Summary of Contents for Acumen DATABRIDGE SDR2-USB
- Page 1 CUMEN NSTRUMENTS ORPORATION DataBridge™ SDR2-USB Configuration Guide revision 1.0 • 04/2009...
- Page 3 Copyright This document is copyrighted by Acumen Instruments Corporation with all rights reserved. No part of this document may be reproduced in any form without prior written consent of Acumen Instruments Corporation. Copyright © 2009 by Acumen Instruments Corporation. All rights reserved.
-
Page 5: Table Of Contents
SDR2-USB Configuration Guide rev 1.0 Getting Started Table of Contents 1. Getting Started ..............5 Overview ....................5 Before you start ..................6 A quick guide to the DataBridge SDR2-USB .......... 6 ... - Page 6 Exception 10: USB Error ..............28 Exception 11: Directory Creation Error ..........28 Exception 12: FAT12 File System Detected ........28 Contacting Acumen Instruments Corporation ........29 6.2.1 Technical support ................. 29 6.2.2 ...
-
Page 7: Getting Started
SDR2-USB Configuration Guide rev 1.0 Getting Started Getting Started 1.1 Overview DataBridge SDR2-USB serial data recorders record RS-232 serial data to industry-standard mass storage using an Microsoft Windows™-compatible FAT file format. The SDR2-USB is equipped with a USB 2.0 socket and is designed for use with USB storage media such as USB flash memory keys. -
Page 8: Before You Start
Getting Started SDR2-USB Configuration Guide rev 1.0 1.2 Before you start Before you start, be sure you have the following items available: • DataBridge SDR2-USB • A 5-30VDC power supply • RS-232 DB9 serial cable • The device you wish to record from (serial data source) 1.3 A quick guide to the DataBridge SDR2-USB On the front of the SDR2-USB are the USB "A"... -
Page 9: Deploying The Databridge Sdr2-Usb
SDR2-USB Configuration Guide rev 1.0 Getting Started On the rear is the male nine-pin D-subminiature connector (DB9M) for the data port. The 5 to 30 VDC power input is also located on the rear panel. From serial data source 5 to 30 VDC Power Figure 1.2. -
Page 10: Congratulations
Getting Started SDR2-USB Configuration Guide rev 1.0 Figure 1.3. Creating setup.txt. Once the file is created, double-click it to open the file in Windows Notepad and enter “DataPortBaud=9600” as shown in Figure 1.4. This tells the SDR2-USB to communicate with your data source at 9600 baud. The baud rate for your serial data source may differ from 9600 bps. -
Page 11: Configuring The Databridge Sdr2-Usb
SDR2-USB Configuration Guide rev 1.0 Configuring the DataBridge SDR2-USB Configuring the DataBridge SDR2-USB Now that you’ve successfully edited the SDR2-USB’s setup.txt file, you are ready to configure it for use with your serial data source. Using the setup file, you can: •... -
Page 12: Comments
Configuring the DataBridge SDR2-USB SDR2-USB Configuration Guide rev 1.0 2.1 Comments Within the setup.txt file, it is useful to record comments documenting the settings chosen and why some configuration choices were made. Comments are also useful for temporarily disabling setting(s) for the purposes of testing multiple settings. -
Page 13: Step 2: Insert Usb Storage Device And Apply Power
SDR2-USB Configuration Guide rev 1.0 Configuring the DataBridge SDR2-USB Figure 2.2. Setting date and time. Step 2: Insert USB storage device and apply power Eject the USB storage device and remove it from the computer. Insert the USB device into the SDR2-USB, and connect power. The SDR2-USB will display its usual flashing pattern, then read the setup file and turn on all 4 front-panel LED indicators. -
Page 14: Specifying A Filename And Folder
Configuring the DataBridge SDR2-USB SDR2-USB Configuration Guide rev 1.0 Hardware handshaking prevents a data source from sending data when the SDR2-USB is not ready to receive it – the SDR2-USB can “shut off” the transmitting data source if, for example, the USB storage media is slow or not present. -
Page 15: Configuring File Creation Behavior
SDR2-USB Configuration Guide rev 1.0 Configuring the DataBridge SDR2-USB Figure 2.3. Specifying filename and folder for recording. 2.5 Configuring file creation behavior Be default, the SDR2-USB creates a new file in the recording folder every time recording is initiated, generating a new, unique filename based on the previous filename. -
