Summary of Contents for Alen Paralda
- Page 1 USER MANUAL HEPA AIR PURIFIER...
-
Page 2: Table Of Contents
CONTENTS Important Safeguards..........Know Your Air Purifier ..........Program Mode .............. Specifications ............. Warranty .............. -
Page 3: Important Safeguards
IMPORTANT! Please Read Before Starting 1. Read all instructions before operating the air purifier. . This product operates at 10V AC, 60Hz only. 3. Do not run power cord under carpets, and do not cover with throw rugs. 4. Arrange cord such that it will not be tripped over. 5. -
Page 4: Know Your Air Purifier
KNOW YOUR AIR PURIFIER Reminder: Make sure the HEPA filter is properly installed before use. Where to locate: 1) Keep the unit in a place at least yards away from the TV set, radio, etc. to avoid interference. ) Do not blow air directly into the air purifier. 3) Keep both sides of the unit more than 6 inches away from the wall. - Page 5 KNOW YOUR AIR PURIFIER Control Panel for Paralda Air Purifier Filter Replacement Indicator On/Off Button Fan Speed button Program button Ionizer button UV button...
- Page 6 KNOW YOUR AIR PURIFIER Interior Housing (lift filter cover on top of unit to access). UV Casing Filter Cartridge Filter Reset UV Casing Replacing the UV Bulb 1) Before replacing the UV bulb, please unplug the unit and remove the cover. ) Lift the filter cover.
- Page 7 KNOW YOUR AIR PURIFIER Replacing the Filter Lift the filter cover. ) Turn the plastic locking mechanism that holds the filter in place. 3) Lift straight up on the filter cartridge handle and remove completely. 4) Insert the new filter. Re-lock the filter in place.
-
Page 8: Program Mode
PROGRAM MODE Program Mode: The program mode is designed to program fan speed changes at certain times throughout the day. 1. Press and hold PROGRAM key for 2 seconds to enter setup mode. The unit will beep and the clock will then start to blink. The CURRENT TIME will turn on. - Page 9 PROGRAM MODE NOTE: When in Program Mode, the clock is illuminated. When in Manual Mode, the clock is not illuminated. This is your visual indication for which mode you are using. In order to switch between Program Mode and Manual Mode, a short press of the PROGRAM key toggles between the modes.
-
Page 10: Specifications
SPECIFICATIONS Model Specifications Voltage 10V AC Frequency 60 Hz Power Max. Coverage Area 400 sq ft Net Weight 17.3 lbs Dimensions 11.3” x 8” x 8” HEPA Filter Life 6 months UV Lamp life 3-5 years Replacement Filter Cross Reference: Visit www.alencorp.com for a complete listing of suppliers. -
Page 11: Warranty
Alen shall not be liable for any loss or damage directly or indirectly arising from the use of the dehumidifier, or for any consequential damages arising from such use including damages from water leak- age.
