Apollo 120 III User Manual

12.1”/15.0”/15.1” tft intel celeron/pentium iii plastic-housing panel pc with versatile stand design
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
APOLLO 120 /150 III
12.1"/15.0"/15.1" TFT Intel
®
Celeron/Pentium
III
®
Plastic-housing Panel PC with
Stand design
Versatile
User' s Manual
(Version 2305)

Advertisement

Table of Contents
loading

Related Manuals for Apollo 120 III

Summary of Contents for Apollo 120 III

  • Page 1 APOLLO 120 /150 III 12.1”/15.0”/15.1” TFT Intel ® Celeron/Pentium ® Plastic-housing Panel PC with Stand design Versatile User’ s Manual (Version 2305)

  • Page 2: Copyright Notice

    Copyright Notice This document is copyrighted 2003 by the Manufacturer. The information provided in this document has been carefully checked and is accurate at the time of publication. However, the Manufacturer assumes no responsibility for any infringements of patents or other rights of third parties that may result from its use.
  • Page 3 Unpacking After unpacking the APOLLO 120/150 III carton, check and see if the following items are included and in good condition. APOLLO III main system Accessories Power cord (90 External FDD cable (optional) External 5V/12V DC power cable (optional) x 1 Utilities &...

  • Page 4: Important Safety Precautions

    Important Safety Precautions Before getting started, read these instructions and save them for later reference. Turn off the computer before cleaning. Clean with a damp or dry cloth only. Do not spray any liquid cleaner on screen directly. The power outlet socket used to plug in the computer power cord must be located near the system and easily accessible.
  • Page 5 10. The openings on the computer enclosure are for the cabin ventilation to prevent the computer from overheating. DO NOT COVER THE OPENINGS. 11. The brightness of the flat panel display will decrease with use. However, hours of use will vary depending on the application environment.

  • Page 6: Table Of Contents

    OVERS IN THIS ANUAL 1.3..........1-5 PECIFICATIONS 1.4..........1-10 IMENSIONS 1.4.1. APOLLO 120 ........1-10 1.4.2. APOLLO 150 ........1-11 2. USING THE SYSTEM ........2-13 2.1....... 2-14 DENTIFYING THE YSTEM 2.1.1. Front View........... 2-14 2.1.2. Side Views........... 2-15 2.1.3.
  • Page 7 4. I/O CONNECTION ........4-29 4.1........... 4-30 ARALLEL 4.2. COM P 4 ........4-31 ORTS X 4.3. 100/10 B -T E (RJ-45)....4-33 THERNET 4.4. VGA I ......... 4-33 NTERFACE 4.5....4-34 ISPLAY RAPHIC UPPORT 4.5.1. When System Memory Clock = 66MHz ..4-34 4.5.1.1.
  • Page 8 ......5-74 TAND ODULE SSEMBLY 6. SYSTEM MOTHERBOARD & I/O BOARD ..6-77 6.1. APOLLO III M ......6-78 OTHERBOARD 6.1.1. General Information ......6-78 6.1.2. Specifications........6-79 6.1.3. Locating Jumpers & Connectors....6-81 6.1.4. Jumpers & Jumper Setting..... 6-82 6.1.4.1.
  • Page 9 6.1.5.12. SCSI 1: PRT/Serial Port/DIO Port ..6-91 6.1.5.13. SCSI 2: KB/MS/VGA/LAN USB/FDD ... 6-92 6.1.5.14. CN4: PCI/ISA Expansion Slot.... 6-93 6.2. APOLLO III I/O B ......6-96 OARD 6.2.1. Locating Jumpers & Connectors....6-96 6.2.2. Jumpers & Jumper Setting..... 6-97 6.2.2.1.
  • Page 10 7. AWARD BIOS SETUP ........7-105 7.1. BIOS.......... 7-106 WARD 7.2......7-107 ONTROL EFINITION 7.3.......... 7-108 ETTING 7.3.1. Main Menu......... 7-108 7.4. AWARD BIOS S ....... 7-108 ETUP 7.4.1. AWARD BIOS Setup Main Menu.... 7-108 7.4.2. Standard CMOS Features..... 7-110 7.4.3.

  • Page 11: Introduction

    User Manual version 2305 1. I NTRODUCTION This chapter provides background information and detail specification on the APOLLO 120/150 III. Sections in this chapter include: General Information What covers in this Manual Specification Dimension APOLLO 120/150 III...

  • Page 12: General Information

    Celeron/Pentium III/Pentium IV plastic-housing multimedia panel PC system. With a 150W or 200W ATX power supply as its engine, the APOLLO is a genuine P4 panel PC designed for high performance multimedia application. Featuring with versatile stand design for different environmental applications, the APOLLO itself can be used as a ready-to-play system by connecting to necessary peripherals.

  • Page 13: What Covers In This Manual

    1.2. What Covers in this Manual This handbook contains most information you need to set up and use the APOLLO III system. You do not need to read everything in this handbook to use the system. For a quick start, see the following chapter summaries;...
  • Page 14 Appendix A details the 12.1”/15.0” or 15.1” LCD specifications. Appendix B introduces the DiskOnChip installation. Appendix C introduces the Wake-On-LAN feature. Appendix D explains the first MB memory map. Appendix E provides the specifications for the built-in power supply. APOLLO 120/150 III...

  • Page 15: Specifications

    User Manual version 2305 1.3. Specifications ® ® APOLLO: 12.1”/15.0” or 15.1” TFT Intel Celeron/Pentium III Plastic-housing Panel PC with Versatile Stand design SYSTEM Flat Panel APOLLO 120: 12.1” color TFT, 800*600 Viewing angle Luminance (cd/m 150 or above Simultaneous mode APOLLO 150: 15.0”/15.1”...
  • Page 16 Integrated 2D/3D graphics engine, 4X AGP u Share system memory architecture able to utilize the display memory size up to 64MB u Supporting LCD/VGA dual display mode (under Windows 98 and Windows ME and Windows XP) APOLLO 120/150 III...
  • Page 17 Expansion card size (L*W) PCI card: max. 190*120 mm ISA card max. 190*120 mm if no internal FDD is installed; 170*120 mm if internal FDD is installed Front Bezel LED indicators for HDD, LAN, POWER IrDA receiver (optional) APOLLO 120/150 III...
  • Page 18 CD-ROM or CD-RW or DVD-ROM or COMBO Slim type*1 (optional) or External type via USB Floppy Disk Drive Slim type*1 (optional) or Via external FDD or External type via USB Hard Disk Drive 3.5" HDD*1 (optional) or 2.5” HDD x 2 (optional) APOLLO 120/150 III...
  • Page 19 Inside: heavy-duty steel Outside: fire-proof resilient ABS/PC plastic Color (standard) Beige Black Dimension (chassis only, unit: mm) APOLLO 120: 368*321*116.5 (L*W*D); 334.7*284.21 (for panel mount) APOLLO 150: 406*360*129 (L*W*D); 384*284.2 (for panel mount) Mounting Panel mount with mounting kits Wall mount with swing arm: standard VESA mounting...

