7-BAND EQUALIZER WITH DIRECT SUB INPUT
3-WAY CROSSOVER WITH SUB SONIC FILTER
MANUAL AND USER GUIDE
XEQ
Front panel Sub output level control
Variable Sub woofer Crossover
Variable Sub woofer Crossover
4-Layer PC Board with SMT Devices
Direct "Sub Input"
8 Volt RMS Output
Input Clip Indicator for Easy Gain Setting
IDX
Fully Variable Band Pass Crossover
Sub Sonic Filter
Variable Sub Phase Shift
4-Layer PC Board with SMT Devices
Independent Front and Rear Inputs
8 Volt RMS Output
Output Clip Indicator for Easy Gain Setting
Advertisement
Table of Contents
Summary of Contents for ARC Audio IDX
- Page 1 7-BAND EQUALIZER WITH DIRECT SUB INPUT 3-WAY CROSSOVER WITH SUB SONIC FILTER MANUAL AND USER GUIDE Front panel Sub output level control Variable Sub woofer Crossover Variable Sub woofer Crossover 4-Layer PC Board with SMT Devices Direct "Sub Input" 8 Volt RMS Output Input Clip Indicator for Easy Gain Setting Fully Variable Band Pass Crossover Sub Sonic Filter...
-
Page 2: Table Of Contents
If at any Advanced System Controls and the full benefit of a High quality 7 Band point you begin to feel overwhelmed, return to your local Arc Audio dealer and let the trained professionals install or tune it for you. -
Page 3: Installation Information
The Connections and Controls Installation Information 1. The XEQ needs to be installed in the signal path between your source 1. Front Output unit and your external amplifier(s). 2. Rear Output 3. Input 2. Physically mount the XEQ near the drivers listening position. Make sure 4. -
Page 4: 2-Way With Direct Sub Input
1. Front Output: Simply connect to the amplifier driving the front speakers. This is a full 2-WAY With DIRECT SUB INPUT range output so if you plan to run it hard you should use a crossover at this point. 2. Rear Output: Just like it sounds, this is connected to the rear amp. 3. -
Page 5: 2-Way With Fading Front And Rear
2-WAY With FADING FRONT and REAR XEQ SPECIFICATIONS Signal to Noise Ratio (A-Weighted) >100dB THD @ 8.0V Output 0.005% Channel Separation >75dB EQ Frequency Range @ 50Hz +/- 12dB, Q=1.38 100Hz +/- 12dB, Q=1.20 275Hz +/- 12dB, Q=1.25 770Hz +/- 12dB, Q=1.18 2.2KHZ +/- 12dB, Q=1.08 6.0KHz... -
Page 6: Specifications
If at any point you begin to feel overwhelmed, return to your local Arc Audio dealer and let the trained professionals install or tune it for you. - Page 7 The Connections and Controls Installation Information 1. The IDX needs to be installed in the signal path between your source unit and your 1. Front Input 14. Front X-Over Gain external amplifier (s). 2. Rear Input 15. Front Frequency Control 2.
- Page 8 1. Front Input: This is the default input. If you are using one input (2 CH.) connect your RCAs here. 14. Front X-Over Gain: Each crossover has its own gain. This will make up front tuning much easier. You will only need to make basic adjustments to your amp gains. 2.
- Page 9 2-WAY FADING FRONT AND REAR 3-WAY WITH ACTIVE FILTERING NOTE: THE CONTROL POSITIONS SHOWN ARE FOR MIDS AND TWEETERS ONLY ONE SUGGESTED CONFIGURATION. YOUR NOTE: THE CONTROL POSITIONS SHOWN ARE SYSTEM MAY REQUIRE DEFERENT SETTINGS. ONLY ONE SUGGESTED CONFIGURATION. YOUR SYSTEM MAY REQUIRE DEFERENT SETTINGS.
- Page 10 3-WAY WITH ACTIVE FILTERING FOR MID-BASS AND COMPONENT SET NOTE: THE CONTROL POSITIONS SHOWN ARE ONLY ONE SUGGESTED CONFIGURATION. YOUR SYSTEM MAY REQUIRE DEFERENT SETTINGS. IDX SPECIFICATIONS Signal to Noise Ratio (A-Weighted) >100dB THD @ 9.0V Output 0.005% Channel Separation >75dB Sub Sonic Filter (12dB/Octave) 15Hz-150Hz...
