Citrix DL385 - ProLiant - G5 Administrator's Manual

Xenserver administrator's guide 4.1.0
Hide thumbs Also See for DL385 - ProLiant - G5:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual, Manual
XenServer Administrator's Guide
4.1.0
Published March 2008
1.0 Edition
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DL385 - ProLiant - G5 and is the answer not in the manual?

Questions and answers

Related Manuals for Citrix DL385 - ProLiant - G5

Summary of Contents for Citrix DL385 - ProLiant - G5

  • Page 1 XenServer Administrator's Guide 4.1.0 Published March 2008 1.0 Edition...
  • Page 2 XenServer Administrator's Guide XenServer Administrator's Guide: Release 4.1.0 Published March 2008 Copyright © 2008 Citrix Systems, Inc. Xen®, Citrix®, XenServer™, XenCenter™ and logos are either registered trademarks or trademarks of Citrix Systems, Inc. in the United States and/or other countries. Other company or product names are for informational purposes only and may be trademarks of their respective owners.
  • Page 3 XenServer Administrator's Guide...

  • Page 4: Table Of Contents

    Table of Contents 1. Overview ........................1 1.1. XenServer Hosts and resource pools ..............1 1.2. Networking ......................1 1.3. Storage ......................1 1.4. Command Line Interface ................... 2 1.5. How this Guide relates to other documentation ........... 2 2. XenServer Hosts and resource pools ................3 2.1.
  • Page 5 XenServer Administrator's Guide 3.5.1. Sample QLogic iSCSI HBA setup ............29 3.5.2. Removing HBA-based FC or iSCSI device entries ......... 29 3.6. Virtual disk QoS settings (Enterprise Edition only) ..........29 4. Networking ........................ 31 4.1. Networking configuration performed during Host installation ....... 31 4.2.
  • Page 6 XenServer Administrator's Guide 6.2. Troubleshooting connections between XenCenter and the XenServer Host ..100 6.3. Special debug boot options ................100 Index ........................... 101...

  • Page 7: Overview

    Chapter 1. Overview This document is an administrator's guide to XenServer™, the platform virtualization solution from Citrix™. It describes the tasks involved in configuring a XenServer deployment -- in particular, how to set up storage, networking and resource pools, and how to administer XenServer Hosts using the xe command line interface (CLI).

  • Page 8: Command Line Interface

    Overview • manage and administer storage repositories 1.4. Command Line Interface The Command Line Interface chapter introduces "xe": a powerful CLI that facilitates administration of all aspects of XenServer, including host configuration, storage, networking and VMs. The CLI guide describes: •...

  • Page 9: Xenserver Hosts And Resource Pools

    Chapter 2. XenServer Hosts and resource pools A resource pool comprises multiple XenServer Host installations, bound together into a single managed entity which can host Virtual Machines. When combined with shared storage, a resource pool enables VMs to be started on any XenServer Host which has sufficient memory and then dynamically moved between XenServer Hosts while running with minimal downtime (XenMotion).

  • Page 10: Creating A Resource Pool

    XenServer Hosts and resource pools Note The requirement for a XenServer Host to have a static IP address to be part of a resource pool also applies to the servers providing the shared NFS or iSCSI storage. Although not a strict technical requirement for creating a resource pool, the advantages of pools (for exam- ple, the ability to dynamically choose on which XenServer Host to run a VM and to dynamically move a VM between XenServer Hosts) are only available if the pool has one or more shared storage repositories.

  • Page 11: Installing And Managing Vms On Shared Storage

    XenServer Hosts and resource pools xe pool-list Set the shared storage as the pool-wide default with the command xe pool-param-set uuid=pool-uuid default-SR=sr-uuid Since the shared storage has been set as the pool-wide default, all future VMs will have their disks created on shared storage by default.

  • Page 12: Backups

    XenServer Hosts and resource pools Procedure 2.4. To remove XenServer Host b from a resource pool via the CLI Open a text console on any XenServer Host in the pool. Find the UUID corresponding to XenServer Host b using the command xe host-list Command XenServer Host b to leave the pool with the command xe pool-eject host-uuid=uuid...