  • Page 20: Dimensions

    User Manual version 2305 1.4. Dimensions 1.4.1. APOLLO 120 The APOLLO 120’s chassis size is shown below. This does not include the dimension of the stand. This does not include the dimension of the stand. Figure 1-1: APOLLO 120 DIMENSION...
  • Page 21 User Manual version 2305 1.4.2. APOLLO 150 The APOLLO 150’s chassis size is shown below. This does not include the dimension of the stand. Figure 1-2: APOLLO 150 DIMENSION 1-11 APOLLO 120/150 III...
  • Page 22 User Manual version 2305 2-12 APOLLO 120/150 III...

  • Page 23: Using The System

    User Manual version 2305 2. U SING THE YSTEM Identifying the APOLLO system System setup for the first-time use 2-13 APOLLO 120/150 III...

  • Page 24: Front View

    I/O arrangement of the APOLLO 120/150. 2.1.1. Front View When the APOLLO 120/150 is put upright on the desktop with the provided pedestal, its front view appears as below. The illustrations of the APOLLO 120/150 may differ slightly because the APOLLO system series has two different LCD size: 12.1”...

  • Page 25: Side Views

    The left side of the panel PC appears as below: Screw holes for peripheral device attachment Floppy disk drive CD-ROM Side door for two PCI/ISA expansion outlet Cable management cutout Base covers +pedestal = versatile stand 2-15 APOLLO 120/150 III...

  • Page 26: I/O Outlets

    User Manual version 2305 2.1.3. I/O Outlets When you turn around the APOLLO system, you will find the power switch and all the I/O ports are located at the rear cover of the panel PC. . COM 4 . COM 2 XTERNAL .

  • Page 27: System Setup For The First-Time Use

    User Manual version 2305 2.2. System Setup for the First-time Use To set up the APOLLO 120/150 for the first-time use, you should have the following items ready. The items are either in the accessory box or available in any computer stores.

  • Page 28: Running The Bios Setup

    User Manual version 2305 2.2.2. Running the BIOS Setup If you are a commercial user, the APOLLO 120/150 III should have been properly set up and configured by your dealer. You may still find it necessary to change the system configuration information.

  • Page 29: Operating System And Driver Installation

    User Manual version 2305 2.2.3. Operating System and Driver Installation The APOLLO III system is not equipped with an operating system when delivered from the original manufacturer. If you are a commercial user, the system is likely to have been pre-installed proper operating system and software drivers by your dealer or system integrator.
  • Page 30 User Manual version 2305 3-20 APOLLO 120/150 III...
  • Page 31 User Manual version 2305 3. V & ERSATILE STANDING MOUNTING OPTIONS The APOLLO 120/150 is designed for universal standing and mounting to fit into various environmental applications. This chapter highlights the steps of different mounting options with graphical illustrations. Sections...

  • Page 32: Versatile Stand

    Compact in its size, all-in-one in its design along with its industrial-grade reliability, the APOLLO system standing upright is the best replacement for a desktop computer. When the APOLLO is to stand upright, the two base back covers can either be assembled or not to be assembled to the pedestal.

  • Page 33: Fixed Standing

    HINGE (¥ª ) with LOCK HINGE (¥k ) APOLLO 120/150 Âà ¶ b - × ¹ ¢ ¤ U » \ Âà ¶ b ¤ ä ¬ [ APOLLO 120/150 Âà ¶ b - × ¹ ¢ ¤ W » \ APOLLO 120/150 ¶ì...

  • Page 34: Cable Management

    User Manual version 2305 3.1.4. Cable Management The APOLLO’s pedestal is not only a versatile stand but a functional stand able to manage the system cabling. 1. The rectangle-shape opening (Fig. 3-2) at the bottom side of the big pedestal can act as a cable management cutout.

  • Page 35: Wall Mounting And Mobile Applications

    User Manual version 2305 3.2. Wall Mounting and Mobile Applications The APOLLO system provides 1 set of VESA mounting holes, 75*75mm on the rear side of the chassis. System integrators can design their special wall mount brackets per the two sets of VESA holes or obtain market-available swing arms for wall mounting, table mounting or mobile applications.
  • Page 36 User Manual version 2305 3-5: APOLLO 150 VESA IGURE HOLES IGURE IGURE 3-26 APOLLO 120/150 III...

  • Page 37: Panel Mounting

    User Manual version 2305 3.3. Panel Mounting The APOLLO system provides a set of optional mounting brackets for system panel mounting. The following figures illustrate the way to use the brackets for panel mounting. IGURE IGURE 3-27 APOLLO 120/150 III...

  • Page 38: Kiosk Integration

    The APOLLO system can also be integrated to a KIOSK cabinet to make a ready-to-play KIOSK terminal. The following is an example of APOLLO KIOSK. It is a flexible and robust device that can be mounted virtually anywhere and in any forms including tabletop, pedestal, pole and wall mounting.

  • Page 39: I/O Connection

    User Manual version 2305 4. I/O C ONNECTION This chapter describes the APOLLO system I/O ports and how to use the I/O interface to connect to external devices. 4-29 APOLLO 120/150 III...

  • Page 40: Parallel Port

    IGURE 4.1. Parallel Port The APOLLO 120/150 can support the latest EPP and ECP parallel port protocols. It can be used to connect to a wide array of printers, ZIP drive, parallel scanner and any other parallel devices.

  • Page 41: Com Ports

    User Manual version 2305 4.2. COM Ports x 4 The APOLLO 120/150 features with four onboard COM ports. COM 1, 2 & 4 are D-SUB serial ports located at the rear side of the chassis, ready to connect to a wide range of serial devices.
  • Page 42 COM1, 2 & COM4 are all D-SUB 9-pin connectors. To connect to any serial device; follow the procedures below; 1. Turn off the APOLLO system and the serial devices. 2. Attach the interface cable of the serial device to the 9-pin D-SUB serial connector.

  • Page 43: 100/10 Base

    Ethernet (RJ-45) interface. For network connection, follow the instructions below. 1. Turn of the APOLLO system and the Ethernet hubs. 2. Plug in one end of cable of a 100/10 Base-T hub to the system’s RJ-45 phone jack. The pin assignment of the RJ-45 is listed as follow;...

  • Page 44: When System Memory Clock = 66Mhz

    INDOWS INDOWS INDOWS The APOLLO itself is onboard with an AGP LCD/VGA controller. When dual display mode is activated, it can support a LCD panel (digital TTL) and a CRT or an analog monitor at either mirror mode or multiple-monitor mode.

