v. 6.july.2010
DVM COMPRESSORE
owner's manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVM Compressore and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DV Mark DVM Compressore

Summary of Contents for DV Mark DVM Compressore

  • Page 1 v. 6.july.2010 DVM COMPRESSORE owner’s manual...
  • Page 2 MORE INFORMATION For warranty and service information, please contact your local DV Mark distributor (contact information available at www.dvmark.it). For more technical information, please visit us at www.dvmark.it and fill out the form on the Contact Us page. We hope you enjoy your effect pedal and use it to make great music! “The Lightning Flash with arrowhead symbol within an equilateral triangle, is intended to alert the...
  • Page 3 Mark dvM coMPressore! dvM coMPressore (we chose an Italian name to express how proud we are to manufacture all our products in Italy) is a high-quality tube compressor that features all the individual controls normally found on professional studio outboard compressors: gain, threshold, ratio, attack, release and volume.
  • Page 4 4. FUNCTION OVERVIEW GAIN (1) - instrument input level control THRESHOLD (2) - input level at which the sound becomes compressed RATIO (3) - how intense the compression is ATTACK (4) - how quickly the sound is compressed RELEASE (5) - how quickly the sound decompresses VOLUME (6) - This output volume control allows you to balance the compressed signal level with your uncompressed signal level (when the pedal is off ).
  • Page 5 This warranty does not apply to any damage to the product caused by misuse, mishandling, accident, abuse, alteration, modification or unauthorized repairs. Product appearance and normal wear and tear (worn paint, scratches, etc.) are not covered by this warranty. DV Mark reserves the right to be the sole arbiter regarding the misuse or abuse of this product.
  • Page 6 If any problem occurs, please don’t hesitate to contact our support team at service@dvmark.it. You can fill out this form and send a copy to DV Mark (Parsek srl, Via Po 52, 66020 San Giovanni Teatino, CHIETI ITALY) or, even better, you can now register your warranty online in a matter of minutes, using our online registration form at www.dvmark.it.
  • Page 7 6. TECHNICAL SPECS 7. BLOCK DIAGRAM InPut IMPedAnce: 300 Kohm GAIn: 0 ÷ +16dB tHresHoLd: 30mvp ÷ 1,8vp rAtIo: 1:1 ÷ 1:∞ (hard limiter) AttAcK: 2 ÷ 50 ms reLeAse: 100 ÷ 750 ms outPut IMPedAnce: 100 ohm Power requIreMents - dc InPut: +12vdc 700mA tuBe: 1x ecc81...
  • Page 8 Product specifications are subject to change without notice Via Po, 52 - 66020 San Giovanni Teatino (Ch) - Italy - Tel. +39 085 446 3755 - Fax +39 085 440 7764 www.dvmark.it - info@dvmark.it...
