Specifications; Hard Drive; Expansion Slots; Environmental Information - Sony VGC-LT37N - Vaio All-in-one Desktop Computer Specifications

VGC-LT37N

Specifications

General
Computer Type: Desktop
Type of Use: All-in-one
Hardware
Keyboard: 99 keys, 19.05 mm pitch, 2.7 stroke
Action Buttons: Action Buttons on Keyboard -
Standby, S1, S2, S3, Volume-/+, Muting, Power
On/Off.
Action Buttons on PC - Display On/Off, WLAN
On/Off, Keyboard/Mouse connection.
Camera: Built-in 1.3 megapixel MOTION EYE®
camera and microphone
Mount Design: VESA-100
Processor
Type: Intel® Core™ 2 Duo Processor T9300
1
Speed: 2.50GHz
Front Side Bus Speed: 800MHz
L2 Cache: 6MB
Memory
Type: DDR2
Installed: 3GB PC2-5300 (2GBx1 + 1GBx1)
14
Maximum: 4GB
Speed: 667MHz

Hard Drive

2
Capacity: 500GB
Speed: 7200rpm
Interface: Serial ATA
Optical Drive #1
DVD+R DL Write: 6x max.
DVD+R Write: 8x max.
DVD+RW Write: 8x max.
DVD-R Write: 8x max.
DVD-RW Write: 6x max.
CD-R Write: 24x max.
CD-RW Write: 4x max.
5
DVD±RW: Yes (DVD±R DL/DVD±RW/RAM Drive)
CD Read: 24x max.
DVD Read: 8x max.
DVD-RAM Write: 5x max.
DVD-R DL Write: 6x max.
DVD-RAM Read: 5x max.

Expansion Slots

Multimedia Card Reader: One Memory Stick
Duo™ media slot with MagicGate®
functionality
One PCMCIA - Type II/Type I card slot with
CardBus support
One ExpressCard® /34 slot
One Secure Digital (SD™ memory card) media
slot
Audio
Sound System: Intel® High Definition Audio
Speakers (Total): 2 x 3 Watt stereo speakers + 5
Watt subwoofer
Display
6
Screen Size: 22"
Resolution: 1680× 1050
XBRITE-HiColor™ Technology: Yes
Technology: WSXGA+
Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Graphics
Processor: Mobile Intel® Graphics Media
Accelerator X3100 with Intel® Clear Video
Technology with Total Available Graphics
10
Memory of 358MB (max.)
Chipset: Mobile Intel® GM965 Express Chipset
Inputs and Outputs
Audio In: 1 (Line In)
Ethernet Port: 1
Headphone Jack: 1
9
i.LINK® Interface: 1 4-pin interface
Modem Jack: 1
Microphone Input: 1
USB Port(s): 5 (2.0 compliant)
DC-In: 1
S/PDIF Output(s): 1
Networking/Modem
Ethernet Protocol: 10Base-T/100Base-TX/1000Base-
T
Ethernet Speed: Fast Ethernet (RJ-45)
Modem Type: V.92/V.90 compatible data/fax
modem (RJ-11)
Wireless LAN: Intel® PRO/Wireless 4965AGN
Network Connection (802.11a/b/g/n)
Power
Power Requirements: 168W+10%
Input Voltage: 100-240V
Software
Operating System: Genuine Microsoft® Windows
Vista® Business with SP1
Internet Services: AOL® 90-Day Risk Free Trial - For
new users only
Supplied Software: Microsoft® Works SE 9.0 w/
60-Day Trial Version of Microsoft® Office Small
13
Business 2007
Security and Anti-Virus Software: Microsoft®
Windows Live™ OneCare™ Trial Version
The VAIO® Software Experience: VAIO® Startup
Assistant
Click to Disc™ Editor - Import, Edit, Burn
VAIO® Movie Story - Simple Movie Creation
VAIO® MusicBox - Music by Mood
VAIO® Media plus - Multimedia Streaming
Software
*Please access VAIO® Help and Support from
your PC for a complete list of software and trial
applications.
Service and Warranty Information
Limited Warranty: 1 year limited warranty . See
actual warranty for details.
Telephone Support: 1 year toll-free technical
telephone assistance, available 24/7 .
Online and Email Support: Support available
from http://www.esupport.sony.com/EN/VAIO

