FD Series
FD5000 FD6000
Installation Manual
INTRODUCTION
Thank you for choosing ARC Audio's Foose Designs
line of hi-performance mobile audio products. We hope
you enjoy your experience with all our products and we
welcome any questions or comments you may have.
Specifications
FD5000
Diameter
5 ¼"
Musical Power
140 watts
Nor. Power
75 watts
Sensitivity
87db
Frequency
70hz-
response
20Khz
IMP.
4 Ohm
Protection
PTC
Most speaker damage occurs as a result of amplifier
distortion also known as "Clipping". Clipping occurs
when an amp is driven beyond its maximum rated
output. This kind of distortion can be hard to hear
unless you know what to listen for. Any time you hear
a harsh ear piercing sound at hi volume your amp is
probably clipping.
CAUTION:
FD6000
Diameter
6 ½"
Musical Power
175 watts
Nor. Power
90 watts
Sensitivity
87db
Frequency
60hz-
response
20Khz
IMP.
4 Ohm
Protection
PTC
1
Advertisement
Table of Contents
Related Manuals for ARC Audio FD5000
Summary of Contents for ARC Audio FD5000
-
Page 1: Specifications
INTRODUCTION Thank you for choosing ARC Audio’s Foose Designs line of hi-performance mobile audio products. We hope you enjoy your experience with all our products and we welcome any questions or comments you may have. Specifications FD5000 FD6000 Diameter 5 ¼”... - Page 2 Please check the suitability of the installation location before you begin. Do not cut any of the car’s structure. Pay attention to the mechanism of the window and door. If you do not have experience with automotive electrical and mechanical systems contact a professional installer.
- Page 3 Wiring Install the Tweeter When wiring this system it is important to make all The tweeter comes with 2 different types of connections carefully and securely. Follow the mounts. Flush mount and Surface mount. instructions carefully. All audio connections have a + and -.
-
Page 4: Limited Warranty
This number must be clearly marked on the outside of the box. damage to the component speakers. Terms & Conditions: ARC Audio warranties the unit to be free of any material defects • Care must be taken not to mix the tweeter and or defects in workmanship for a period of one year and will repair this unit or any part thereof only if it proves to be defective as a result of normal use.