  • Page 45: Single Display Mode

    16 43, 60, 70, 75, 85, 100, 120 60, 70, 75 32 43, 60, 70, 75 1280*1024 43, 60, 75, 85 16 43, 60, 75, 85 32 43 1600*1200 60, 65, 70, 75, 85 16 60 1920*1440 4-35 APOLLO 120/150 III...

  • Page 46: Mirror Display Output Mode

    60, 72, 75, 85, 100 800*600 56, 60, 72, 75, 85, 100, 60, 70, 75 120, 160 56, 60, 72, 75, 85, 100, 60, 70, 75 1024*768 43, 60, 70, 75, 85, 100, 60, 70, 75 4-36 APOLLO 120/150 III...

  • Page 47: Multiple Display Output Mode

    60, 70, 75 120, 160 56, 60, 72, 75, 85, 100, 60, 70, 75 56, 60 1024*768 43, 60, 70, 75, 85, 100, 60, 70, 75 43, 60, 70, 75 1280*1024 43, 60, 75, 85 1600*1200 60, 65 4-37 APOLLO 120/150 III...

  • Page 48: When System Memory Clock = 100Mhz

    43, 60, 70, 75, 85, 100, 120 60, 70, 75 43, 60, 70, 75, 85, 100 60, 70, 75 1280*1024 43, 60, 75, 85 43, 60, 75, 85 43, 60 1600*1200 60, 65, 70, 75, 85 60, 65, 70, 75, 85 1920*1440 4-38 APOLLO 120/150 III...

  • Page 49: Mirror Display Output Mode

    120, 160 56, 60, 72, 75, 85, 100, 60, 70, 75 120, 160 56, 60, 72, 75, 85 1024*768 43, 60, 70, 75, 85, 100, 60, 70, 75 43, 60, 70, 75, 85, 100, 60, 70, 75 4-39 APOLLO 120/150 III...

  • Page 50: Multiple Display Output Mode

    1024*768 43, 60, 70, 75, 85, 100, 60, 70, 75 43, 60, 70, 75, 85, 100, 60, 70, 75 43, 60 1280*1024 43, 60, 75, 85 43, 60, 75 1600*1200 60, 65, 70, 75, 85 1920*1440 4-40 APOLLO 120/150 III...

  • Page 51: When System Memory Clock = 133Mhz

    The following tables contain all graphic support modes under the following condition and are classified under three output modes (single mode, mirror mode and multiple-monitor mode). System memory clock = 133MHz Memory bus width = 64 bit Video memory size = 8MB or above 4-41 APOLLO 120/150 III...

  • Page 52: Single Display Mode

    85, 100, 120 1280*1024 43, 60, 75, 85 60 16 43, 60, 75, 85 60 32 43, 60, 75, 85 60 1600*1200 60, 65, 70, 75, 16 60, 65, 70, 75, 32 60 1920*1440 16 60 4-42 APOLLO 120/150 III...

  • Page 53: Mirror Display Output Mode

    56, 60, 72, 75, 85, 100, 60, 70, 75 120, 160 56, 60, 72, 75, 85, 100, 60, 70, 75 1024*768 43, 60, 70, 75, 85, 100, 60, 70, 75 43, 60, 70, 75, 85, 100, 60, 70, 75 4-43 APOLLO 120/150 III...

  • Page 54: Multiple Display Output Mode

    43, 60, 70, 75, 85, 100, 60, 70, 75 43, 60, 70, 75, 85, 100, 60, 70, 75 43, 60, 70, 75 1280*1024 43, 60, 75, 85 43, 60, 75, 85 1600*1200 60, 65, 70, 75, 85 60, 65 1920*1440 4-44 APOLLO 120/150 III...

  • Page 55: Ps/2 Keyboard Interface

    PS/2 KB to AT KB is needed. 4.7. PS/2 Mouse Interface The APOLLO system has one PS/2 mouse connector located at the rear side. A simple plug-in will make the connection. 4-45 APOLLO 120/150 III...

  • Page 56: External Fdd (Db-15)

    User Manual version 2305 4.8. External FDD (DB-15) The APOLLO 120/150 provides two ways to connect to a floppy disk drive to fit into specific environmental applications: 1. Internal FDD 2. External FDD If the FDD is frequently used, it is suggested to use an internal floppy disk drive.

  • Page 57: 12V Dc-Out

    The APOLLO system provides a +5V/12V DC-out connector. It is used to provide necessary power source for some external devices. For example, if the APOLLO III system is to be housed in a KIOSK cabinet which requests extra cooling fan for heat dispensing, then the fan power cable can be attached to 5V/12V DC-out to obtain power from the computer directly.

  • Page 58: Dio (Digital Input & Output)

    User Manual version 2305 4.11. DIO (Digital Input & Output) The APOLLO III provides 2-channel digital input and output that can be used for the system’s simple automation control needs. The digital I/O can be configured to control the opening of a cash drawer or to sense the warning signal of an uninterrupted power system (UPS) or to do the store security control.
  • Page 59 Out_Data 0~3 SD4~SD7 EXAMPLE: REM Digital I/O example program X = INP (&H208) REM INPUT Digital I/O port for 4 bit X = OUT (&H208) REM OUTPUT Digital I/O port for 4 bit 100 Return Port 208H Definition 4-49 APOLLO 120/150 III...

  • Page 60: Audio Interface (Line-In, Mic-In, Spk-Out)

    The IR KB sensor containing wireless KB firmware is located at the front bezel. To use the wireless keyboard, please note that the APOLLO III IrKB sensor on the front bezel and the wireless keyboard sensor have to face each other at the same horizontal level and the distance of the IR transceiver and receiver should not exceed 1 meter.

  • Page 61: Hardware Installation And Upgrade

    User Manual version 2305 HARDWARE INSTALLATION AND UPGRADE This chapter overviews the installation of the APOLLO III’s internal components and devices. This chapter is for service engineers not for the end user. Sections include: The exploded diagram Motherboard assembly Touchscreen controller...
  • Page 62 User Manual version 2305 ® The APOLLO 120/150 III consists of a Celeron/ Pentium multimedia motherboard with an adequate CPU and relevant SDRAM on it. The system control board and other internal devices such as expansion card, HDD and power supply are already housed in a plastic rear cover.

  • Page 63: Recognizing The System Major Parts

    User Manual version 2305 5.1. Recognizing the System Major Parts In terms of LCD size, the APOLLO has two models, one 12.1” and the other 15.1”. The assembly of the two models is basically the same except the LCD assembly. The following diagram highlights the system major parts that make up the APOLLO 120 main system.
  • Page 64 User Manual version 2305 The following diagram shows the system major parts that make up the APOLLO 150 main system. APOLLO 150 ¥D Å é ² Õ « ~ APOLLO 150 -± ª O ² Õ « ~ APOLLO 150 LCD²Õ « ~ CDROM-FDD²Õ...

