A960G+/A960GL+ Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee
that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the
contents here and specially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and
we will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.
Dichiarazione di conformità
sintetica
Ai sensi dell'art. 2 comma 3 del D.M.
275 del 30/10/2002
Si dichiara che questo prodotto è
conforme alle normative vigenti e
soddisfa i requisiti essenziali richiesti
dalle direttive
2004/108/CE, 2006/95/CE e
1999/05/CE
quando ad esso applicabili
Short Declaration of conformity
We declare this product is complying
with the laws in force and meeting all
the essential requirements as specified
by the directives
2004/108/CE, 2006/95/CE and
1999/05/CE
whenever these laws may be applied
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Biostar A960G
Summary of Contents for Biostar A960G
- Page 1 A960G+/A960GL+ Setup Manual FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 2: Table Of Contents
Table of Contents Chapter 1: Introduction.......... 1 Before You Start ................1 Package Checklist................1 Motherboard Features..............2 Rear Panel Connectors ..............3 Motherboard Layout ................4 Chapter 2: Hardware Installation ......5 Installing Central Processing Unit (CPU)........5 FAN Headers..................7 Installing System Memory ..............8 Connectors and Slots ...............10 Chapter 3: Headers &... -
Page 3: Chapter 1: Introduction
A960G+/A960GL+ CHAPTER 1: INTRODUCTION EFORE TART Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: Prepare a dry and stable working environment with sufficient lighting. Always disconnect the computer from power outlet before operation. -
Page 4: Motherboard Features
Data transfer rates up to 3 Gb/s SATA II Integrated Serial ATA Controller SATA Version 2.0 specification compliant Realtek RTL 8111F (A960G+) 10 / 100 / 1000 Mb/s auto negotiation Realtek RTL 8105E (A960GL+) 10 / 100 Mb/s auto negotiation 5.1 channels audio out... -
Page 5: Rear Panel Connectors
Board Size 182 mm(W) x 225 mm(L) Special RAID 0 / 1 / 10 support Features Biostar reserves the right to add or remove support for OS Support Windows XP / Vista / 7 any OS With or without notice. ANEL... -
Page 6: Motherboard Layout
Motherboard Manual OTHERBOARD AYOUT Note: represents the 1 pin. ■... -
Page 7: Chapter 2: Hardware Installation
A960G+/A960GL+ CHAPTER 2: HARDWARE INSTALLATION (CPU) NSTALLING ENTRAL ROCESSING Step 1: Pull the lever toward direction A from the socket and then raise the lever up to a 90-degree angle. Step 2: Look for the white triangle on socket, and the gold triangle on CPU should point towards this white triangle. - Page 8 Motherboard Manual Step 3: Hold the CPU down firmly, and then close the lever toward direct B to complete the installation. Step 4: Put the CPU Fan on the CPU and buckle it. Connect the CPU FAN power cable to the CPU_FAN1. This completes the installation.
-
Page 9: Fan Headers
A960G+/A960GL+ FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different due to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1. -
Page 10: Installing System Memory
Motherboard Manual NSTALLING YSTEM EMORY A. Memory Modules Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. - Page 11 A960G+/A960GL+ Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated. Note: If the DIMM does not go in smoothly, do not force it. Pull it all the way out and try again.
-
Page 12: Connectors And Slots
Motherboard Manual ONNECTORS AND LOTS SATA1~SATA4: Serial ATA Connectors The motherboard has a PCI to SATA Controller with 4channels SATA interface, it satisfies the SATA 2.0 spec and with transfer rate of 3Gb/s. Assignment Ground Ground Ground ATXPWR2: ATX Power Source Connector This connector provides +12V to CPU power circuit. - Page 13 A960G+/A960GL+ ATXPWR1: ATX Power Source Connector This connector allows user to connect 24-pin power connector on the ATX power supply. Assignment Assignment +3.3V +3.3V -12V +3.3V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK Standby Voltage+5V +12V +12V Ground +3.3V...
- Page 14 Motherboard Manual PEX16_1: PCI-Express X16 Slot PCI-Express 2.0 compliant. Maximum theoretical realized bandwidth of 4GB/s simultaneously per direction, for an aggregate of 8GB/s totally. PCI-Express supports a raw bit-rate of 2.5Gb/s on the data pins. PCI1: Peripheral Component Interconnect Slot This motherboard is equipped with 1 standard PCI slot.