  • Page 13: Coping With Machine Failures

    XenServer Hosts and resource pools Note • Do not create the backup in domain 0. • This procedure may create a large backup file. • To complete a restore you may have to reboot to the original install CD. • This data can only be restored to the original machine. Procedure 2.7.

  • Page 14: Master Failures

    XenServer Hosts and resource pools When a member XenServer Host fails, there may be VMs still registered in the running state. If you are sure that the member XenServer Host is definitely down, and that the VMs have not been brought up on another XenServer Host in the pool, use the xe vm-reset-powerstate CLI command to forcibly halt the VMs.

  • Page 15: Physical Machine Failure

    XenServer Hosts and resource pools Procedure 2.10. To restore host sotfware and configuration Run the command: xe host-restore host=host file-name=hostbackup Reboot to the host installation CD and select "Restore from backup". 2.7.5. Physical Machine failure If the physical host machine has failed, use the appropriate procedure listed below to recover. Warning Any VMs which were running on a previous member (or the previous host) which has failed will still be marked as Running in the database.
  • Page 16 XenServer Hosts and resource pools xe vm-import filename=backup --metadata If the metadata import fails, run the command: xe vm-import filename=backup --metadata --force This command will attempt to restore the VM metadata on a 'best effort' basis. Restart all VMs.

  • Page 17: Storage

    Chapter 3. Storage This chapter discusses the framework for storage abstractions. It describes the way physical storage hard- ware of various kinds is mapped to VMs, and the software objects used by the XenServer Host API to per- form storage-related tasks. Detailed sections on each of the supported storage types include procedures for creating storage for VMs using the CLI, with type-specific device configuration options, and some best practices for managing storage in XenServer Host environments.

  • Page 18: Managing Storage

    Storage • The LVM format can be used on either local disk or shared storage. Shared LVM access can be provided using either an iSCSI or a Fibre Channel LUN hosted on a network filer that allows shared access by multiple initiators or HBAs.

  • Page 19: Local Disks

    Storage SR type Description Shared? Sparse? VDI Resize? Fast Clone? lvmohba Logical Volume Management over Fibre Channel or iSCSI Host Bus Adapter (HBA) lvmoiscsi Logical Volume Management over iSCSI using software initiator netapp NetApp filer using Ontap All storage repositories in XenServer are implemented as Python scripts and stored within the control domain's file system in /opt/xensource/sm.

  • Page 20: Shared Iscsi Storage

    Storage for virtual disks (VDIs). VDIs are stored in the Microsoft VHD format only. Moreover, as NFS SRs can be shared, VDIs stored in a shared SR allow VMs to be started on any XenServer Hosts in a resource pool and be migrated between them using XenMotion with no noticeable downtime.

  • Page 21: Shared Lvm Storage Over Fc Or Iscsi Hardware Hbas

    Storage Shared iSCSI support using the software iSCSI initiator is implemented based on the Linux Volume Manager (LVM) and provides the same performance benefits provided by LVM VDIs in the local disk case. Shared iSCSI SRs using the software-based host initiator are capable of supporting VM agility using XenMotion: VMs can be started on any XenServer Host in a resource pool and migrated between them with no notice- able downtime.

  • Page 22: Shared Netapp Storage

    Storage The sr-probe command should be used to list the LUN-backed SCSI devices present on the host, and will force a scan for new LUN-backed SCSI devices each time it is run. The path value returned by sr-probe for a LUN-backed SCSI device will be consistent across all hosts with access to the LUN, and therefore must be used when creating shared SRs accessible by all hosts in a resource pool.
  • Page 23 Storage There are two constraints to consider, therefore, in mapping the virtual storage objects of the XenServer Host to the filer; in to order to maintain space efficiency it makes sense to limit the number of LUNs per FlexVol, yet at the other extreme, in order to avoid resource limitations a single LUN per FlexVol provides the most flexibility.

  • Page 24: Storage Configuration Examples

    Storage which is compared to all other signatures in the data volume. If an exact block match exists, the duplicate block is discarded and the disk space reclaimed. A-SIS can be enabled on "thin provisioned" Netapp-based SRs and will operate according to the default filer A-SIS parameters, typically every 24 hours. It must be enabled at the point the SR is created and any custom A-SIS configuration managed directly on the filer.

