American DJ Avenger ll User Instructions

American DJ
Avenger II
WITH 10 LENSES!
CAUTION!
SPECIFICATIONS: MODEL - Avenger II™
Weight: 18 lbs.
Size: 14"H x 14"W x 16"L
Lamp: 2x ZB-64514 - 120V 300W
Fuse: 7A
Supply Voltage: 120V
Working Position: Any Safe position
Duty Cycle: maximum 10 min. on/off
Colors: 10 Multiple Colored Lenses
Optional: ZB-ADJ300 120V 300W 150 hr. Long Life lamp
also available.
Product Discription:
Great effect for mobile DJ's and small clubs, the Avenger II™ produces 20 beams of multi-color light that rotate back and
forth to the beat o f t he music via the internal mic. F an coo led, e xtrem el y reli able. I nc lude s han ging
bracket and lamps. Optional 300W ADJ-300, 150 hr. Long Life lamp also available.

Operating Instructions:

Unit is rea dy to be hung o r set o n fla t surface. U nit wil l reac t to bass sou nd of mu sic via i ts inter nal
microphone. Adjust the sensitivity knob on rear of unit for desired effect. Be sure not to obstruct cooling vents. Keep in a
well ventilated area. For best results, use fog in order to see the beams of light.
Caution! Never open unit when in use. Always disconnect main power before serving or replacing lamp. Remember always
replace same lamp and fuses.
Lamp replacement: Unscrew lamp replacement door. Remove and replace lamp.
Affordable Quality Lighting Products from American DJ® Los Angeles, CA. 90058
Read instructions before installing or operating unit.
User Instructions
®
™

HALOGEN LAMP WARNING!

This fixture is fitted with halogen
lamps which are highly suscepti-
ble to damage i f impro p e r l y
handled. Never touch lamp with
bare fingers as the oil from your
hands will shorten lamp life. Also,
never move fixture until lamp
has had ample time to cool.
R e m e m b e r, lamps are not cov-
ered under warranty conditions.
