W h a t is t h e M x 1
Thank you for purchasing a ARC AUDIO product
MX1 is an extremely flexible dual output electronic
crossover.
Each output has its own crossover
frequency adjustment.
pass and high pass filter with high quality gold plated
RCA sockets for input and output.
K e y F e a t u r e s
2 Way Active Crossover.
Independently Adjustable Crossover Points ( Fine
tuning).
o
o
Phase 0 or 180 Selectable for Low Pass Filter.
Selectable 12dB (Stereo) or 24dB Slope(Mono) for
Low Pass Filter.
Dual Frequency Range
for Low Pass and High Pass.
The configurations are Low
~
55Hz
600Hz or 550Hz~ 6KHz
1
The
Advertisement
Summary of Contents for ARC Audio MX-1
- Page 1 W h a t is t h e M x 1 Thank you for purchasing a ARC AUDIO product MX1 is an extremely flexible dual output electronic crossover. Each output has its own crossover frequency adjustment. The configurations are Low pass and high pass filter with high quality gold plated RCA sockets for input and output.
- Page 2 C o n t r o ls F u n c t io n a l D ia g r a m INPUT HIG H PASS LOW PASS N o t e s When mono switch is selected the low pass output automatically switch to 24dB slope.
- Page 3 Dimensions L x H x D C a u t io n : MX-1 Amplifie r Continuous exposure to excessive sound pressure levels may cause permanent hearing loss. ARC AUDIO asks that you use common sense when setting volume levels.