  • Page 25: Probing An Sr

    Storage There are two basic steps involved in creating a new storage repository for use on a XenServer Host via the CLI: 1. Probe the SR type to determine values for any required parameters. 2. Create the SR to create the SR object and associated PBD objects, plug the PBDs, and activate the SR. These steps differ in detail depending on type of SR being created.
  • Page 26 Storage # xe sr-probe type=lvmoiscsi device-config:target=192.168.1.10 device-config:targetIQN=iqn.192.168.1.10:filer1 Error code: SR_BACKEND_FAILURE_107 Error parameters: , The SCSIid parameter is missing or incorrect, \ <?xml version="1.0" ?> <iscsi-target> <LUN> <vendor> </vendor> <LUNid> </LUNid> <size> 42949672960 </size> <SCSIid> 149455400000000000000000002000000b70200000f000000 </SCSIid> </LUN> </iscsi-target> Probing the same target and supplying all three parameters will return a list of SRs that exist on the LUN, if any.

  • Page 27: Creating A Local Lvm Sr (Lvm)

    Storage SR type device-config Can be probed? Required for sr-create? parameter, in order of dependency username password chapuser chappassword aggregate FlexVols allocation asis server serverpath device device 3.3.3. Creating a local LVM SR (lvm) Device-config parameters for lvm SRs are: Parameter Name Description Required...

  • Page 28: Creating A Shared Lvm Over Iscsi Sr Using The Software Iscsi Initiator (Lvmoiscsi)

    Storage Parameter Name Description Required server IP address or hostname of the NFS server serverpath path, including the NFS mount point, on the NFS server in which the SR will reside To create a shared nfs SR on 192.168.1.10:/export1 use the following command. xe sr-create host-uuid=<VALID_UUID>...
  • Page 29 Storage To create a shared lvmohba SR perform the following steps on each host in the pool: 1. Zone in one or more LUNs to each XenServer Host in the pool. This process is highly specific to the SAN equipment in use. Please refer to the documentation for your SAN or contact your storage administrator for details.
  • Page 30 Storage # xe sr-probe type=lvmohba \ host-uuid=1212c7b3-f333-4a8d-a6fb-80c5b79b5b31 Error code: SR_BACKEND_FAILURE_90 Error parameters: , The request is missing the device parameter, \ <?xml version="1.0" ?> <Devlist> <BlockDevice> <path> /dev/disk/by-id/scsi-360a9800068666949673446387665336f </path> <vendor> HITACHI </vendor> <serial> 730157980002 </serial> <size> 80530636800 </size> <adapter> </adapter> <channel>...

  • Page 31: Creating A Shared Netapp Sr Over Iscsi

    Storage Note The Repair Storage Repository function within XenCenter can be used to retry the PBD creation and plugging portions of the sr-create operation. This can be valuable in cases where the LUN zoning was incorrect for one or more member servers in a pool when the SR was created. Correct the zoning for the affected hosts and use Repair Storage Repository instead of removing and re- creating the SR.

  • Page 32: Introducing A Sr

    Storage 2. To destroy the SR, which deletes both the SR and corresponding PBD from the XenServer Host database and deletes the SR contents from the physical media: xe sr-destroy uuid=<SR_UUID> 3. Or, to forget the SR, which removes the SR and corresponding PBD from the XenServer Host database but leaves the actual SR contents intact on the physical media: xe sr-forget uuid=<SR_UUID>...

  • Page 33: Moving Virtual Disk Images (Vdis) Between Srs

    Storage 1. Upgrade all hosts in the resource pool to XenServer 4.1. 2. Ensure all hosts in the pool have the SR's LUN zoned appropriately. See Section 3.3.2, “Probing an SR ” for details on using sr-probe to verify the LUN is present on each host. 3.

  • Page 34: Managing Vdis In A Netapp Sr

    Storage 5. Within XenCenter select the VM's storage tab. Use the Attach button and select the VDIs from the new SR. This step can also be done use the vbd-create CLI command. 6. To delete the original VDIs, within XenCenter select the storage tab of the original SR. The original VDIs will be listed with an empty value for the VM field and can be deleted with the Delete button.

