CyberTrack H1
720p HD Desktop Webcam
Model: CyberTrack H1
QuickGuide
English
www.adesso.com
CONTENTS
A
B
CyberTrack H1 Webcam
Quick Start Guide
DESCRIPTION
Power
Indicator
Lens
Adjustable Clip
LIMITED WARRANTY
Adesso provides a one year limited warranty for all of its products against defects in
material and workmanship.
During this period, Adesso will repair or replace any product which proves to be defec-
tive. However, Adesso will not warranty any product which has been subject to improper
freight handling, shipping abuse, neglect, improper installation or unauthorized repair.
The warranty will not cover products installed with components not approved by Adesso
and products where the sealed assembly trace has been broken.
If you discover a defect, Adesso will, at its option, repair or replace the product at no
charge to you provided you return it during the warranty period with freight charges
pre-paid to Adesso. Before returning any product, you must obtain a Return Merchan-
dise Authorization number (RMA). This RMA # must be clearly marked on the outside
of the package you are returning for warranty service. Be certain to also include your
name, shipping address (no PO Boxes), telephone number, and a copy of the invoice
showing proof of purchase in the package.
SUPPORT
We
have
listed
most
of
http://www.adesso.com/faqs.asp.
you contact our E-mail or Telephone Support.
Email Support: If our FAQ's do not help you resolve your issues, please email
support@adesso.com
Telephone Support:
Toll Free: (800) 795-6788
9:00AM to 5:00PM PST Monday - Friday
1
INSTALLATION
1. Flip and clip webcam on monitor edge or lay flat on desktop.
C
Driver & Software CD
Flip & Clip
2. Turn your computer ON and then plug the webcam USB connector into
an available USB port on your computer.
Microphone
3. Insert the enclosed Driver & Software CD into the CD-ROM drive of
your computer. The installation menu will pop up automatically (click
setup.exe if installation menu does not run automatically).
4
our
FAQ's
(Frequently Asked
Questions)
at:
Please visit our FAQ Service & Support pages before
2
Lay Flat
USB Port
USB Cable
5
INTRODUCTION
Adesso's CyberTrack H1 features 720p HD Video Resolution that allows you to record
and share colorful VGA quality video with fine detail. This webcam offers you broad
Instant Messenger compatibility, so you can enjoy video conferencing with today's
most popular Instant Messenger applications. This webcam also includes an integrated
wide-angle microphone that lets your voice be heard loud and clear, whether you are
chatting with loved ones or doing business on a video call. With all these great features,
you can easily record and transmit your videos to everyone!
SPECIFICATIONS
• Image Sensor: High Resolution CMOS Color Sensor
• Resolution: 1.3 Megapixels
• Video Format: 24-Bit True Color
• Interface: USB 2.0
• Frame Rate: 30 ftps @ 320 x 240
15 ftps @ 640 x 480
15 ftps @ 1280 x 720
• Dynamic Range: < 72db
• Focus Setting: Manual
• Features: Automatic White Balance & Auto Color Compensation
REQUIREMENTS
• Hardware: VGA Display Card Supported with DIRECTX
• Operating System: Windows
7, Windows
Vista & Windows
®
®
• Connectivity Interface: USB port
4. Click DRIVER SETUP from installation menu to install webcam driver, after
driver installation click WEBCAM COMPANION 4 (optional) for bonus
webcam features software installation.
Note: Webcam Companion 4 license key is located on software CD envelope.
5. After the installation is complete, your webcam is ready to be used with your
instant messenger applications or with Webcam Companion 4 software.
Video & Audio Setup for Instant Messenger
Use the following setup instructions according to your instant messenger
application settings:
1. Select the video source "Vimicro USB 2.0 UVC PC Camera"
2. Select the audio source "USB Microphone"
3. Hit "Save" or "Apply" for the update settings
Note:
For more help on using Webcam Companion 4 see user manual on
enclosed Driver & Software CD.
CyberTrack H1 081111 V6
XP
®
3
6
