- Page 1 NetMaster Network NK100, NK101 and NK120 Part No. 505942R1 www.comlaundry.com September 2001...
-
Page 3: Table Of Contents
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. 505942 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... - Page 4 505942 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
-
Page 5: Getting Started
Alliance Laundry For 124 to 249 machines or greater than 4,000 feet of network length NOTE: Have a computer specialist install the network board into the PC. 505942 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 6: Netmaster Coin Network Adaptable Store Sample Order
Accessories Obtained from Local Electronic Supply Store Qty Description Comments Twisted Pair Wire, 18 AWG tinned copper Connects networked machines and PC. Computer Wire Cutters/Stripper and a Small Screwdriver © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 505942... -
Page 7: Netmaster Cardmate Networked Adaptable Store Sample Order
CVC/PRK/PAPER Thermal Roll Paper Kit For CVC printer (6 rolls). **Alliance Laundry Systems suggests having at least 2 Card Add Valve Stations. The type and quantity of Card Add Valve Stations would depend on preferences of the store owner. 505942... -
Page 8: Netmaster Cardmate Networked Store Sample Order
Can be used to colect date, program or diagnostics (network replaces). NK120 Repeater Used to network store with 125-249 units. PC Anywhere Connects your home computer to your store computer. Bought at local store. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 505942... -
Page 9: Accessories Obtained From Local Electronic Supply Store
*The type of network card ordered would depend on the type of computer the store owner is using. These cards need to be installed by a professional. **Alliance Laundry Systems suggests having at least 2 Card Add Valve Stations. The type and quantity if Card Add Valve Stations would depend on preferences of the store owner. - Page 10 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 505942...
-
Page 11: Installation
The other 560 1/4 Watt resistor (red from 1, black from 2). Refer to Figure 6. connects between the black and green wires of the network cable. 505942 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 12: Connecting The Machines To The Pc And Each Other
WHITE CONNECTOR (210099) SINGLE UNITS TERMINAL STRIP GREEN R / S BLACK COM1201N Figure 3 STACKED UNITS CONTROL3a Figure 4 NOTE: Stacked units will have two connectors. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 505942... - Page 13 Ohm, 1/2 Watt terminating resistor should be placed in slots 4 and 5 to terminate the connection at the end of the network. Refer to Figure 7. 505942 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
-
Page 14: Connecting The Repeater To The Pc
9. Connect the wall adapter to a 120 VAC 60 Hz. removed. outlet. 4. Connect one of the 210150 Network Cables to segment 2 of the repeater. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 505942... - Page 15 To Connect Repeater to PC WALL ADAPTER (120 VOLT) REPEATER GREEN BLACK 12 VOLT TERMINAL STRIP DATA CONNECTOR NBS-42 BLACK CARD GREEN COM210N COM210N NETWORK CABLE (210150) Figure 8 505942 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
-
Page 16: Connecting The Repeater To A Laptop
NBS-20 CARD RS-485 REPEATER NETWORK CABLE 12 VOLT (210150) NETWORK CABLE (210165) TERMINAL STRIP 1/2 WATT TERMINATING RESISTOR BLACK GREEN WHITE BLACK GREEN COM1047N BLACK Figure 9 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 505942... -
Page 17: Troubleshooting
- Bad firmware in reader Loading valid FW ends error intact - Firmware updated, but s/w not - Bad firmware in reader Loading valid FW ends error intact 505942 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... - Page 18 - Maximum heat time Cycle power to clear error exceeded “E:Pr” - Pressure switch sequence error - Pressure switches out of Cycle power to clear error sequence © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 505942...
-
Page 19: Network Interface Boards
NOTE: Both shorts or flipped wires will cause Errors” and numerous “Unable to Connect” numerous errors on the central PC, including messages. “Protocol Errors” and numerous “Unable to Connect” messages. 505942 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 20: Card Reader
Hotlisted card inserted into the reader Card inserted into the reader was on the hotlist. Card destroyed. NOTE: Errors marked with an "X" remain on the display until the error condition is cleared. All other errors are displayed temporarily, for approximately 2 seconds. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 505942... -
Page 21: Card Insertions Not Recognized By The Card Reader
NOT flashing one second on/one second off, it is not functioning correctly. It will need to be either reset ( by powering down then up again) or replaced. 505942 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 22: Ec:20 - Error Reading Card
If, after cleaning, the problem persists when numerous cards have been tried numerous times, the reader is not reading cards properly and should be replaced. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 505942... - Page 23 Requires each machine to have a separate node address. Last (NIB) on the network requires an 120 (NIB) (NIB) (NIB) (NIB) Ohm terminating resistor for proper communication. Figure 10 505942 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
-
Page 24: Network Board Service
In general, there are three possible sources of failure, the NWB, the FEC, and the Harness. Parts may need to be swapped out individually to isolate the problem. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 505942... -
Page 25: Network Board To Pc Communication Problems
Try swapping the NW cable from the rear connector to the NWB and test again. If communication is successful, the harness needs to be replaced. 505942 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... - Page 26 Notes © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 505942...