  • Page 65: Installing The Cpu

    User Manual version 2305 5.2. Installing the CPU The APOLLO III can adapt Socket 370 Intel Celeron Pentium III CPU. Upgrading the CPU can increase the system performance. When Pentium III 1GB 133MHz is used with the system, it is suggested to attach another system cooling fan at the right side of the system compartment to prevent the system from overheating.

  • Page 66: Nstalling The Sdram M Emory M Odule

    User Manual version 2305 5.3. Installing the SDRAM Memory Module The APOLLO 120/150 III system control board provides 1 x 168-pin DIMM socket, able to support SDRAM memory from 32MB up to 512MB. To install the memory module, follow the instructions below.

  • Page 67: Motherboard Assembly

    5. The IR/LED 2*13-pin cable (Fig. 5-7 (7) & Fig. 5-8 (5)) has to go through the rectangle opening located at the bottom side of the chassis, then connected to motherboard’s J9, the HDD LED & ACPI LED & SMI connector. 5-57 APOLLO 120/150 III...

  • Page 68: Touch Controller Assembly

    4. Fix the touchscreen controller (13) to the bracket with 2 PMS 3*6 screws. 5. Fold both cables properly. 6. Make sure the two screws at the outward upper side of the chassis are also properly fixed. 5-58 APOLLO 120/150 III...

  • Page 69: Assembly

    User Manual version 2305 5.6. HDD Module Assembly The APOLLO provides enough space to build in a 3.5” hard disk drive in the system compartment. The following steps show the way to install an internal hard disk drive. 1. Make the chassis lower side near you. Now, from your point of view, the 3.5"...

  • Page 70: T Ouchscreen Or F Ront B Ezel A Ssembly

    User Manual version 2305 5.7. Touchscreen or Front Bezel Assembly The APOLLO is able to accommodate Elo analog resistive touch or Intelli (SAW) touch or MicroTocu capacitive touchscreen. LEASE NOTE THAT WHEN DIFFERENT TOUCH MODULE IS INSTALLED DIFFERENT TOUCHSCREEN METAL BRACKETS ARE NEEDED...
  • Page 71 User Manual version 2305 APOLLO 120 -± ª O ² Õ « ~ 12" -± ª O ² Õ ¥ ó 12" ¾ó ½ ¦ À £ ± ø ( ¥ª ¥ k ) 12" ¾ó ½ ¦ À £ ± ø ( ¤W ¤ U ) 12.1"ELO TOUCH ¹q ª...

  • Page 72: Lcd Module Assembly

    The invertor module is to be fixed at the right middle side of the LCD holder with the up side down. For APOLLO 120, the IR/LED board (2) is to be fixed to the lower side of the LCD holder.
  • Page 73 Attach the insulator (6) to the invertor (7). The invertor cable (8) for APOLLO 150 is a 7-pin to 4-pin cable with wafer connectors at both sides. Connect the 7-pin end to the invertor first. The other end is for later...
  • Page 74 LCD holder after the LCD module is to be installed to the system. 12. For APOLLO 150, fix 6 bronze sticks (15 mm) to the lower sides of the LCD holder. Fix the IR/LED board to the LCD holder with two 3*6 screws.
  • Page 75 12" LCD ²Õ « ~ 12.1"LCD PANEL 12"LCD©T © w ¬ [¤U 12"LCD ©T © w ¬ [¤W LCD CABLE DFP41-50P 330mm MODULE APOLLO LED A1.0 SPEAKER LED CABLE 120mm 12"INVERTER MOLEX P-HRS4P 220mm INVERTER 12.1"TORISAN 12"INVERTERµ´ ½ t¤ù 1 20*26.7*0.35 12"«e Å...
  • Page 76 Connect the other end of the touch power cable to the onboard PWR 1. 5. For APOLLO 150, the invertor now is to be fixed to the left outward side of the chassis and have the invertor cable go into the chassis through the cutout.

  • Page 77: Cd-Rom/Dvd-Rom/Fdd Module Assembly

    The APOLLO provides enough space to accommodate a CD-ROM or CD-RW or DVD-ROM and a floppy disk drive. The CD-ROM or DVD-ROM drive used in the APOLLO 120/150 is not the common 5.25” drive seen in computer stores. Rather, it is a slim type drive widely used in notebook computers.

  • Page 78: The Motherboard

    CDROM ¶¡ ¹ j ¬ W 2 .5mm MODULE CDROM-FDD CDROM CABLE 150mm SOUND CABLE P/H 2.54 120mm slim FDD FDD ³n ± Æ 2 6pin 130mm ºÏ ¾ ÷ ¬ [ RISER B 5-10: CD-ROM/FDD IGURE MODULE ASSEMBLY 5-68 APOLLO 120/150 III...

  • Page 79: External Fdd Connection

    3. To drive the floppy disk drive, it will need 5V power. Connect the provided FDD power cable to the floppy disk drive to the +5V/12V DC-out connector to obtain 5V power for the device. 5-69 APOLLO 120/150 III...

  • Page 80: Power Module Assembly

    6. Connect the big 4P end of the power cable to the HDD. 7. Connect the small 4P end the CD-ROM board. 8. The power module is to be installed to the system right on the top of the CD-ROM/FDD module. 5-70 APOLLO 120/150 III...
  • Page 81 §ù ¨ ¹ S OFT SWITCH 120mm POWER©T © w ¬ [ ª þ ¥ ó - 1(AC-AC) The power cable coming out from the cutout and connected to the MB’s ATX power connector. 5-11: APOLLO AC P IGURE OWER MODULE 5-71 APOLLO 120/150 III...

  • Page 82: Expansion Outlets & Riser Card Assembly

    User Manual version 2305 5.11. Expansion Outlets & Riser Card Assembly The APOLLO 120/150 provides PCI/ISA expansion slots for system expansion. Via the specially designed riser card, the system can accommodate either two PCI or one PCI plus one ISA expansion cards; all the connectors of the expansion card will come out from the expansion outlet on the left side of the chassis for further cable connection.

  • Page 83: Back Panel Assembly

    6. Fix the back panel module to the main system. 7. Fix a stand bracket at the bottom side of the chassis with 2 screws. APOLLO ÅK ¥ ó « á » \ ² Õ « ~ ÅK ¥ ó « á » \ I/O »\ MODULE APOLLO IO A1.0...

