Acer TravelMate TM662LCi Brochure

TravelMate ™ 660 Series
Acer recommends Microsoft
for Mobile Computing.
TECHNICAL SPECIFICATIONS
TM662LCi
Platform & Core Logic Mobile Intel ® Centrino ™ Technology
• Intel ® Pentium ® M processor at 1.5GHz; 1024KB L2 cache; supporting Enhanced
Intel ® SpeedStep ® technology
• Intel ® 855GM chipset with 400MHz FSB
• Wireless: Integrated Intel ® PRO/Wireless 2100 network connection
Operating System Microsoft ® Windows ® XP Home Edition or Microsoft
Memory 512MB (2x256) DDR RAM upgradeable to 2048MB, 512KB FLASH BIOS; Shadow RAM-Support
HDD 40GB Enhanced-IDE hard disc drive with patented Disc Anti-Shock Protection
Storage Hot swappable Media bay with DVD/CD-RW combo
Display 15.0" SXGA+ TFT LCD with 1400 x 1050 pixel resolution, 16.7 million colours
Graphics Integrated 3D AGP Dynamic Video Memory Technology (DVMT) with up to 64MB of VRAM; Simultaneous LCD and CRT display; DualView
Multimedia Audio system with built-in microphone and speakers; MS-Sound compatible
Interfaces Parallel; 4 x USB 2.0; 1x Infrared (FIR); VGA for external monitor; 32bit type II PCMCIA CardBus slot; audio I/O; 1x S-video out (NTSC/PAL); 1x IEEE 1394 port;
1x docking port; RJ-11 jack; RJ-45 jack; 1x SmartCard slot
Security TravelMate SmartCard solution, featuring: 2 x SmartCards and PlatinumSecret
Slot for Kensington lock; BIOS user and supervisor passwords
Weight and Dimensions 330 (W) x 272 (D) x 28.9-31.8 (H) mm; 2.86 kg for 15" LCD model
Modem and Ethernet 56K ITU V.92 data/fax modem; Wake-on-Ring ready; 10/100Mbps Fast Ethernet; Wake-on-LAN ready
Wireless Connection Integrated Intel ® PRO/Wireless 2100 network connection 802.11b
Power ACPI power management supporting Standby and Hibernation modes; 75W 3-pin AC Adapter
Battery 65Wh Lithium-Ion battery pack with a battery life of up to 5 hours; rapid charge in 2.5 hours; 3.5 hours charge-in-use
Keyboard and pointer Acer "FineTouch" keyboard with Windows keys; inverted "T" 84/85/88 cursor layout; TouchPad pointing system with 4 scroll keys; Euro key; 4 launch keys,
including Internet and email (with LED for received mail) and 2 user-programmable keys
Quality and Temperature & humidity test; free drop test; spill test; acoustics test; weight pressure tests; shock and vibration test; electrostatic discharge test;
Reliability tests MTBF (Mean Time Between Failure) test; hinge life test
Software Acer Notebook Manager; Acer Launch Manager; Norton AntiVirus
Supplied with Manual; power supply unit; battery; recovery CD; 1x CD-RW
Options Memory expansion modules; additional battery; additional AC adapter; Acer MediaBay DVD-RW and DVD/CD-RW module; Acer MediaBay 2nd HDD and battery
module; external USB FDD; Acer EasyPort; I/O replicator; external battery charger
Certifications Microsoft ® Windows ® XP/ Windows ® 2000 - ACPI - Mobile PC2001 – SMBIOS 2.3 support with asset tag capability
Warranty 1 year carry in
In a continuing effort to improve the quality of our products, information in this brochure is subject to change without notice. Images
appearing are only representations of some of the configurations available for this model. Availability may vary depending on region. Acer
disclaims any liability for errors and omissions in product descriptions. Copyright 2004 Acer Europe. All rights reserved. Acer and the Acer logo
are registered trademarks. Microsoft ® , Windows ® , and the Windows logos are registered trademarks of Microsoft Corporation. Other
companies' names are used herein for identification purposes only and belong to their respective owners.
www.acer.co.uk www.acer.dk www.acer.pl
Acer UK Limited Acer Scandinavia A/S Acer Computer Poland
Tel. +44-1753-699 200 Tel. +45 39 16 88 00 Tel. +48-22-606-25 90
Fax +44-1753-699 201 Fax +45 39 16 88 01 Fax. +48-22-606-25 91
Sales enquiries: 0870 9002237
www.acercomputer.fi www.acer.no www.acer.hu
Acer Computer Finland Oy Acer Computer Norway AS Acer Computer Hungary
Tel +358-9-225 2690 Tel. +47-66-761 070 Tel. +36-1-248-3600
Fax +358-9-225 26916 Fax +47-66-901 031 Fax +36-1-248-3609
www.acer.cz www.acer-ee.com www.acer.ru
Acer Czech Republic s.r.o. Acer Eastern Europe Acer CIS Inc
Tel. +420-2-613-414-05 Tel. +49-4102-488 0 Tel. +7-095-937-3366
Fax +420-2-613-414-04 Fax +49-4102-488 270 Fax +7-095-937-3367
Unwired mobile
performance
® ®
Windows XP Professional
TM663LMi
Mobile Intel ® Centrino ™ Technology
• Intel ® Pentium ® M processor at 1.6GHz; 1024KB L2 cache; supporting Enhanced
Intel ® SpeedStep ® technology
• Intel ® 855GM chipset with 400MHz FSB
• Wireless: Integrated Intel ® PRO/Wireless 2100 network connection
® Windows ® XP Professional Edition preloaded
Hot swappable Media bay with DVD-Dual drive
™
™ suite (PlatinumPAS ™ , PlatinumSecure ™ and PlatinumKey ™ );
™ ; Adobe Acrobat ® Reader ™ ; PowerDVD; NTI CD Maker ™
