PRODUCT. Information about Alphasonik, Inc. authorized warranty service may also be obtained at www.alphasonik.com or by contacting or writing Alphasonik, Inc. at the address listed on the back of this booklet. 2. This warranty will become void if service is performed by any one other than an approved Alphasonik, Inc.
- Page 19 YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. 10. Should you have any difficulties with the performance of this prod- uct during warranty or with any Alphasonik, Inc. authorized service center, you may contact the Alphasonik, Inc. National Service Manager at the address listed on the back of the booklet card or call 714.670.8950 for a listing of Authorized...
- Page 20 Alphasonik Inc. 7050 Village Drive Bldg G Buena Park CA 90621 TEL: (714)670-8950 FAX: (714)670-8959 www.alphasonikinc.com...