  • Page 84: Stand Module Assembly

    HINGE (¥ª ) with LOCK HINGE (¥k ) APOLLO 120/150 Âà ¶ b - × ¹ ¢ ¤ U » \ Âà ¶ b ¤ ä ¬ [ APOLLO 120/150 Âà ¶ b - × ¹ ¢ ¤ W » \ APOLLO 120/150 ¶ì...
  • Page 85 °ò ® y ² Õ « ~ ¥D Å é ² Õ « ~ APOLLO 120/150 ©³ ® y - × ¹ ¢ ¤ W » \ APOLLO 120/150 ©³ ® y - × ¹ ¢ ¤ U » \...
  • Page 86 User Manual version 2305 5-76 APOLLO 120/150 III...

  • Page 87: System Motherboard & I/O Board

    User Manual version 2305 6. S & I/O B YSTEM MOTHERBOARD OARD The system controller used in the APOLLO III ® system is a special-design Celeron/Pentium multimedia motherboard. All the onboard signal is connected to an I/O board via 2 SCSI cables for external device connection.

  • Page 88: Apollo Iii Motherboard

    User Manual version 2305 6.1. APOLLO III Motherboard This section provides background information and detail specification on the APOLLO 120/150 III system engine, PC 610. Sections include: General Information ² Features ² Specification ² Board placement & Dimension ² 6.1.1. General Information...

  • Page 89: Specifications

    PS/2 Keyboard Interface x 1 Internal Keyboard Interface x 1 PS/2 Mouse Interface x 1 USB Interface x 4 supporting USB 1.0 devices u IrDA: 5-pin header with CIR support u Ethernet 100/10 Base-T Ethernet Support WAKE-ON-LAN 6-79 APOLLO 120/150 III...

  • Page 90: Audio Function

    Read back capability that displays temperature, voltage and fan speed Supporting Intel processor thermal diode output (real processor temperature) u Expansion Bus: PCI/ISA x 1 u Power: ATX power Dimension: 300*146 mm (L*W) Specifications are subject to change without notice. 6-80 APOLLO 120/150 III...

  • Page 91: Locating Jumpers & Connectors

    User Manual version 2305 6.1.3. Locating Jumpers & Connectors The following figure helps you to locate the jumpers and connectors on the motherboard. 6-81 APOLLO 120/150 III...

  • Page 92: Jumpers & Jumper Setting

    The table below lists the function of each jumper. The related jumper settings are shown in the coming sections. Jumper Description DOC Address Selection Clear CMOS COM2 RS-232/422/485 selection COM2 RS-232/422/485 selection COM2 RS-232/422/485 selection COM2 RS-232/422/485 selection COM2 RS-232/422/485 selection JP10 COM2 RS-232/422/485 selection 6-82 APOLLO 120/150 III...

  • Page 93: Doc 2000 Address Setting (Jp1)

    6.1.4.2. Clear CMOS (JP2) Clear CMOS Normal 6.1.4.3. COM 2 232/422/485 Setting (JP5,6,7,8,9 & 10) COM 2 is a RS-232/422/485 serial port. JP5, 6, 7, 8, 9 and JP10 determine the specific port type. RS-232 RS-422 RS-485 JP10 6-83 APOLLO 120/150 III...

  • Page 94: Connectors & Pin Assignment

    I/O Connector FAN1 CPU FAN Connector FAN2 System FAN Connector ATX Power ON/OFF LCD Connector INV1 LCD Inverter connector FDD1 FDD connector IDE1 Primary IDE connector IDE2 Primary IDE connector COM3 Serial Port 3 (For Touch Screen) 6-84 APOLLO 120/150 III...
  • Page 95 Find the proper orientation and push down the power connector firmly to make sure the pins are aligned. Its pin assignments are listed below: Pin # Signal Pin # Signal 3.3V 3.3V 3.3V -12V PSON# PWROK SB5V +12V 6-85 APOLLO 120/150 III...

  • Page 96: J2: Cd Audio In

    6.1.5.3. J7: HDD LED & ACPI LED & SMI Pin # Signal HDD LED+ HDD LED- ACPI LED+ ACPI LED- 6.1.5.4. J8: IR / CIR Connector Pin # Signal Pin # Signal CIRRX IRRX 5V (CIR) IRTX 6-86 APOLLO 120/150 III...

  • Page 97: J9: Power Led & Kb

    6.1.5.6. SW1: ATX Power ON/OFF & Reset Pin # Signal Power ON/OFF 6.1.5.7. COM3 COM 3 is an internal RS-232 reserved for touchscreen. Its corresponding pin assignment is listed as below; Pin # Signal Pin # Signal 6-87 APOLLO 120/150 III...

  • Page 98: Lcd1: Lcd Connector

    P12 (G4) P13 (G5) P14 (G6) P15 (G7) P16 (R0) P17 (R1) P18 (R2) P19 (R3) P20 (R4) P21 (R5) P22 (R6) P23 (R7) SHFCLK DE / M VBCTL1 VBCLK SSYNC VBHCLK ENVB PCIRST# ENEXTPLK INTA# 6-88 APOLLO 120/150 III...

  • Page 99: Inv1: Lcd Inverter Connector

    User Manual version 2305 6.1.5.9. INV1: LCD Inverter Connector Pin # Signal Backlight ADJ Backlight Enable 6.1.5.10. FDD1: FDD connector Pin # Signal Pin # Signal INDEX# DSA# DSKCHG# MOA# DIR# RWC# STEP# TRAK0# RDATA# HEAD# 6-89 APOLLO 120/150 III...

  • Page 100: Ide1/Ide2: Primary/Secondary Hdd

    DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA10 DATA 4 DATA11 DATA 3 DATA12 DATA 2 DATA13 DATA 1 DATA14 DATA 0 DATA15 IDEREQ IOW# IOR# ICHRDY# DACK IDEIRQ IDECS0 IDECS1 HDD LED 6-90 APOLLO 120/150 III...
  • Page 101 SOUTB AFD# SLCT CTSB DSRB BUSY SINB DCDB IN 0 IN 1 RTSD IN 2 DTRD IN 3 SOUTD OUT 0 OUT 1 CTSD OUT 2 DSRD OUT 3 SIND DCDD +12V +12V +12V +12V +12V 6-91 APOLLO 120/150 III...

  • Page 102: Scsi 2: Kb/Ms/Vga/Lan Usb/Fdd

    UV1- BLUE DDCCLK DDCDATA RWC# INDEX# MOA# DSA# DIR# LINE IN _R STEP# LINE IN_L HP_R TRAK0# HP_L RDATA# HEAD# DSKCHG# KBDATA KBCLK BACK LIGHT MSDATA MSCLK VCC3 SB5V VCC3 SB5V VCC3 SB5V VCC3 SB5V SB5V 6-92 APOLLO 120/150 III...

