ViewSonic VG2039m-LED Datasheet page 2

20" (19.5" Viewable)
Ergonomic LED Monitor
Widescreen with DisplayPort Input
Efficiency & Comfort
The VG2039m-LED is one of the great examples of an ergonomically
designed tool. Based on your height, chair and desk conditions, you can adjust
it up and down for 5.3 inches, swivel it 360°, or tilt it 20°, whatever makes you
more comfortable.
Height
Planet-Friendly Mercury-Free LED Backlighting
The LED backlight conserves up to 50%* more energy when
compared to conventional CCFL displays. LED Backlighting
also allows for a sleek and slim panel profile.
Peace of Mind
Our industry-leading pixel performance guarantee, and
our 3-year limited warranty, makes ViewSonic a market
leader in commitment to quality. ViewSonic is dedicated
t o u s i n g t h e h i g h e s t g r a d e p a n e l s a n d o ff e r s s o l i d
and reliable products.
Specifications
LCD PANEL Type
Display Area
Optimum Resolution
Brightness
Contrast Ratio
Dynamic Contrast Ratio
Viewing Angles
Response Time
Backlight
Backlight Life
Aspect Ratio
Panel Surface
INPUT Analog
Digital
Sync
Frequency
AUDIO OUTPUT Speakers
COMPATIBILITY PC
Mac
®
CONNECTOR Analog
Digital
USB
Audio
Power
POWER Voltage
Consumption
CONTROLS Basic
OSD
*Energy savings may vary based on cost, actual usage and other factors. Specifications and availability are subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic
representative for complete details.Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2013 ViewSonic Corporation. All rights reserved. [16544-00B-02/13]
Sales: (888) 881-8781 or SalesInfo@ViewSonic.com • More product information: www.ViewSonic.com
Swivel
20" (19.5" Viewable) Wide Color a-Si TFT Active Matrix LED
17.0" horizontal x 9.4" vertical; 19.5" diagonal
1600x900
250 cd/m (typ)
2
1000:1 static (typ)
20,000,000:1
170º horizontal, 160º vertical
5ms (typ.)
White-light LED
30,000 hours (min)
16:9
Anti-glare, hard-coating (3H)
RGB analog (75 ohms, 0.7 / 1.0 Vp-p)
DVI-D (TMDS, 100 ohms), Display Port
H/V separated (TTL)
Fh = 24 ~ 82 kHz ; Fv = 50 ~ 75 Hz
2 watt (x2)
VGA up to 1600x900 @ 60Hz (preferred)
Power Mac (up to 1280x1024)
15-pin mini D-sub (VGA)
DVI-D (with HDCP), DisplayPort
Type A USB (x2)
Type B USB (Upstream)
3.5mm Audio In
3.5mm Headphones
Internal Power Board, 3-pin plug (CEE22)
AC 100–240V (universal), +/-10% Wide Range
17W (typ)
Optimize: 15W (typ)
Conserve:14W (typ)
Power, 1, down, up, 2
Auto Image Adjust, Contrast/Brightness, Input Select, Audio
adjust, Audio Input, Color Adjust, Information, Manual Image
Adjust, Setup Menu, Memory Recall (See user guide for
complete OSD functionality)
VESA Mountable
100mm x 100mm
Kensington ®
Lock Slot
Tilt
USB x2
USB
Upstream
ERGONOMICS
Height Adjust
OPERATING
CONDITIONS
DIMENSIONS Physical with stand
(W x H x D) Physical without stand
WEIGHT Net with stand
Net without stand
WALL MOUNT
REGULATIONS
RECYCLE/DISPOSAL
WARRANTY
What's in the box?
VG2039m-LED monitor, power cable, VGA video cable, DVI cable, audio cable, USB cable,
Quick Start Guide, ViewSonic Wizard CD
VG2039m-LED
AC In Audio In DVI-D
Headphone DisplayPort
Tilt -5º ~ 20º
Swivel 360º
3.2" (0-80mm)
Temperature 32–104ºF (0–40ºC)
Humidity 10–90% (non-condensing)
18.4 x 15.0 x 9.8 in. / 466 x 382 x 250 mm
18.4 x 10.9 x 2.3 in. / 466 x 274 x 59 mm
Packaging 20.5 x 17.5 x 5.1 in. / 521 x 445 x 130 mm
8.1 lb. / 3.7 kg
5.8 lb. / 2.6 kg
Gross 10.6 lb. / 4.8 kg
VESA 100 x 100 mm
®
UL/cUL, FCC-B, ENERGY STAR
REACH SVHC List, RoHS, Windows 7/8
Please dispose of in accordance with local,
state or federal laws.
Three-year limited warranty on parts, labor and backlight
Menu Controls
VGA
, EPEAT Silver,
®
ViewSonic Corporation's QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
