Appendix B
Link Distance
Maximum distance between devices connected through
DFE-853 or DFE-854 transceivers are as follows. For further help,
please contact the establishment from which you purchased your
transceiver.
Network Devices with DFE-853 Transceivers
Switch-Switch
Switch-Hub(Including Switch-Uplink Port)
Hub(Class II repeater)-Hub(Class II repeater) 5M
Network Devices with DFE-854 Transceivers
Switch-Switch
Switch-Class I Hub
Switch-Class II Hub
Hub(Class II repeater)-Hub(Class II repeater) 16.2M
Maximum
Distance
100M(HDX/FDX)
100M(HDX/FDX)
Maximum
Distance
2Km(FDX),
412M(HDX)
160.8M(HDX)
208.8M(HDX)