  • Page 103: Cn4: Pci/Isa Expansion Slot

    User Manual version 2305 6.1.5.14. CN4: PCI/ISA Expansion Slot The PC 610 provides an ISA/PCI slot for ISA and PCI device expansion. CN4: PCI/ISA Slot Side 6-93 APOLLO 120/150 III...
  • Page 104 E24 NC A24 SA7 F25 KEY B25 IRQ3 E25 KEY A25 SA6 F26 NC B26 DACK2 E26 NC A26 SA5 F27 AD17 B27 TC E27 AD16 A27 SA4 F28 IRDY B28 ALE E28 FRAME A28 SA3 6-94 APOLLO 120/150 III...
  • Page 105 D14 DACK7 G14 AD2 SD11 H15 KEY D15 DRQ7 G15 KEY SD12 H16 V D16 V G16 V SD13 H17 V D17 MASTER G17 V SD14 H18 GND D18 GND G18 GND SD15 H19 GND G19 GND 6-95 APOLLO 120/150 III...

  • Page 106: Locating Jumpers & Connectors

    User Manual version 2305 6.2. APOLLO III I/O Board All the onboard I/O signal of the APOLLO motherboard is connected to an I/O board via 2 SCSI cables for external device connection. This section provides jumper definition and connector signal of the I/O board.

  • Page 107: Jumpers & Jumper Setting

    COM2 Pin 9 power selection COM4 Pin 9 power selection 6.2.2.1. JP1: Keyboard Power Select SB5V 6.2.2.2. COM port Power Selection JP1: COM1 Pin 9 Power selection JP2: COM2 Pin 9 Power selection JP4: COM4 Pin 9 Power selection 6-97 APOLLO 120/150 III...

  • Page 108: Connectors & Pin Assignment

    CRT Display Connector FDD1 External FDD Connector USB1 USB Connector 1 USB2 USB Connector 2 DIO1 Digital I/O Connector LAN1 Ethernet Connector MIC1 Microphone In Connector LINE1 Line In Connector SPK1 Speaker Output Connector LCD Backlight Control 6-98 APOLLO 120/150 III...

  • Page 109: Kb1: Ps/2 Keyboard Connector

    User Manual version 2305 6.2.3.1. KB1: PS/2 Keyboard Connector Pin # Signal KBDATA SB5V KBCLK 6.2.3.2. KBMS: PS/2 Mouse Pin # Signal MSDATA MSCLK 6.2.3.3. COM1, COM2, COM4: DB-9 Pin # Signal Pin # Signal RI (+5V/12V) 6-99 APOLLO 120/150 III...

  • Page 110: Cn1: Dc Power Output

    DATA 2 SLINT# DATA 3 DATA 4 DATA 5 DATA 6 DATA 7 ACK# BUSY SLCT 6.2.3.6. CRT1: VGA (D-SUB 15 Pin) Pin # Signal Pin # Signal Pin # Signal Green DDCDATA Blue Hsync Vsync DDCCLK 6-100 APOLLO 120/150 III...

  • Page 111: Fdd1: External Fdd Connector

    Pin # Signal Pin # Signal USBVCC USBVCC Data- Data- Data+ Data+ 6.2.3.9. DIO1: RJ-11 Connector Pin # Signal Pin # Signal +12V IN_0 IN_1 OUT_0 OUT_1 6.2.3.10. LAN1: RJ-45 Ethernet Connector Pin # Signal Pin # Signal 6-101 APOLLO 120/150 III...

  • Page 112: Mic1

    User Manual version 2305 6.2.3.11. MIC1 Pin # Signal Vref MIC IN 6.2.3.12. LINE 1 Pin # Signal Right CHI Left CH 6.2.3.13. SPK 1 Pin # Signal Right CHI Left CH 6-102 APOLLO 120/150 III...
  • Page 113 SOUTB AFD# SLCT CTSB DSRB BUSY SINB DCDB IN 0 IN 1 RTSD IN 2 DTRD IN 3 SOUTD OUT 0 OUT 1 CTSD OUT 2 DSRD OUT 3 SIND DCDD +12V +12V +12V +12V +12V 6-103 APOLLO 120/150 III...

  • Page 114: Scsi 2: Kb/Ms/Vga/Lan Usb/Fdd

    UV1- BLUE DDCCLK DDCDATA RWC# INDEX# MOA# DSA# DIR# LINE IN _R STEP# LINE IN_L HP_R TRAK0# HP_L RDATA# HEAD# DSKCHG# KBDATA KBCLK BACK LIGHT MSDATA MSCLK VCC3 SB5V VCC3 SB5V VCC3 SB5V VCC3 SB5V SB5V 6-104 APOLLO 120/150 III...

  • Page 115: Award Bios Setup

    User Manual version 2305 7. A BIOS S WARD ETUP The chapter describes how to set up BIOS configuration. 7-105 APOLLO 120/150 III...

  • Page 116: Award Bios

    (POST). If any error or mismatch occurs, an error message will be shown on the screen and the computer will be prompted to run the setup program. 7-106 APOLLO 120/150 III...

  • Page 117: Control Key Definition

    Load the default CMOS value from BIOS default table, only for Option Page Setup Menu F7 key Load the default F8 key Reserved F9 key Reserved F10 key Save all the CMOS changes, only for Main Menu 7-107 APOLLO 120/150 III...

  • Page 118: Getting Help

    Esc : Quit F9 : Menu in BIOS Select Item F10: Save & Exit Setup Time, Date, Hard Disk Type … Use the arrow keys to move among the items and press <Enter> to enter the sub-menu. 7-108 APOLLO 120/150 III...

  • Page 119: Etup

    Setup, or just to Setup. & : Save CMOS value settings to CMOS EXIT SETUP and exit setup. : Abandon all CMOS value changes XIT WITHOUT SAVING and exit setup. 7-109 APOLLO 120/150 III...

  • Page 120: Standard Cmos Features

    Full Screen Function (Disable) Halt On (All, But Keyboard) Base Memory 640K Extended Memory 64448K Total Memory 65536K Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 7-110 APOLLO 120/150 III...
  • Page 121 CYLS. Number of cylinders HEADS number of heads PRECOMP write precomp LANDZONE Landing zone SECTORS number of sectors If a hard disk has not been installed select NONE and press <Enter>. 7-111 APOLLO 120/150 III...
  • Page 122 The system boot will not stop for a disk error; it will stop for all other errors All, But Disk/Key The system boot will not stop for a keyboard or disk error; it will stop for all other errors 7-112 APOLLO 120/150 III...