Page 16: Testing Your Configuration
Configuring the DataBridge SDR2-USB SDR2-USB Configuration Guide rev 1.0 feed is received by adding the line TimestampTrigger=10. The recorder will be “armed” to time stamp when a line feed is received, then insert a stamp when the next character is received— at the start of the next line. It is common to encounter a data source that periodically outputs “bursts”... -
Page 17: Operations
SDR2-USB Configuration Guide rev 1.0 Operations Operations 3.1 Setup file reading The setup.txt file on the USB storage device is read only when power is applied to the SDR2-USB. Once read, all settings found in setup.txt are retained by the recorder. 3.2 Record mode operation When you press the record button, the SDR2-USB searches for the current file specified in the setup file, creates it if necessary, and opens it. -
Page 18: Stopping Recording
Operations SDR2-USB Configuration Guide rev 1.0 3.2.2 Stopping recording Incoming data is written to the open file as it is received until you stop recording by pressing the record button. The SDR2-USB then closes the file, updates its directory entry (recording file size, date, and time), and returns to stop mode. -
Page 19: Formatting The Storage Media
SDR2-USB Configuration Guide rev 1.0 Operations Delete files on the target media using your computer or replace the media, then insert and press the record button to record data normally. 3.2.7 Formatting the storage media If you have purchased a USB storage device, you may need to format it NOTE: If your USB using MS-DOS™, Windows 95/98/ME™, Windows NT/2000/XP™, or storage media was... -
Page 20: Resetting To Factory Defaults
Operations SDR2-USB Configuration Guide rev 1.0 3.3 Lithium battery maintenance The SDR2-USB's real-time clock uses a small lithium battery to maintain time when external power is unavailable. The life of this battery should exceed 5 years. If you find your SDR2-USB is not keeping time correctly when power is lost, you may need to replace the battery. -
Page 21: Setup File Reference
SDR2-USB Configuration Guide rev 1.0 Setup File Reference Setup File Reference All SDR2-USB configuration is performed via the setup.txt file in the root folder of the USB storage device. The setup file is read only when power is connected to the SDR2-USB, and all settings specified within the setup file are retained by the recorder indefinitely. -
Page 22: Data Port Setup Commands
Setup File Reference SDR2-USB Configuration Guide rev 1.0 4.1.2 Data Port Setup Commands DataPortBaud (default=9600): Use this setup file command to specify a bits/second rate for communication with your data source. Industry- standard baud rates are 300, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, and 230400 bps. -
Page 23: Scheduled File Closing Commands
SDR2-USB Configuration Guide rev 1.0 Setup File Reference possible when space available on the storage media is exhausted. Together with scheduled file closing, this option can be used to configure the SDR2-USB as a circular buffer— as the disk fills, the oldest file is overwritten. -
Page 24: Other Commands
Setup File Reference SDR2-USB Configuration Guide rev 1.0 TimestampTrigger: The TimestampTrigger setup file line specifies a decimal ASCII character that “arms” the time stamping function. Once the trigger character is received, the recorder will insert a time stamp when the next byte of data is received. -
Page 25: J4 Remote Control Port
SDR2-USB Configuration Guide rev 1.0 J4 Remote Control Port J4 Remote Control Port 5.1 Overview The SDR2-USB’s J4 remote connector allows for starting and stopping recording via external switches/buttons or TTL/CMOS digital logic. The J4 connector also provides alternate outputs for the front-panel fault, data, and record indicators. -
Page 26: Functions
Table 5.1. J4 remote control port pin functions. 5.4 Pinout and Mating Cable The J4 connector is a 2mm 10-pin connector housing that mates to a Hirose DF11-10DS-2C shell (Digi-Key part number H2023-ND). A pre-built J4 cable is available from Acumen Instruments Corporation on request. -