Environmental Information

EPEAT™ : Meets Silver EPEAT™ Rating
RoHS®: Compliant
For more information:
www.sony.com/vaioeco
Regulation and Standard Compliance
Energy Star® Compliant: 4.0
Dimensions
7
Weight: 22.7 lbs. (CPU and Display only)
VAIO® LT PC/TV All-in-one
Measurements: 25.3"(W) x 16.5"(H) x 7"(D)
and Display only)
Supplied Accessories
AC Adapter (VGP-AC19V17)
Wireless Keyboard (4 batteries)
Wireless Mouse (2 batteries)
8cm Disc Adapter
Color: Silver
UPC Code: 027242742543
1. GHz denotes microprocessor internal clock speed; other factors may
affect application performance. CPU speed will be reduced under
certain operating conditions.
2. GB means one billion bytes when referring to hard drive capacity.
Accessible capacity may vary. A portion of hard disk space is
reserved as a recovery partition.
3. Requires 802.11n compatible access point. Some functionality may
require Internet services, which may require a fee.
4. Broadband Internet service required along with third party services
which may require a subscription or other service fee.
5. DVD media/formats are not universally compatible.
6. Viewable area measured diagonally.
7. Non-metric weights and measures are approximate and may vary.
8. Measured at the narrowest point
9. i.LINK is a trademark of Sony used only to designate that a product
contains an IEEE 1394 connector. All products with an i.LINK
connector may not communicate with each other.
10. Total Available Graphics Memory refers to the new Windows Vista®
classification of graphics memory, which is the total of Dedicated
Video Memory, System Video Memory and Shared System Memory.
3
Shared System Memory varies depending on the operating condition
and system memory size.
11. See actual limited warranty for details. For a copy of Sony's warranty,
please visit www.esupport.sony.com, call toll-free 888-476-6972 (888-
4SONYPC), or write to Sony Electronics, 12451 Gateway Boulevard,
Fort Myers, FL 33913.
12. For certain third party software applications, Sony provides first level
phone support. Additional telephone support may be available from
the applicable 3rd party vendor. Availability and schedule for any
such support is determined by the applicable software vendor.
13. 60-Day Trial Version of Microsoft® Office 2007 - This trial software will
work only for 60 days after you first use it. You will not be able to use
the software if you do not activate it as described the first time you use
the software. You can activate the software by Internet: Internet
service charges may apply. If you want to keep using the software
after the 60-day trial period, you must convert to the perpetual
version. You can convert online by following the conversion
instructions presented during setup and paying the required fees.
14. A portion of the system memory over 3GB may not be available to
the operating system.
15. Requires wall mount bracket sold separately. Restrictions apply.
Computer Interface: For this product,there are a multitude of varying
software packages and add-on hardware options. This product is not
manufactured to work with any specific software, and Sony does not and
cannot make any warranty or representation with respect to the
performance of this product with any particular software packages
and/or non-Sony add-on hardware options except those mentioned here.
Sony hereby disclaims any representations or warranties that this
product is compatible with any combination of non-Sony products you
may choose to connect to it. While Sony representatives or Sony
authorized dealers may be able to assist you and may make
recommendations, they are NOT authorized to vary or waive this
disclaimer. Purchasers must determine for themselves the suitability and
compatibility of the hardware and software in each and every particular
instance. Software titles pre-installed on the Sony computer are subject
to change without notice. Preinstalled software may not be identical to
retail versions or have all documentation. Features and specifications are
subject to change without notice. This product meets the standards of the
International Energy Star Program for energy efficiency.
Lamp in this product contains mercury. Disposal of these materials may
be regulated due to environmental considerations. For disposal or
11
recycling information, please contact your local authorities or the
Electronic Industries Alliance (www.eiae.org).
©2008 Sony Electronics Inc. All rights reserved. Reproduction in whole or
in part without written permission is prohibited. Sony, i.LINK, VAIO, XBRITE-
12
HiColor, VAIO logo, Handycam, MOTION EYE, Memory Stick Duo,
MagicGate, and Click to Disc are trademarks of Sony in the U.S. and in
other countries. Intel, Centrino and Core are trademarks of the Intel
Corporation in the U.S. and in other countries. Microsoft and Windows
Vista are registered trademarks of the Microsoft Corporation in the U.S.
and in other countries. All other trademarks are trademarks of their
respective owners.
Printed 04/08.
7,8
(CPU
Last Updated: 06/30/2008