  • Page 35: Sample Qlogic Iscsi Hba Setup

    Storage 3.5.1. Sample QLogic iSCSI HBA setup For full details on configuring QLogic Fibre Channel and iSCSI HBAs please refer to the QLogic website. Once the HBA is physically installed into the XenServer Host use the following steps to configure the HBA: 1.
  • Page 36 Storage Note also that in the shared SR case i.e. where multiple hosts are accessing the same LUN, the QoS is applied to VBDs accessing the LUN from the same host, i.e. QoS is not applied across hosts in the pool. Note that QoS settings will not have any effect on VHD-based storage types.

  • Page 37: Networking

    Chapter 4. Networking This chapter discusses how physical network interface cards (NICs) in XenServer Hosts are used to enable networking within Virtual Machines (VMs). XenServer supports up to 4 physical NICs per XenServer Host and up to 7 virtual network interfaces (VIFs) per VM. XenServer 4.1 provides automated configuration and management of NICs via the xe command line inter- face (CLI).

  • Page 38: Managing Networking Configuration For Standalone Xenserver Hosts

    Networking When a host has multiple NICs the configuration present after installation depends on which NIC is selected for management operations during installation: • PIFs are created for each NIC in the host • the PIF of the NIC selected for use as the management interface is configured with the IP addressing options specified during installation •...

  • Page 39: Connecting Virtual Machines (Vms) To Networks

    Networking 4.2.2. Connecting Virtual Machines (VMs) to networks When a new VM is created via the CLI, it does not contain a virtual network interface (VIF). Adding a VIF and connecting it to the desired network must be done as additional steps. When creating VMs using XenCenter, the New VM wizard contains a page allowing creation of virtual network interfaces.

  • Page 40: Creating Nic Bonds

    Networking xe pif-list Create a VLAN object specifying the desired physical PIF and VLAN tag. A new PIF will be created and plugged into the specified network. The UUID of the new PIF object is returned. xe vlan-create network-uuid=<network UUID> pif-uuid=<PIF UUID> vlan=5 Attach VM VIFs to the new network.
  • Page 41 Networking xe pif-list Use the bond-create command to create the bond by specifying the newly created network UUID and the UUIDs of the PIFs to be bonded separated by commas. The UUID for the bond is returned: xe bond-create network-uuid=<network UUID> pif-uuids=<PIF UUID 1>,<PIF UUID 2> Note See Section 4.2.4.2, “Controlling the MAC address of the bond”...

  • Page 42: Controlling Quality Of Service (Qos)

    Networking the MAC address of the bond should be the same as the PIF/NIC currently in use, allowing the IP address of the host received from DHCP to remain unchanged. The MAC address of the bond can be changed from PIF/NIC currently in use for the management interface, but doing so will cause existing network sessions to the host to be dropped when the bond is enabled and the MAC/IP address in use changes.

  • Page 43: Changing Networking Configuration Options

    Networking Once storage resources are available via the NIC, create the appropriate storage repositories. To change an unmanaged NIC to managed, use the pif-introduce command. Note Use of the pif-scan command will reset all NICs on the host to managed. 4.2.7.

  • Page 44: Managing Networking Configuration For Xenserver Pools

    Networking xe pif-list Use the pif-param-list command to verify the IP addressing configuration for the PIF that will be used for the management interface. If necessary, use the pif-reconfigure-ip command to configure IP ad- dressing for the PIF to be used. See Chapter 5, Command line interface for more detail on the options available for the pif-reconfigure-ip command.
  • Page 45 Networking 4.3.2.1. Adding NIC bonds to new resource pools Install the master host and use XenCenter to create the pool. Create the NIC bond on the master as follows: Use the network-create command to create a new pool-wide network for use with the bonded NICs.
  • Page 46 Networking xe host-management-reconfigure pif-uuid=<bond PIF UUID> Use the pif-reconfigure-ip command to remove the IP address configuration from the non-bonded PIF previously used for the management interface. This step is not strictly necessary but might help reduce confusion when reviewing the host networking configuration. xe pif-reconfigure-ip uuid=<old mgmt PIF UUID>...
  • Page 47 Networking xe pif-reconfigure-ip uuid=<old mgmt PIF UUID> mode=None For each member server, join it to the pool and repeat 3 and 4 to move the management interface on the member server to enable the bond. 4.3.2.2. Adding NIC bonds to an existing pool When adding a NIC bond to an existing pool, the bond must be manually created on each host in the pool.

