Summary of Contents for Aspire AD-N820B
- Page 1 OWNER'S MANUAL MODEL:AD-N820B POWER OPEN/CLOSE DVD/CD/MP3/CD-R/CD-RW/JPEG/KODAK PICTURE CD PLAYER PROGRESSIVE SCAN DVD PLAYER AD-N820B...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SUBTITLE BEFORE USE TITLE ANGLE Safety Precautions SEARCH Important Safety Instructions VOLUME and MUTE Notice REPEAT Disc Protection MENU Playable Discs ZOOM Accessories PROGRAM AUDIO A-B REPEAT CONTROL and CONNECTION Panel Basic connection SPECIAL FUNCTION PLAYBACK Remote control JPEG Disc Playback MP3 Playback BASIC PLAYBACK... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS The lightning flash with arrowhead symbol, within an equila- teral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage " within the product's en- closure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 4: Notice
SAFETY PRECAUTIONS FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rule. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Important Safety Instructions
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. -
Page 6: Disc Protection
The pickup may be condensed with water under the following situation. -
Page 7: Playable Discs
PLAYABLE DISCS and ACCESSORIES The following discs can be played: Designed for Windows Media Discs than those listed above can not be played. Non-standardized discs, even if they may be labeled as above can not be played. The performance of recorded disc is depend on the method and quality of disc-burning. In some cases, the disc may not be played. -
Page 8: Panel
PANEL FRONT PANEL PLAY/PAUSE STOP PREV NEXT POWER OPEN/CLOSE DVD/CD/MP3/CD-R/CD-RW/JPEG/KODAK PICTURE CD PLAYER PROGRESSIVE SCAN DVD PLAYER AD-N820B 1.PLAY/PAUSE 6.TRAY 2.STOP 7. REMOTE CONTROL SENSOR 3.PREVIOUS 8.LED SCREEN 4.NEXT 9. OPEN/CLOSE 5.POWER SWITCH REAR PANEL OUTPUT C / P DIGITAL AUDIO OUT COAXIAL Manufactured under license from Apparatus Claims of... -
Page 9: Basic Connection
BASIC CONNECTION BASIC CONNECTION Connecting to a TV with Audio/Video cable DIGITAL AUDIO OUT C / P COAXIAL OPTICAL S-VIDEO VIDEO C / P 2-CH AUDIO OUT VIDEO OUT To video input(yellow) To audio inputs(red, white) To S-video output To S-video input If the TV has an S-video input, connect the DVD player with an S-video cable. -
Page 10: Remote Control
REMOTE CONTROL REMOTE CONTROL Function Function 14. MUTE 1. OSD(On Screen Display) STANDBY MENU OPEN/CLOSE 2. STANDBY 15. REPEAT V.MODE 3. V.MODE 16. MENU SUBTITLE 4. SUBTITLE 17. OPEN/CLOSE TITLE/PBC ANGLE SEARCH 5. TITLE/PBC 18. DIGITS AND 10+ BUTTONS SETUP ZOOM PROG 19. -
Page 11: Basic Playback
BASIC PLAYBACK Preparations Previous and Next During playing, press PREV key can back to start When you want to view a disc, turn on the TV and of this chapter, then each press this key will skip a select the video input connected to the DVD player. chapter still the start of the disc. -
Page 12: Advanced Playback
ADVANCED PLAYBACK IMPORTANT NOTE: ALL DESCRIBING FUNCTION IS FOR DVD DISCS. IF YOU PLAY OTHER FORMAT DISC, THE OPERATION AND DISPLAY ON SCREEN WILL BE DIFFERENT. SEARCH Follow this operation : Press this button and the screen will display some first Title 02/10 Time : : information about disc, such as : "...
