Not Recommended for New Installations.
Please contact Technical Support for more information.
PCMCIA Ethernet Adapter Card
Model ETCIACT
Documentation Number ETCIACT0698
B&B Electronics Mfg. Co. Inc.
707 Dayton Road -- P.O. Box 1040 -- Ottawa, IL 61350
PH (815) 433-5100 -- FAX (815) 433-5105
Internet:
http://www.bb-elec.com
orders@bb-elec.com
support@bb.elec.com
B&B Electronics -- February 1998
Documentation Number ETCIACT0698 Manual
Cover Page
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH (815) 433-5100 -- FAX (815) 433-5105

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ETCIACT and is the answer not in the manual?

Questions and answers

Related Manuals for B&B Electronics ETCIACT

Summary of Contents for B&B Electronics ETCIACT

  • Page 1 Not Recommended for New Installations. Please contact Technical Support for more information. PCMCIA Ethernet Adapter Card Model ETCIACT Documentation Number ETCIACT0698 B&B Electronics Mfg. Co. Inc. 707 Dayton Road -- P.O. Box 1040 -- Ottawa, IL 61350 PH (815) 433-5100 -- FAX (815) 433-5105 Internet: http://www.bb-elec.com orders@bb-elec.com...

  • Page 2: Table Of Contents

    Table of Contents CHAPTER 1: MODEL ETCIACT ETHERNET ADAPTER CARD ..1 1.1 I ..................1 NTRODUCTION 1.2 F ..................1 EATURES 1.3 P .................1 ACKAGE ONTENTS 1.4 LED I ................1 NDICATORS 1.5 C ..............2 ABLE EQUIREMENTS 1.6 T : ........2 RIVER ONTAINS THE OLLOWING CHAPTER 2: HARDWARE INSTALLATION ........3 2.1 T...

  • Page 3: Chapter 1: Model Etciact Ethernet Adapter Card

    Chapter 1: Model ETCIACT Ethernet Adapter Card This chapter introduces the ETCIACT Ethernet adapter card and describes the features, unpacking information, and description of the LED indicators. 1.1 Introduction The ETCIACT allows portable computers with a type II PCMCIA slot to connect to a network.

  • Page 4: Cable Requirements

    1.5 Cable Requirements 10Base T: Category 3, 4, and 5 UTP cable can be used. Maximum distance for each UTP cable is approximately 100 meters (328 feet). 10Base 2: The connection uses RG-58 A/U thin coaxial cable. Requires a T connector to connect the cable to the BCN port. The last PC in the segment will require a 50-Ohm terminator to be attached to the open arm of the T connector.

  • Page 5: Chapter 2: Hardware Installation

    Chapter 2: Hardware Installation 2.1 To Install the Ethernet Adapter Card: Turn off the power to your PC. Insert the ETCIACT adapter card into a type II PCMCIA slot. Be sure that the ETCIACT card is installed label side up. Slide the card all the way into the slot.

  • Page 6: Chapter 3: Configuration/Software Installation

    Chapter 3: Configuration and Software Installation This chapter assumes that you have already finished the hardware installation step. If you have not completed this step go to Chapter 2: Hardware Installation. It is also assumed that when your Operating System was installed that the Card Service support and the Socket Services support were included with the Operating System installation.
  • Page 7 Click on next to install the Network adapter manually. g) Select Network adapters. h) From the select Device dialog box choose Novell/Anthem from the Manufacturers List and NE2000 compatible as the model. i ) Click “OK” the next dialog box will show you the I/O address and Interrupt Request.

  • Page 8: Onfiguration Information

    j ) Windows then copies the files and may ask you to insert a Windows disk . Insert the disk and click “OK”. k) Reboot your PC. To check the installation go to Control Panel (Start/Settings/Control Panel). Click on the Device Manager tab, click on Adapter, and double click on the adapter that you installed.

  • Page 9: Socket Services And 3.3 Additional Software

    3.2 Socket Services and Card Services Installation In most cases the Operating System of your PC came with the PCMCIA Card Service and Socket Service drivers already installed or on a Utility disk. Refer to your PC’s manual for specific information. The following programs are available on the driver disk for installing Card Service and Socket Services.
  • Page 10 Chapter 4: Troubleshooting If the ETCIACT Ethernet adapter card is not working properly try the following: a) Check the connections – re-plug the cables and check for any signs of damage or a bad connection b) Check the ETCIACT card connection- be sure that the card is oriented properly (label side up) c) For a 10Base-T LAN segment –...
