Monitor Controls and Indicators
A
VIDEO Input Select button
A,B
B
C
D
Power Indicator & Power Button
Driver Installation
Use the monitor CD to install the appropriate monitor driver for your operating system.
Microsoft
To manually install or update the driver, perform the following steps:
1. Insert the monitor CD into the CD-ROM drive.
2. Click StartÆControl PanelÆ Appearance & Themes and then click the Display icon.
3. In the Display Properties window, click the Settings tab, and then click Advanced.
4. Click the Monitor tab, and then click PropertiesÆ Driver tabÆ Update Driver.
5. When the Hardware Update Wizard dialog box appears, choose "Install the software automatically," and click
Next> and then Finish to complete the installation.
6. Close the Display Properties window.
Microsoft
To manually install or update the driver, perform the following steps:
1. Click StartÆSettingsÆControl Panel and then double-click Display.
2. In the Display Properties window, click the Settings tab, and then click Advanced.
3. Click the Monitor tab, and then click ChangeÆSpecify the location of the driverÆNext.
4. When the Update Device Driver Wizard dialog box appears, select "Display a list of all the drivers in a specific
location, so you can select the driver you want," and click Next>.
5. Insert the monitor CD into the CD-ROM drive, then click Have Disk.
6. Type d:\ (change the drive letter to match your CD-ROM drive if it is not drive D) in the Copy manufacturer's files
from: box, then click OK.
7. Click Next>, Next>, and then Finish to complete the installation.
8. Close the Display Properties window.
2
Dell™ 1504FP Flat Panel Color Monitor Quick Setup Guide
A
buttons
Auto adjust
MENU
®
®
Windows
XP Operating System
®
®
Windows
Millennium Operating System
B
C
D
Use this button to select between two different video signals that may be
connected to your monitor.
A confirmation dialog will also be flashed on-screen indicating either
'ANALOG INPUT' or 'DIGITAL INPUT'.
Use these buttons to adjust (decrease/increase ranges) items in the OSD,
and to select sub-menus.
Use this button to activate automatic setup and adjustment.
The MENU button opens the on-screen menu (OSD), exits from menus and
sub-menus, and exits the OSD.
Use this button to open the OSD system and to activate the highlighted
function. See Accessing the Menu System.
The power indicator lights steady green, steady amber, blinking amber, or
blinking green / amber to indicate the power management state of the
monitor. See Power-saving modes.
The Power button turns the monitor on and off.
