Alinco EBC-6 Manual

There are two ways to affix the EBC-6 to your car window. See interior molding of your car window to
determine which method is best for you.

Method 1

The EBCS clamps to the interior window molding using bracket-A from the top and bracket-6 from the
bottom (see FIG.l). Bracket-A should be hooked over the interior molding while bracket-B should be slid
in between the molding and the door panel. Clamp tightly. Slide in the bracketcover all the way to the
to the groves of bracket-A (see FIG.4). The bracket-cover may be cut to a desired length for best
operating position.

Method 2

The EBC-6 hangs bracket-A to the window slit. First fold bracket-A about 1.5 inches from the flat end
(see FIG.2). Insert the folded end into the window slit (see FIG.3). Slide in the bracket cover and bend
the bracket along the curvature of the door panel. Hook the radiihanger to the groves of bracket-A (see
FIG.4). The bracketcover may be cut to a desired length for best operating position.

FIG.1

Bracket B
Bracket Cover
Slide inthe
cover all the
to clamper

FIG.3

would help Stabilize
the bracket
438 Amapola Ave., Suite 130 . Torrance, California 90501
Phone: 31 O/61 8-8616

FIG.4

Rubber
Fax: 31 O/61 8-8758
