User Manual
NOTE: To ensure this system works safely and to its fullest potential, please read the User Manual before
use, and keep it handy for future reference. See important safety information on Pages 7-8.
Thank you for purchasing Acesonic's AM-170 250-
Watt (@ 4 Ohms) Professional Mixing Amplifier.
Acesonic takes pride in providing its customers with
only the most advanced and highest quality products
on the market. With proper care and use you will
get many years of satisfying use from your Acesonic
product.
Be sure to keep original packaging in case re-shipping
is required for returns or repairs.
First Things First
Before using your AM-170, take a few simple steps:
• Check to see that your local power outlets supply
the correct voltage for the AC input.
Table of Contents
First Things First .................................................1
System Components ............................................2
Product Features ..................................................2
Initial Setup Considerations ................................2
Front Panel Operations .......................................2
Back Panel Operations ........................................3
®
250-Watt Professional Mixing Amplifier
• Do not open the device as there are no user-
serviceable parts inside. For repairs, contact the
local distributor, an authorized service center or
Acesonic's U.S. headquarters.
• Care and cleaning directions are included in this
User Manual, but preventive measures are good
common sense. Do not use the device in areas that
are wet or prone to dampness. Always allow suffi-
cient room around the device to provide sufficient
air flow for cooling.
• When the device will not be used for a long period
of time, disconnect the power plug from the wall,
as well as the back of the unit, and remove all con-
necting cables for proper storage.
Remote Control Operations ................................4
Care & Maintenance ...........................................4
Troubleshooting ..................................................5
Connecting the AM-170 .....................................6
Company Contact Information ...........................8
1
AM-170
Advertisement
Table of Contents
Related Manuals for Acesonic AM-170
Summary of Contents for Acesonic AM-170
-
Page 1: Table Of Contents
Acesonic’s U.S. headquarters. on the market. With proper care and use you will • Care and cleaning directions are included in this get many years of satisfying use from your Acesonic User Manual, but preventive measures are good product. common sense. Do not use the device in areas that Be sure to keep original packaging in case re-shipping are wet or prone to dampness. -
Page 2: System Components
System Components Front Panel Operations Your Acesonic AM-170 unit is designed for years of Refer to the Figure A at the top of page 3 (right). enjoyment. Please take a moment to review the fol- 1. KEY CONTROL - The line of buttons allows you lowing instructions for its proper use and care. -
Page 3: Back Panel Operations
Figure A that takes commands from the Remote Control is 15. INFORMATION DISPLAY WINDOW – This located here. Do not obstruct line of sight access to color display shows a range of information, as well as this portion of the display during use. the frequency levels of the program material. -
Page 4: Remote Control Operations
6. AUDIO OUT – RCA jacks for Audio out. 10. SOURCE INPUTS – The jacks in this location accept inputs from BGM, AUX, DVD and CDG. 7. REC OUT AND LINE OUT – These RCA jacks are for sending Audio to external recording units or 11. -
Page 5: Troubleshooting
Troubleshooting Symptom Possible Cause Solution(s) Will not turn on AC power adapter cord is Check the AC adapter and the incorrectly attached or not AC outlet connections, as well as plugged into outlet the voltage selection switch Check the fuse below the AC adapter and see if it is broken No audio can be heard, audio Incorrect input source selected... -
Page 6: Connecting The Am-170
Connecting the AM-170 Figure C Technical Specifications Maximum Output ..........80W+80W @ 8 Ohm Max RMS (continuous) Output ......125W+125 W @ 4 Ohm RMS Microphone Input Sensitivity ............<20mV Music Input Sensitivity ..............300mV Microphone Frequency Response ........20Hz–20KHz/ 3dB Music Frequency Response ........... 20Hz–20KHz/ 3dB Microphone EQ ....Treble: +/- 5dB (10KHz), Bass: +/- 5dB (100Hz) Music EQ ......Treble: +/- 5dB (10KHz), Bass: +/- 5dB (100Hz) Speaker Wattage Impedance .......... -
Page 7: Fcc Advisory, Safety Warnings & Safe Use
FCC Advisory, Safety Warnings & Safe Use receiver is plugged Mises en garde, precautions et procedures de sûreté • If necessary, consulting the dealer or an experi- enced radio/TV technician for help 2. Important: When connecting the AM-170 to audio equipment, use only high-quality, shielded cables such as what is supplied with this product. -
Page 8: Company Contact Information
161 S. 8th Avenue One (1) Year Manufacturer Warranty & City of Industry Lifetime Technical Support CA 91746-3208 Designed in U.S.A. U.S.A. Technical Support: (626) 820-0645 E-mail: techsupport@acesonic.com © 2010 Acesonic USA, Inc. • All rights reserved Web site: www.acesonic.com...