-
Page 15: Chapter 3: Headers & Jumpers Setup
A960G+/A960GL+ CHAPTER 3: HEADERS & JUMPERS SETUP OW TO ETUP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened... - Page 16 Motherboard Manual F_USB1/F_USB2: Headers for USB 2.0 Ports at Front Panel These headers allow user to connect additional USB cable on the PC front panel, and also can be connected with internal USB devices, like USB card reader. Assignment +5V (fused) +5V (fused) USB- USB-...
- Page 17 A960G+/A960GL+ J_PRINT1: Printer Port Connector This header allows you to connector printer on the PC. Assignment Assignment -Strobe Ground -ALF Data 6 Data 0 Ground -Error Data 7 Data 1 Ground -Init -ACK Data 2 Ground -Scltin Busy Data 3...
- Page 18 Motherboard Manual JCMOS1: Clear CMOS Jumper Placing the jumper on pin2-3 allows user to restore BIOS safe setting and CMOS data. Pease carefully follow the procedures to avoid damaging the motherboard. Pin 1-2 Close: Normal Operation (default). Pin 2-3 Close: Clear CMOS data.
-
Page 19: Chapter 4: Raid Functions
A960G+/A960GL+ CHAPTER 4: RAID FUNCTIONS PERATING YSTEM Supports Windows XP, Windows Vista, and Windows 7. RRAYS RAID supports the following types of RAID arrays: RAID 0: RAID 0 defines a disk striping scheme that improves disk read and write times for many applications. - Page 20 Motherboard Manual RAID 1: Every read and write is actually carried out in parallel across 2 disk drives in a RAID 1 array system. The mirrored (backup) copy of the data can reside on the same disk or on a second redundant drive in the array. RAID 1 provides a hot-standby copy of data if the active volume or drive is corrupted or becomes unavailable because of a hardware failure.
- Page 21 A960G+/A960GL+ RAID 10: RAID 1 drives can be stripped using RAID 0 techniques. Resulting in a RAID 10 solution for improved resiliency, performance and rebuild performance. Features and Benefits Drives: Minimum 4, and maximum is 6 or 8, depending on the platform.
-
Page 22: Chapter 5: Useful Help
Motherboard Manual CHAPTER 5: USEFUL HELP RIVER NSTALLATION After you installed your operating system, please insert the Fully Setup Driver DVD into your optical drive and install the driver for better system performance. You will see the following window after you insert the DVD The setup guide will auto detect your motherboard and operating system. -
Page 23: Software
A960G+/A960GL+ OFTWARE Installing Software 1. Insert the Setup DVD to the optical drive. The drivers installation program would appear if the Autorun function has been enabled. 2. Select Software Installation, and then click on the respective software title. 3. Follow the on-screen instructions to complete the installation. - Page 24 If you are not using Outlook Express as your default e-mail client application, you may need to save the system information to a .txt file and send the file to our tech support with other e-mail application. Go to the following web http://www.biostar.com.tw/app/en-us/about/contact.php for getting our contact information.
-
Page 25: Bios Update
A960G+/A960GL+ BIOS Update BIOS Update is a convenient utility which allows you to update your motherboard BIOS under Windows system. Show current BIOS information Update BIOS from the Internet Save current BIOS to a .bin file Update BIOS with a BIOS file <Backup BIOS>... - Page 26 Motherboard Manual <Update BIOS> Before doing this, please download the proper BIOS file from the website. Then click Update BIOS button, a dialog will show for asking you backup current BIOS. Click Yes for BIOS backup and refer to the Backup BIOS procedure;...
-
Page 27: Extra Information
A960G+/A960GL+ XTRA NFORMATION CPU Overheated If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again. - Page 28 Motherboard Manual BIO-Flasher BIO-Flasher is a BIOS flashing utility providing you an easy and simple way to update your BIOS via USB pen drive or floppy disk. The BIO-Flasher is built in the BIOS chip. To enter the utility, press <F12> during the Power-On Self Tests (POST) procedure while booting up.