Page 27: Force-Record Shunt Installation
SDR2-USB Configuration Guide rev 1.0 J4 Remote Control Port Contact Function Direction Wire Color (3.3 VDC) GND (0 VDC) Black REC_BUTTON input Blue REC_TOGGLE input Grey FAULT output Yellow no connect DATA output Orange RECORD output Green (3.3 VDC) GND (0 VDC) Table 5.2. -
Page 29: Service And Support
SDR2-USB Configuration Guide rev 1.0 Service and Support Service and Support 6.1 Exception Codes The following are common error codes encountered when using DataBridge SDR2-USB products. To determine which error has occurred, watch the "exception" indicator on the SDR2-USB's front panel and count the number of rapid blinks. -
Page 30: Exception 4: Bad Boot Record
Try ejecting and reinserting the card or using a new card and contact Acumen if problem persists. Exception 6: EEPROM Error Rare hardware error. Contact Acumen to discuss repair or replacement. Exception 7: Cache Error Rare hardware error. Contact Acumen to discuss repair or replacement. -
Page 31: Contacting Acumen Instruments Corporation
Corporation can be reached at the following phone numbers: (515) 296-5366 (voice) (515) 296-3554 (fax) 6.2.2 U.S. Mail Acumen Instruments Corporation can be reached by mail at: Acumen Instruments Corporation 2625 N. Loop Drive Suite 2200 Ames, IA 50010 6.2.3... -
Page 32: Warranty
6.4 Warranty 6.4.1 One year warranty Acumen Instruments Corporation warrants this product to be free from defects in materials and workmanship for a period of one (1) year from the date of shipment. During the warranty period, Acumen Instruments Corporation will, at its option, either repair or replace products that prove to be defective. -
Page 33: Serial Port Basics
SDR2-USB Configuration Guide rev 1.0 Serial Port Basics A.Serial Port Basics A.1 Serial specifications Serial data is any data that is sent one bit at a time using a single electrical signal. In contrast, parallel data is sent 8, 16, 32, or even 64 bits at a time using a signal line for each bit. -
Page 34: Data Rates And The Uart
Serial Port Basics SDR2-USB Configuration Guide rev 1.0 The EIA RS-232C standard permits data rates up to 19200 bps and cable lengths up to 400 meters (but not both). data rate maximum distance (bps) (meters) (feet) 19200 9600 4800 2400 1200 1216 Table A.1. -
Page 35: Dte And Dce
SDR2-USB Configuration Guide rev 1.0 Serial Port Basics To transfer data asynchronously, the UART frames the 8 data bits between a stop bit and a start bit. The start bit is always a zero, while the stop bit is always a one. So, a byte of data sent serially is made up of 10 bits instead of the usual 8. -
Page 36: Handshaking
Serial Port Basics SDR2-USB Configuration Guide rev 1.0 modem cable because it can connect two terminals (DTE’s) without the use of modems (DCE’s). Note that GND pins are always connected. Most devices have female connectors (DB9 or DB25) if they are configured for DCE operation and male connectors if they are configured for DTE operation, but this is not always the case. - Page 37 SDR2-USB Configuration Guide rev 1.0 Serial Port Basics CTS, etc.), RS-232 devices use +3V to +25V to assert the signal and –3V to –25V to deassert the signal. These voltage levels are defined in the EIA/TIA- 232E specification. So, when a DTE devices drives RTS at –9.50V, it is signaling the DCE to stop sending data.
-
Page 39: Specifications
Specifications SDR2-USB Configuration Guide rev 1.0 B.Specifications B.1 Electrical specifications SDR2-USB requires a 5 to 30 VDC power source power source via NOTE: The connectors J7 and J1 on SDR2-USB. J1 is inaccessible on the SDR2-USB SDR2-USB datasheet without removing the enclosure. contains further specifications. -
Page 40: J1 Power Receptacle Pin Configuration
Specifications SDR2-USB Configuration Guide rev 1.0 B.1.6 J1 power receptacle pin configuration Function +5.0 to +30 VDC Ground Table B.3. The SDR2-USB internal power receptacle pin configuration. B.2 Serial communications Serial Port electrical interface compliance EIA/TIA-232E and V.28 data rates 50 to 921600 baud data bits 7 or 8... - Page 41 Specifications SDR2-USB Configuration Guide rev 1.0 Notes:...