  • Page 123: Advanced Bios Features

    OS Select For DRAM > 64MB (Non-OS2) Report NO FDD for Win 95 (No) Video BIOS Shadow (Enabled) Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 7-113 APOLLO 120/150 III...
  • Page 124 This number may be used for verification in Internet transactions and e-commerce. If you prefer not to use or distribute the unique processor number, use this item to suppress the processor number. The choice: Enabled & Disabled. 7-114 APOLLO 120/150 III...
  • Page 125 Normal A pin in the keyboard controller controls GateA20 Fast Lets chipset control GateA20 YPEMATIC ETTING Key strokes repeat at a rate determined by the keyboard controller. When enabled, the typematic rate and typematic delay can be selected. The choice: Enabled & Disabled. 7-115 APOLLO 120/150 III...
  • Page 126 Whether report no FDD for Win 95 or not. The choice: Yes & No. BIOS S IDEO HADOW This item allows the video BIOS to be copied to system memory for faster performance. The choice: Enabled & Disabled. 7-116 APOLLO 120/150 III...

  • Page 127: Advanced Chipset Features

    Concurrent function (PCI) (Enabled) CPU Pipeline Control (Enabled) PCI Delay Transaction (Enabled) Memory Parity Check (Enabled) Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 7-117 APOLLO 120/150 III...
  • Page 128 When select 'Delay 1T', background commands are issued 1 clock behind memory address (MA) been issued. When select 'Normal', background command and MA are issued at the same time. The choice: Delay 1T or Normal. 7-118 APOLLO 120/150 III...
  • Page 129 CKE is driven out. The Choice: 1ns, 2ns, 3ns, 4ns, 5ns, 6ns, 7ns, 8ns. OMMAND UTPUT This item is to control the timing to drive memory command onto memory bus. The choice: Normal, Delay 1T. 7-119 APOLLO 120/150 III...
  • Page 130 ONTROL This item controls the phase of EGMRCLK that lags behind SDCLK. The choice: -1.0ns~+6.5ns (Default 0.0ns) EGMWCLK C ONTROL This item controls the phase of EGMWCLK that lags ahead SDCLK. The choice: +5.0ns~-2.5ns (Default 0.0ns) 7-120 APOLLO 120/150 III...
  • Page 131 AGP without any translation. The Choice: 4M, 8M, 16M, 32M, 64M, 128M, 256M WR C RAPHIC INDOW OMBIN Use this item to enable or disable CPU support for WR Combin. The choice: Enabled or Disabled. 7-121 APOLLO 120/150 III...
  • Page 132 PCI Ver.2.1 specifications. We recommend that you leave this item at the default value. The choice: Enabled or Disabled. EMORY ARITY HECK Enabled this item to test the boot-up memory. . The choice: Enabled or Disabled. 7-122 APOLLO 120/150 III...

  • Page 133: Integrated Peripherals

    (2E8) Serial Port 4 Use IRQ (IRQ 11) Init Display First (PCI slot) Fast Write Capability (Enabled) AGP 4X Capability (Enabled) AGP Auto Calibration (Enabled) System Share Memory… … … … … (8MB) Extended Graphic Memory 7-123 APOLLO 120/150 III...
  • Page 134 If you are getting disk drive errors, try setting this value to Disabled. This field does not appear when the Internal PCI/IDE field, above, is Disabled. The choice: Enabled or Disabled. 7-124 APOLLO 120/150 III...
  • Page 135 This item allows you to select the IR half/full duplex funcion. The choice: Half or Full. NBOARD ARALLEL This item allows you to determine access onboard parallel port controller with which I/O address. The choice: 3BC/IRQ7, 378/IRQ7, 278/IRQ5, Disabled. 7-125 APOLLO 120/150 III...
  • Page 136 This item allows you to decide to active which bus first (PCI Slot or AGP first). The choice: PCI Slot or, AGP. YSTEM HARE EMORY This item defines the System Share Memory Size for video. The choice: 2MB, 4MB, 8MB, 16MB, 32MB, 64MB 7-126 APOLLO 120/150 III...

  • Page 137: Power Management Setup

    (Instant Off) Power Status Resume Control (Always Off) Ø PM Wake Up Event (Press Enter) Move Enter : Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 7-127 APOLLO 120/150 III...
  • Page 138 Suspend --> Monitor blanked when the systems enters the Suspend mode. Susp,Stby --> Monitor blanked when the system enters either Suspend or Standby modes. All Modes --> Monitor blanked when the system enters any power saving mode. 7-128 APOLLO 120/150 III...
  • Page 139 Suspend mode. OWER UTTON You could press the power button for more than 4 seconds forces the system to enter the Soft-Off state when the system has “hung.” The choice: Soft-Off, Delay 4 Sec. 7-129 APOLLO 120/150 III...
  • Page 140 Date (of Month) Alarm lets you select a day from 1 to 31 . Time Alarm lets you select a time for the alarm in hours , minutes , and seconds . The choice: Enabled or Disabled. 7-130 APOLLO 120/150 III...

  • Page 141: Pnp/Pci Configuration

    OS cannot boot Move Enter : Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 7-131 APOLLO 120/150 III...
  • Page 142 PCI/ISA PnP for devices compliant with the Plug and Play standard whether designed for PCI or ISA bus architecture. The Choice: Legacy ISA and PCI/ISA PnP. PCI/VGA P ALETTE NOOP Leave this field at Disabled. The choice: Enabled or Disabled. 7-132 APOLLO 120/150 III...

  • Page 143: Pc Health Status

    +12 V - 12 V - 5 V VBAT (V) 5VSB (V) Shutdown Temperature (Disabled) Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 7-133 APOLLO 120/150 III...

  • Page 144: Frequency Voltage Control

    Auto Detect DIMM/PCI Clk (Enabled) Item Help Spread Spectrum (Disabled) Menu Level CPU Host/SDRAM/PCI Clock (Default) Move Enter : Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults 7-134 APOLLO 120/150 III...
  • Page 145 This item allows you to enable/disable the spread spectrum modulate. The choice: Enabled or Disabled. CPU H /DRAM/PCI C LOCK This item allows you to select CPU/PCI frequency. The choice: Auto Detect, 66/66/33MHz, 66/100/33MHz, 100/100/33MHz, 100/133/33MHz, 133/100/33MHz, 133/133/33MHz 7-135 APOLLO 120/150 III...

  • Page 146: Load Fail-Safe Defaults

    Power Management Setup Ø Exit Without Saving Load Fail-Safe Defaults (Y/N) ? N PnP/PCI Configuration Ø PC Health Status Ø Esc : Quit F9 : Menu in BIOS Select Item F10: Save & Exit Setup Load Fail-Safe Defaults 7-136 APOLLO 120/150 III...

  • Page 147: Load Optimized Defaults

    Power Management Setup Ø Exit Without Saving Load Optimized Defaults (Y/N) ? N PnP/PCI Configuration Ø PC Health Status Ø Esc : Quit F9 : Menu in BIOS Select Item F10: Save & Exit Setup Load Optimized Defaults 7-137 APOLLO 120/150 III...

