OWNER'S MANUAL
RET Series
Read all instructions carefully before use.
For any Customer Support needs please choose the
Customer Support tab on www.royalsovereign.com
Royal Sovereign International Inc.
www.royalsovereign.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RET-1500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Royal Sovereign RET-1500

  • Page 1 OWNER'S MANUAL RET Series Read all instructions carefully before use. For any Customer Support needs please choose the Customer Support tab on www.royalsovereign.com Royal Sovereign International Inc. www.royalsovereign.com...
  • Page 2: Table Of Contents

    RET Series TABLE OF CONTENTS TOPIC∙ ∙ ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ PAGE 1. INTRODUCTION∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 2. SAFETY PRECAUTIONS∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 3. PRODUCT IDENTIFICATION ∙ ∙ ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5 4. INSTALLATION∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 4.1 Electrical requirements∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙6 4.2 Box contents∙ ∙ ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙7 4.3 Assembly∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙8 5. OPERATION∙ ∙ ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙11 6.
  • Page 3: Introduction

    RET Series 1. INTRODUCTION Thank you for choosing a Royal Sovereign trimmer. It has been designed and manufactured to provide years of continuous service. For complete operating and maintenance information please read this manual thoroughly. Upon receipt of your trimmer, please inspect the box, the machine and all other contents for shipping damage.
  • Page 4 RET Series Dangerous areas and residual risks All the areas around the machine in which people are at risk of injuries or health problems are considered dangerous. Pay close attention to hands when operating the trimmer. During certain intervention procedures on the machine, which are pointed out each time in this manual, residual risks for the operator may arise.
  • Page 5: Product Identification

    RET Series 3. PRODUCT IDENTIFICATION PART NAME Left Side Cover Power Switch Feed Table Front Fabric Holder Rod Protection Plate Foot Pedal Floor Stand Waste Catcher Right Side Cover Rear Cover Activation Bar Safety Cover...
  • Page 6: Installation

    •∙Protection∙from∙atmospheric∙agents •∙Proper∙illumination •∙Temperatures∙between∙64°∙F∙and∙95°∙F •∙Amount∙of∙humidity∙from∙30%∙to∙80% 4.1 Electrical requirements Royal Sovereign recommends that a licensed electrician ensures proper power installation to your trimmer in accordance with electrical codes in your area. The trimmer should have a dedicated power line. 100V(50/60Hz),110~120V(60Hz),220V(60Hz),220~240V(50Hz) Power Supply...
  • Page 7: Box Contents∙ ∙ ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙7

    RET Series 4.2 Box contents Thoroughly inspect the parts and the unit. It is imperative that any missing parts are reported and a claim is filed with the reseller immediately upon receipt of shipment. Part Name Quantity Picture Main Trimmer Assembly Floor Stand Side Frame Floor Stand Cross Bar Owner's Manual...
  • Page 8: Assembly∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙8

    RET Series 4.3 Assembly 1. Open the box carton and remove all parts. 2. Open the tool-box. (Fig. 4-1) Fig. 4-1 This operation must be carried out by a minimum of two people 3. Attach the lower cross bar to the left floor stand side frame and right floor stand side frame using the supplied screws (M8x55).
  • Page 9 RET Series 6. Mount the support brackets for the fluorescent lamp fixture (fig. 4.6) to the back side of the upper cross bar with the supplied screws. Insert the fluorescent lamp fixture into the brackets, and insert the fluorescent bulb into the lamp fixture. (fig. 4.6) Note : For model RET-2000 and RET-2500, connect the 2 supplied lamps before inserting (fig.4.7) Fig.
  • Page 10 RET Series 8. Screw the wastecatcher square bars into the previously inserted wastecatcher holder rods, (Fig. 4-10) putting the supplied screws through the largest drilling in the square bar, so that the head of the screw sits flush within the bar itself. (Fig. 4-11) Fig.
  • Page 11: Operation∙ ∙ ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙11

    RET Series 5. OPERATION The trimmer must only be used by trained and qualified personnel. The trimmer must be used only for trimming material for which it has been designed. For recommended maximum cutting thickness see page 16. 1. The trimmer should be positioned on a level surface in an area with adequate lighting and enough work space for feeding materials.
  • Page 12: Maintenance

    RET Series 6. MAINTENANCE Standard maintenance CAUTION: Unplug the trimmer from the power outlet during any maintenance to avoid risk of electric shocks. Note: Only qualified personnel should attempt standard maintenance on the trimmer. If needed, wear gloves and use a damp cloth (alcohol) and rubber gum eraser to remove any adhesive on the cutting blade.
  • Page 13: Troubleshooting

    RET Series 7. TROUBLESHOOTING Symptoms Cause Possible Solution a. Plug the power cord into a. Power cord not plugged in appropriate position Machine won't turn on. Lamp b. Power switch is in “0” off is off, and main switch is off b.
  • Page 14: Specifications

    RET Series 8. SPECIFICATIONS 9.1 Technical information MODEL RET-1500 RET-2000 RET-2500 Power supply 100V(50/60Hz), 110~120V(60Hz), 220V(60Hz), 220~240V(50Hz) Absorbed current max 0.8A -(max 1.5A) Max cutting thickness 30mil Usable cutting length 59inch 78inch 98inch Cutting speed 6.6ft/sec Length 77.6inch 99.2inch 116.9inch Width 19.9inch Height...
  • Page 15: Warranty

    The warranty made herein is in lieu of all other warranties, expressed or implied, including any warranty or merchantability or fitness for a particular purpose. Royal Sovereign will not be liable for personal damage or personal injury (unless primarily caused by its negligence), loss of profit, or other incidental or consequential damages arising out of the use or inability to use this equipment.