  • Page 48: Changing Xenserver Host Ip Address Configuration In Resource Pools

    Networking xe bond-create network-uuid=<network UUID> pif-uuids=<PIF UUID 1>,<PIF UUID 2> Note See Section 4.2.4.2, “Controlling the MAC address of the bond” for details on controlling the MAC address used for the bond PIF. Use the pif-list command to determine the UUID of the new bond PIF. Include the host-uuid param- eter to list only the PIFs on the host being configured: xe pif-list device=bond0 host-uuid=<host UUID>...

  • Page 49: Nic/Pif Ordering

    Networking Procedure 4.8. To change the IP address of a pool member host: Use the pif-reconfigure-ip CLI command to set the IP address as desired. See Chapter 5, Command line interface for details on the parameters of the pif-reconfigure-ip command: xe pif-reconfigure-ip uuid=<PIF UUID>...
  • Page 50 Networking xe pif-list params=uuid,device,MAC,currently-attached,carrier,management, \ IP-configuration-mode uuid ( RO) : 1ef8209d-5db5-cf69-3fe6-0e8d24f8f518 device ( RO): eth0 MAC ( RO): 00:19:bb:2d:7e:8a currently-attached ( RO): true management ( RO): true IP-configuration-mode ( RO): DHCP carrier ( RO): true uuid ( RO) : 829fd476-2bbb-67bb-139f-d607c09e9110 device ( RO): eth1 MAC ( RO): 00:19:bb:2d:7e:7a currently-attached ( RO): false...

  • Page 51: Networking Troubleshooting

    Networking xe pif-forget uuid=1ef8209d-5db5-cf69-3fe6-0e8d24f8f518 xe pif-forget uuid=829fd476-2bbb-67bb-139f-d607c09e9110 Use the pif-introduce command to re-introduce the devices with the desired naming: xe pif-introduce device=eth0 host-uuid=<host UUID> mac=00:19:bb:2d:7e:7a xe pif-introduce device=eth1 host-uuid=<host UUID> mac=00:19:bb:2d:7e:8a Use the pif-list command again to verify the new configuration: xe pif-list params=uuid,device,MAC Use the pif-reconfigure-ip command to reset the management interface IP addressing configuration.

  • Page 52: Recovering From A Bad Network Configuration

    Networking $ xe pif-param-set uuid=<pif-uuid> other_config:ethtool-tx=off Finally, re-plug the PIF or reboot the host for the change to take effect. 4.4.2. Recovering from a bad network configuration In some cases it is possible to render networking unusable by creating an incorrect configuration. This is particularly true when attempting to make network configuration changes on a member XenServer Host.

  • Page 53: Command Line Interface

    Chapter 5. Command line interface This chapter describes the XenServer command line interface (CLI). The xe CLI enables the writing of scripts for automating system administration tasks and allows integration of XenServer into an existing IT infrastructure. The xe command line interface is installed by default on XenServer Hosts and is included with XenCenter. A stand-alone remote CLI is also available for Linux.

  • Page 54: Special Characters And Syntax

    Command line interface Shorthand syntax is also available for remote connection arguments: username password -pwf password file port server Example: On a remote XenServer Host: xe vm-list -u myuser -pw mypassword -s hostname Arguments are also taken from the environment variable XE_EXTRA_ARGS, in the form of comma-separated key/value pairs.

  • Page 55: Command Types

    Command line interface 5.3. Command types Broadly speaking, the CLI commands can be split in two halves: Low-level commands concerned with listing and parameter manipulation of API objects, and higher level commands for interacting with VMs or hosts in a more abstract level. The low-level commands are: •...

  • Page 56: Parameter Types

    Command line interface Note that not every value of class has the full set of class-param- commands; some have just a subset. 5.3.1. Parameter types The objects that are addressed with the xe commands have sets of parameters that identify them and define their states.

