Adesso WKB-2000BA Quick Start Manual

Mini Keyboard

Bluetooth 3.0
®
Model: WKB-2000BA
QuickGuide
English
www.adesso.com
CONTENTS
insert delete
tab
caps
lock return
shift shift
ctrl alt alt ctrl
A B
Keyboard Micro USB Cable

DESCRIPTION

insert delete
tab
caps
lock
return
shift
shift
ctrl alt alt ctrl
Use these special keys to access
iPad features: home screen, search,
copy, paste, slideshow, on-screen
keyboard and screenshot
Screen Lock
Use these Multimedia Hotkeys
to access multimedia tools

CHARGING BATTERY

Charge keyboard battery using computer USB port or any USB power
adaptor (i.e. iPad charger):
a. Insert the Micro USB Charging Cable Connector into the keyboard
micro USB charging port, located on right side of keyboard.
Note: Insert Micro USB Cable with battery charging symbol facing up,
as shown below.
CONNECT
b. Insert the USB end of the Micro USB Cable into the USB port of your
computer or any USB power adaptor.
CONNECT a
Adesso Keyboard Micro USB Cable

LIMITED WARRANTY

Adesso provides a one year limited warranty for all of its products against defects in
material and workmanship.
During this period, Adesso will repair or replace any product which proves to be
defective. However, Adesso will not warranty any product which has been subject to
improper freight handling, shipping abuse, neglect, improper installation or
unauthorized repair. The warranty will not cover products installed with components not
approved by Adesso and products where the sealed assembly trace has been broken.
If you discover a defect, Adesso will, at its option, repair or replace the product at no
charge to you provided you return it during the warranty period with freight charges
pre-paid to Adesso. Before returning any product, you must obtain a Return
Merchandise Authorization number (RMA). This RMA # must be clearly marked on the
outside of the package you are returning for warranty service. Be certain to also include
your name, shipping address (no PO Boxes), telephone number, and a copy of the
invoice showing proof of purchase in the package.

SUPPORT

We have listed
http://www.adesso.com/faqs.asp.
you contact our E-mail or Telephone Support.
Email Support: If our FAQ's do not help you resolve your issues, please email
support@adesso.com
Telephone Support:
Toll Free: (800) 795-6788
1
9:00AM to 5:00PM PST Monday - Friday

Bluetooth CONNECTION SETUP

1. Turn iPad power to ON, then place keyboard power switch to ON.
2. Press keyboard CONNECT button to activate Bluetooth
C
Quick Start Guide
Connect Button
Activates Bluetooth signal
CONNECT ®
Caps Lock Indicator
Light will display when Caps Lock
is selected
Charging Indicator
3. Select iPad Settings, then General and Bluetooth option, slide
Light will display in orange when
charging and green when
the iPad Bluetooth toggle to ON. After a few seconds Adesso
keyboard is fully charged
Bluetooth Keyboard will appear in list of Bluetooth devices, select
Low Battery Indicator
Light will display in orange when
keyboard.
battery is low
Charging
Mini USB port to be used with USB
Cable to charge Keyboard
ON/OFF Power Switch
Activates and deactivates
Keyboard power
4

iPad Hotkeys

Key Action
Home Screen
Search
Copy
Paste
Slideshow
On-Screen Keyboard
Screenshot
Screen Lock

Multimedia Hotkeys

Key Action
Previous Track
Play/Pause
Computer's USB Port
b Previous Track
OR
Mute
Volume Down
Volume Up
7
USB Power Adaptor
most of our FAQ's (Frequently Asked Questions)
Please visit our FAQ Service & Support pages before
signal.
®
Connect
Button
CONNECT
insert delete
ON/OFF
Power Switch
tab
caps
lock
return
shift shift
ctrl alt alt ctrl
Description
Returns iPad screen to home screen
Launches iPad search feature
Copy text or image
Paste text or image
Launches iPad slideshow feature
Shows or hides iPad on-screen keyboard
Takes snapshot of screen
Deactivates iPad (standby mode) and locks screen
Description
Takes you to previous track in multimedia software
Plays or pauses track in multimedia software
Takes you to next track in multimedia software
Mutes computer main volume
Decreases computer main volume
Increases computer main volume

INTRODUCTION

The Adesso Bluetooth 3.0 Mini Keyboard 2000 is the perfect companion
®
for your iPad and other Bluetooth enabled devices. This Bluetooth
™ ®
keyboard is designed using the latest wireless technology and a unique
silicon material that protects your keyboard from unexpected spills and
allows washing to eliminate germs. The silicon material also offers a faster
and almost silent tactile response, so you can be productive without the
extra noise. The keyboard includes a standard layout with iPad
Hot Keys to access your iPad's shortcuts with one-touch. Along with all
these great features, this keyboard is also compact and portable, so you can
take it everywhere.

SPECIFICATIONS

• Keyboard Layout: 76-Key Mini Layout
• Key Type: Silicon
• Wireless Technology: Bluetooth 3.0 wireless technology with
®
backward compatibility
• Working Range: 30 feet (10m)
• Indicators: Caps Lock, Charging & Low Battery
at:
• iPad Hot Keys: 8
• Multimedia Hot Keys: 6
• Keyboard Dimensions: 9.25 x 5.25 x 0.30" (235 x 133 x 7mm)
• Battery Life: Up to 100 hours (continuous use) /
Up to 30 days (standby mode)

REQUIREMENTS

• Bluetooth 3.0, 2.1, 2.0 & 1.1 wireless technology
®
2
4. A screen will show asking to pair Adesso Bluetooth Keyboard,
using Adesso Bluetooth Keyboard enter the randomized passkey
provided on screen and press return. Upon completion, your iPad
screen will show the keyboard connected and will be ready for use.
Randomized number
5
NOTE:
• The Bluetooth LED Indicator on the keyboard will flash when the
Connect Button is being pressed.
• The keyboard goes to sleep mode after 5 minutes of inactivity, it is
suggested to turn the keyboard Power Switch to OFF when leaving
your desk for more than an hour to save battery life.

TROUBLESHOOTING

If you cannot get your keyboard to work after installation, please try the
following:
1. Make sure the Power Switch at the side of the keyboard is set to ON.
2. Make sure you have setup Bluetooth connection correctly on your
iPad, as instructed on Bluetooth Connection Setup (pg. 5,6).
3. Make sure that the keyboard is within range of your iPad. Maximum
keyboard Bluetooth range is about 30 feet.
4. Make sure that both your iPad battery and the keyboard battery are
fully charged.
8
3.0
®
and Multimedia
™
3
6
9
WKB-2000BA 091411 V4
