Dynasty Scan DMX
Unpacking:
Thank you for purchasing the Dynasty Scan DMX by
American DJ
. Every Dynasty Scan DMX has been thoroughly tested
®
and has been shipped in perfect operating condition. Carefully check
the shipping carton for damage that may have occurred during ship-
ping. If the carton appears to be damaged, carefully inspect your fix-
ture for any damage and be sure all equipment necessary to operate
the unit has arrived intact. In the event damage has been found or parts
are missing, please contact our toll free customer support number for
further instructions. Please do not return this unit to your dealer with-
out contacting customer support first.
Introduction:
The Dynasty Scan DMX is a six channel, intelligent
DMX scanner. The fixture can operate in three different operating
modes; stand alone, sound-active, or in a Master/Slave configuration.
The Dynasty Scan DMX is best used in multiples of four. When used
as a stand alone unit or when used in multiples linked in a master/
slave configuration. For best results use fog or special effects smoke
to enhance the beams projections.
During the initial start-up or use of this product a light smoke or
smell may arise from the unit. This is a normal process and is
cause by the heat associated with the lamp.
Customer Support:
American DJ
support line, to provide help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to 5:
00 p.m. Pacific Standard Time.
Voice:
(800) 322-6337
Fax:
(323) 582-2941
E-mail:
support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Warning!
This may cause severe eye damage. Avoid looking directly
into the light source at all times!
American DJ
- www.americandj.com - Dynasty Scan DMX Instruction Manual Page 2
®