  • Page 148: User Password

    The new password will be stored in the CMOS. Please note that to enable this option, either Setup or System is to be selected from the ADVANCED BIOS FEATRUES first. 7-138 APOLLO 120/150 III...

  • Page 149: Save And Exit Setup

    Exit Without Saving PnP/PCI Configuration Ø Save to CMOS and Exit (Y/N) ? Y PC Health Status Ø Esc : Quit F9 : Menu in BIOS Select Item F10: Save & Exit Setup Save Data to CMOS 7-139 APOLLO 120/150 III...

  • Page 150: Exit Without Saving

    Quit Without Saving Exit Without Saving PnP/PCI Configuration Ø Quit without Saving (Y/N) ? N PC Health Status Ø Esc : Quit F9 : Menu in BIOS Select Item F10: Save & Exit Setup Abandon All Data 7-140 APOLLO 120/150 III...

  • Page 151: Software & Drivers Installation

    User Manual version 2305 8. S & D OFTWARE RIVERS INSTALLATION The chapter introduces the PC 610 onboard VGA, Ethernet, Audio and the respective drivers and installation. 8-141 APOLLO 120/150 III...

  • Page 152: Ethernet Drivers

    SiS630ST Ethernet drivers for Windows 95/95OSR2 ² Windows 98/98SE ² Windows 2000 ² Windows ME ² Windows NT 4.0 ² Windows XP ² For the Ethernet drivers, please download the updated drivers from the following website http://www.sis.com.tw 8-142 APOLLO 120/150 III...

  • Page 153: Pc 610 Agp Xga

    PC 610 also provides an interface for digital flat panels. The PC 610 XGA driver diskettes contain the following drivers; SiS630ST VGA drivers for Windows 9x ² Windows 2000/XP ² For the VGA drivers, please download the updated drivers from the following website http://www.sis.com.tw 8-143 APOLLO 120/150 III...

  • Page 154: Audio Setup

    SiS630ST audio drivers for ² Windows NT 4.0 ² Windows 2000 ² Windows 95/98 ² Windows 98SE ² Windows ME ² Windows XP ² For the audio drivers, please download the updated drivers from the following website http://www.sis.com.tw 8-144 APOLLO 120/150 III...

  • Page 155: Touchscreen Drivers

    User Manual version 2305 8.4. Touchscreen Drivers The panel PC audio driver diskette contains the following drivers; 3M resistive touch drivers ² 3M capacitive touch drivers ² Elo resistive/SAW touch driver ² E-turbo touch drivers ² 8-145 APOLLO 120/150 III...

  • Page 156: Driver Installation

    Please refer to the readme.txt file under each directory for more drivers’ information. Recent releases of operating systems always include setup programs that load automatically and guide you through the installation. 8-146 APOLLO 120/150 III...

  • Page 157: S Pecifications

    Appendix A: LCD Specification A-1. APOLLO 120 LCD The standard display used for the APOLLO 120 is a TORISAN 12.1” TFT active matrix color liquid display (LCD) module; its model no. is MXS121022010 or its equivalent. It composes of LCD panel, driver ICs, control circuit and backlight. By applying 6 bit digital data, 800x600, 260K-color images are displayed on the 12.1”...
  • Page 158 User Manual version 2305 A-2. T APOLLO 150 S FOR The standard display used for the APOLLO 150 is either LG 15.1” TFT LCD, LM151X2 or its equivalent or a Chi Mei 15” TFT LCD, M150X3-L01 or its equivalent. A-2-1: 15.1” LG LM151X2 The LM151X2 is a TTL interface 15.1”...
  • Page 159 A-2-2-2. M ECHANICAL PECIFICATION Item Min. Typ. Max. Unit Horizontal (H) 331.6 Module Size Vertical (V) 254.76 Depth (D) 13.0 Weight (1,350) A-2-2-3. A BSOLUTE AXIMUM ATINGS Item Symbol Value Unit Min. Max. Power Supply Voltage 8-149 APOLLO 120/150 III...

  • Page 160: B: Diskonchip Installation

    User Manual version 2305 B: DiskOnChip Installation The APOLLO 120/150 III is equipped with an internal flash disk which can emulate a floppy disk drive by adapting DiskOnChip memory chips from 2MB to 144MB capacity, and the flash disk is fully compatible with floppy disk format of MS-DOS system.
  • Page 161 380-38F SDLC, bisynchronous 2 (not used) 3A0-3AF Bisynchronous 1 (not used) 3B0-3BF Monochrome display and printer adapter (LPT1) (not used) 3C0-3CF Reserved 3D0-3DF Color/graphics monitor adapter Serial port #3 3F0-3F7 Diskette controller 3F8-3FF Serial port #1 8-151 APOLLO 120/150 III...

  • Page 162: C: Wake-On-Lan

    ATX power supply meeting 2.01 with at least 720mA standby current is also required to support the Ethernet card for this function. The APOLLO is a panel PC system with these two features. To use the APOLLO Wake-On-LAN function, please refer to the following;...
  • Page 163 The remote computer can be waken up by selecting the M AGIC ¢ @ P as shown below. ACKETS OWER Do not change the IP B . The D ROADCAST DDRESS ESTINATION is to be filled in with the Ethernet card’s THERNET DDRESS MAC address. 8-153 APOLLO 120/150 III...
  • Page 164 The adapter address is the LAN card’s MAC address. 4. After obtaining all the above information, the remote computer can be powered on now. Now you can use Desktop On Call or other remote software to control the remote computer. 8-154 APOLLO 120/150 III...

  • Page 165: D: First Mb Memory Map

    User Manual version 2305 D: First MB Memory Map Address range (Hex) Device F000h-FFFFh System ROM CC00h-EFFFh Unused C000h-CBFFh Expansion ROM B800h-BFFFh CGA/EGA/VGA text B000h-B7FFh Unused A000h-AFFFh EGA/VGA graphics 0000h-9FFFh Base memory D000-D7FFH DiskOnChip (Default) 8-155 APOLLO 120/150 III...

  • Page 166: E: Power Supply

    DC power supply. E-1: AC P OWER SUPPLY The AC power supply used in the APOLLO 120/150 III system is a 150 watts 1U ATX power supply. It is a dual output switching power supply specially designed for the APOLLO III system.
  • Page 167 Ripple & 100mV 100mV 150mV 200mV 200mV 100mV noise Regulation Output 0.5A 7A 12A 14A 0.5A 5A 0A 0.2A 0A 1A rating Dimension (unit: mm) ² 180 x 100 x 40.5 (L x W x H) 8-157 APOLLO 120/150 III...