-
Page 29: Troubleshooting
A960G+/A960GL+ ROUBLESHOOTING Probable Solution There is no power in the system. Make sure power cable is Power LED does not shine; the securely plugged in. fan of the power supply does not Replace cable. work Contact technical support. Indicator light on keyboard does not shine. -
Page 30: Appendix: Spec In Other Languages
Max. 512MB gemeinsam benutzter Videospeicher Datentransferrate bis zu 3 Gb/s SATA Integrierter Serial ATA-Controller Konform mit der SATA-Spezifikation Version 2.0. Realtek RTL 8111F (A960G+) 10 / 100 / 1000 Mb/s auto negotiation Realtek RTL 8105E (A960GL+) 10 / 100 Mb/s auto negotiation 5.1-Kanal-Audioausgabe... - Page 31 Platinengröß 182 mm (B) X 225 mm (L) Sonderfunkti Unterstützt RAID 0 / 1 / 10 onen Biostar behält sich das Recht vor , ohne Ankündigung die OS-Unterstü Windows XP / Vista / 7 Unterstützung für ein Betriebssystem hinzuzufügen tzung...
-
Page 32: French
Taux de transfert jusqu'à 3 Go/s. SATA Contrôleur Serial ATA intégré Conforme à la spécification SATA Version 2.0 Realtek RTL 8111F (A960G+) 10 / 100 / 1000 Mb/s négociation automatique Realtek RTL 8105E (A960GL+) 10 / 100 Mb/s négociation automatique Prise en Sortie audio à... - Page 33 182 mm (l) X 225 mm (H) carte Fonctionnal ités Prise en charge RAID 0 / 1 / 10 spéciales Biostar se réserve le droit d'ajouter ou de supprimer le Support SE Windows XP / Vista / 7 support de SE avec ou sans préavis.
-
Page 34: Italian
Velocità di trasferimento dei dati fino a 3 Gb/s. SATA Controller Serial ATA integrato Compatibile specifiche SATA Versione 2.0. Realtek RTL 8111F (A960G+) Negoziazione automatica 10 / 100 / 1000 Mb/s Realtek RTL 8105E (A960GL+) Negoziazione automatica 10 / 100 Mb/s Uscita audio 5.1 canali... - Page 35 Dimension i scheda (altezza) Caratterist iche Supporto RAID 0 / 1 / 10 speciali Biostar si riserva il diritto di aggiungere o Sistemi operativi Windows XP / Vista / 7 rimuovere il supporto di qualsiasi sistema supportati operativo senza preavviso.
-
Page 36: Spanish
Tasas de transferencia de hasta 3 Gb/s. SATA Controlador ATA Serie Integrado Compatible con la versión SATA 2.0. Realtek RTL 8111F (A960G+) Negociación de 10 / 100 / 1000 Mb/s Red Local Realtek RTL 8105E (A960GL+) Negociación de 10 / 100 Mb/s Salida de sonido de 5.1 canales... - Page 37 Funciones Admite RAID 0 / 1 / 10 especiales Soporte de Biostar se reserva el derecho de añadir o retirar el sistema Windows XP / Vista / 7 soporte de cualquier SO con o sin aviso previo. operativo...
-
Page 38: Portuguese
Velocidades de transmissão de dados até 3 Gb/s. SATA Controlador Serial ATA integrado Compatibilidade com a especificação SATA versão 2.0. Realtek RTL 8111F (A960G+) Auto negociação de 10 / 100 / 1000 Mb/s Realtek RTL 8105E (A960GL+) Auto negociação de 10 / 100 Mb/s Suporte Saída de áudio de 5.1 canais... - Page 39 182 mm (L) X 225 mm (A) da placa Característi Suporta as funções RAID 0 / 1 / 10 especiais A Biostar reserva-se o direito de adicionar ou remover Sistemas operativos Windows XP / Vista / 7 suporte para qualquer sistema operativo com ou sem suportados aviso prévio.
-
Page 40: Polish
SATA Zintegrowany kontroler Serial ATA Zgodność ze specyfikacją SATA w wersji 2.0. Realtek RTL 8111F (A960G+), 10/ 100/ 1000 Mb/s z automatyczną negocjacją szybkości Realtek RTL 8105E (A960GL+), 10/ 100 Mb/s z automatyczną negocjacją szybkości 5.1 kanałowe wyjście audio Obsługa... - Page 41 Wymiary 182 mm (S) X 225 mm (W) płyty Funkcje Obsługa RAID 0 / 1 / 10 specjalne Obsluga Biostar zastrzega sobie prawo dodawania lub systemu Windows XP / Vista / 7 odwoływania obsługi dowolnego systemu operacyjne operacyjnego bez powiadomienia.
