Summary of Contents for Alphasonik PBD100E
- Page 1 ALPHASONIK Owner's Manual BASS DRIVER PBD100E...
- Page 2 Today, the new Alphasonik is committed to pushing the envelope with regard to technology, quality and value. Our electronics feature audio- phile parts and circuit topology designed to let the full musical experience come through, loud and clear.
-
Page 3: Table Of Contents
Introduction.................3 Features and Specifications..........4 - 8 Troubleshooting................9 Disclaimer..................10 Warranty................11 - 12 Notes...................13 - 14... -
Page 4: Introduction
Thank you for purchasing this Alphasonik product. Alpha- sonik products are specifically engineered and designed for the mobile audio environment. This manual contains important information about installation, set-up procedures and integrating your new Alphasonik product into your vehicle. With proper care and installation, your new product will provide you with many years of high performance listening enjoyment. -
Page 5: Features And Specifications
FEATURES Bass Driver: The PBD100E contains a Bass Driver circuit that accu- rately recreates and injects Low frequency information back into the signal path. What that means in everyday terms is that the PBD100E will give more bass impact to your best compact discs or even your old tapes. - Page 6 PBD100E BALANCED DIGITAL BASS CONTROL WIDE SWEEP PF MS UB SO NIC BAS SL EVEL FI LTER PO WE R 35 Hz 80 Hz minm NOTE: For signal connection, the output RCA connectors should be connected to the next component after the PBD100E, such as a cross- over, equalizer, or amplifier.
- Page 7 PFM Subsonic Filter Control: This unique feature is legendary with its ability to fine tune the bass response of any system. Why waste power on nasty subsonic information when PFM Subsonic Filter Control can help you to clean things up? Bass Output Control: The PBD100E has the ability to produce large amount of deep, mind shattering bass without damaging your speakers.
- Page 8 8. Input Grounding: For most systems you can leave this jumper set in the BALANCED position. In some systems, the source unit may look for a ground through the RCA connectors. In this event, you should go ahead and change the jumpers to the UNBALANCED position. 9.
- Page 9 B+ (12V): Connect a positive 12 Volt Source. REMOTE: Connect to remote turn on from the source unit. GND: Connect to Chassis Ground of Vehicle. BALANCED DIGITAL BASS CONTROL PBD100E WIDE SWEEP...
-
Page 10: Troubleshooting
If the Unit does not turn-on, and/or the power indicator LED is Not illuminated, do this. 1. Check and make sure that B+ and GND are not reversed. 2. Check that all power Wires are properly connected and has the appropiate voltage, 11 - 16 volts. -
Page 11: Disclaimer
IMPORTANT: Never cut any metal that is an integral part of the vehicle’s safety or structural support system. If you are unsure, it is best to have the product professionally installed by an Authorized Alphasonik Dealer. Never sacrifice your safety for sound. -
Page 12: Warranty
RANTY SERVICE OF THIS PRODUCT. Information about Alphasonik, Inc. authorized warranty service may also be obtained at www.alphasonikinc.com or by contacting or writing Alphasonik, Inc. at the address listed on the back of this booklet. 2. This warranty will become void if service is performed by any one other than an approved Alphasonik, Inc. - Page 13 Alphasonik, Inc. An Alphasonik Extended Warranty Registration Card must be submitted to Alphasonik, Inc. within 30 days of purchase. To process any warranty claim, Alphasonik, Inc. will require the dated proof of purchase, which must specifi- cally show the model and serial number and that installation was provided for the product in question.
- Page 16 ALPHASONIK INC. 7050 VILLAGE DRIVE BLDG. G BUENA PARK, CALIFORNIA. 90621 TEL: (714)670-8950 · FAX: (714)670-8959 www.alphasonikinc.com...
