Insignia Flex NS-13T001 Quick Setup Manual

9.7" Flex™ Android Tablet NS-13T001
QUICK SETUP GUIDE
WE ARE GOING GREEN!
A copy of your User Guide is not provided in the box but is
available online. To find your manual, touch the ? icon on
your tablet. You can also go to
www.insigniaproducts.com,
click Support & Service, enter
your model number in the
Product Search field, then
click Search.
In the box
• QUICK SETUP GUIDE
• Important Information
• USB power adapter
• 30-pin to USB cable
Features
Reset
Speakers
Headphone Microphone Screen rotation lock
jack
30-pin microSD™ Volume up/
connector
card slot down button
Charging the battery
Before using your tablet for the first time, you need to charge the battery
for a minimum of eight hours.
1 Insert the 30-Pin connector into your tablet's charger port.
2 Insert the USB connector into the USB power adapter (wall charger),
then plug the USB power adapter into a power outlet to start charging
the battery. When fully charged the tablet provides approximately 6-8
hours of battery life (or 7 hours video playback) depending on usage type.
Turning on your tablet
Camera
Press the (power) button on the top, right side of your tablet. When
you turn on the tablet for the first time, you will be prompted to sign in
Ambient
to your Google account. Follow the instructions displayed on your tablet.
light sensor
Turning on Wi-Fi and connecting to a Wi-Fi access point
To use the Wi-Fi feature, you need access to a wireless access point or hotspot.
1 Touch the (applications) icon.
2 Touch the (settings) icon.
3 Touch Wi-Fi to access the list of
available networks.
4 Select the Wi-Fi network you want
to connect to. If you are prompted
to enter a password, touch the
password field.
5 When the on-screen keyboard
opens, touch the keys to enter the
password, then touch Enter .
6 Touch Connect to connect to the
wireless access point. If the
connection is successful, the
connected icon appears.
5
Power on/
off button
1
2
2
3
4
6