-
Page 42: Russian
Встроенное последовательное скорость передачи данных до 3 гигабит/с. SATA устройство управления ATA Соответствие спецификации SATA версия 2.0. Realtek RTL 8111F (A960G+) Автоматическое согласование 10 / 100 / 10000 Мб/с Локальная сеть Realtek RTL 8105E (A960GL+) Автоматическое согласование 10 / 100 Мб/с... - Page 43 панели Специальн ые техническ Поддержка RAID 0 / 1 / 10 ие характери стики Biostar сохраняет за собой право добавлять или Поддержк Windows XP / Vista / 7 удалять средства обеспечения для OS с или без а OS предварительного уведомления.
-
Page 44: Arabic
Serial ATA ﻣﺘﻜﺎﻣﻞ ﻢ ﻣﺘﺤﻜ SATA .0.2 اﻹﺻﺪار ﻟﻤﻮاﺻﻔﺎت ﻣﻄﺎﺑﻘﺔ 0001/001/01 اﻟﺴ ﻴﺎرات ﺗﻔ ﺎوض ﺛﺎﻧﻴ ﺔ / ﻣﻴﺠﺎ Realtek RTL 8111F (A960G+) داﺧﻠﻴﺔ ﺷﺒﻜﺔ 001/01 اﻟﺴ ﻴﺎرات ﺗﻔ ﺎوض ﺛﺎﻧﻴ ﺔ / ﻣﻴﺠﺎ Realtek RTL 8105E (A960GL+) اﻟﺼﻮت ﻟﺨﺮج... -
Page 45: Smart Fan
ﻣﻘﺒﺲ ﺻﻮت ارﺗﻔﺎع ﻣﻢ ﻋﺮض ﻣﻢ اﻟﻠﻮﺣﺔ ﺣﺠﻢ ﺗﺪﻋﻢ ﺗﻘﻨﻴﺔRAID 0 / 1 / 10 ﻣﺰاﻳﺎ ﺧﺎﺻﺔ ﺗﺤﺘﻔﻆBiostar ﺑﺤﻘﻬﺎ ﻓﻲ إﺿﺎﻓﺔ أو إزاﻟﺔ اﻟﺪﻋﻢ ﻷي ﻧﻈﺎم ﺗﺸﻐﻴﻞ ﺑﺈﺧﻄﺎر أو Windows XP / Vista / 7 اﻟﺘﺸﻐﻴﻞ أﻧﻈﻤﺔ دﻋﻢ ﺑﺪون إﺧﻄﺎر... -
Page 46: Japanese
H/Wモニター 機能を採用しています。 ITEの「スマートガーディアン」機能 グラフィッ AMD 760Gチップセットに統合 最大の共有ビデオメモリは512MBです クス 最高3Gb/秒のデータ転送速度 SATA 統合シリアルATAコントローラ SATAバージョン2.0仕様に準拠。 Realtek RTL 8111F (A960G+) 10 / 100 / 1000 Mb/秒のオートネゴシエーション Realtek RTL 8105E (A960GL+) 10 / 100 Mb/秒のオートネゴシエーション HDオーディ 5.1チャンネルオーディオアウト ALC662 オのサポー ハイデフィニションオーディオのサポート ト PCI Express X16スロット スロット... - Page 47 A960G+/A960GL+ 仕様 フロントオーディオコネクタ フロントパネルオーディオ機能をサポートします CPUファンヘッダ CPUファン電源装置(スマートファン機能を搭載) システムファンヘッダ システムファン電源装置 CMOSクリアヘッダ 各コネクタは2つのフロントパネルUSBポートをサポートし USBコネクタ ます 電源コネクタ(24ピン) 電源コネクタ(4ピン) プリンタポートコネクタ 各コネクタは1つのプリンタポートをサポートします PS/2キーボード PS/2マウス VGAポート 背面パネル LANポート USBポート オーディオジャック ボードサイ 182 mm (幅) X 225 mm (高さ) ズ RAID 0 / 1 / 10 のサポート 特殊機能...