  • Page 57: Low-Level List Commands

    Command line interface Lists all of the parameters and their associated values. Unlike the class-list command, this will list the values of 'expensive' fields. • [class]-param-get uuid=uuid param-name=parameter [param-key=key ] Returns the value of a particular parameter. If the parameter is a map, specifying the param-key will get the value associated with that key in the map.

  • Page 58: Xe Command Reference

    Command line interface xe vm-list HVM-boot-policy="BIOS order" power-state=halted will only list those VMs for which both the field [power-state] has the value halted, and for which the field [HVM-boot-policy] has the value BIOS order. It is also possible to filter the list based on the value of keys in maps, or on the existence of values in a set. The syntax for the first of these is map-name:key=value, and the second is set-name:contains=value For scripting, a useful technique is passing [--minimal] on the command line, causing xe to print only the first field in a comma-separated list.

  • Page 59: Cd Commands

    Command line interface Delete a bonded interface specified by its UUID from the XenServer Host. 5.4.2. CD commands Commands for working with physical CD/DVD drives on XenServer Hosts. CD parameters CDs have the following parameters: Parameter Name Description Type uuid unique identifier/object reference for the read only name-label...

  • Page 60: Console Commands

    Command line interface Parameter Name Description Type managed true if the device is managed read only xenstore-data Data to be inserted into the xenstore tree read only map parameter sm-config names and descriptions of storage read only map parameter manager device config keys 5.4.2.1.

  • Page 61: Host (Xenserver Host) Commands

    Command line interface Event classes Event classes are listed in the following table: Class name Description pool A pool of physical hosts A Virtual Machine host A physical host network A virtual network A virtual network interface A physical network interface (note separate VLANs are represented as several PIFs) A storage repository A virtual disk image...
  • Page 62 Command line interface Host selectors Several of the commands listed here have a common mechanism for selecting one or more XenServer Hosts on which to perform the operation. The simplest is by supplying the argument host=<UUID or name- label>. XenServer Hosts can also be specified by filtering the full list of hosts on the values of fields. For example, specifying enabled=true will select all XenServer Hosts whose enabled field is equal to true.
  • Page 63 Command line interface Parameter Name Description Type memory-total total amount of physical RAM on the read only XenServer Host, in bytes memory-free total amount of physical RAM remaining read only that can be allocated to VMs, in bytes host-metrics-last-updated Timestamp of the date and time that the read only metrics for a XenServer Host were read, in the form yyyymmddThh:mm:ss z, where...
  • Page 64 Command line interface Parameter Name Description Type uuid The unique identifier/object reference for read only the crashdump host XenServer Host the crashdump read only corresponds to timestamp Timestamp of the date and time that read only the crashdump occurred, in the form yyyymmdd-hhmmss-ABC, where ABC is the timezone indicator, for example, GMT size...
  • Page 65 Command line interface Upload a crashdump to the Citrix Support ftp site or other location. If optional parameters are not used, no proxy server is identified and the destination will be default Citrix Support ftp site. Optional parameters are http-proxy: use specified http proxy, and url: upload to this destination url. 5.4.5.5.
  • Page 66 Command line interface The xapi agent forgets about the specified XenServer Host without contacting it explicitly. This command is useful if the XenServer Host to "forget" is dead; however, if the XenServer Host is live and part of the pool, you should use xe pool-eject instead. 5.4.5.11.
  • Page 67 Command line interface Attribute Description Indicate an approximate range for the time, in seconds, taken to collect this entry. -1 indicates the time is unimportant. Personally identifiable information. Indicates whether the entry would have information that would identify the system owner, or details of their network topology. This is one of: •...
  • Page 68 Command line interface The host(s) on which this operation should be performed are selected via the standard selection mecha- nism (see host selectors above). Optional arguments can be any number of the host selectors listed at the beginning of this section. Caution While the xe host-logs-download command will work if executed on the local host (that is, without a specific hostname specified), do not use it this way.

  • Page 69: Log Commands

    Command line interface and the master will continue to function. If you shut down the master, the pool will be out of action until the master is rebooted and back on line, at which point the members will reconnect and synchronize with the master, or until you make one of the members into the master.

  • Page 70: Network Commands

    Command line interface 5.4.6.1. log-get-keys log-get-keys List the keys of all of the logging subsystems. 5.4.6.2. log-reopen log-reopen Reopen all loggers. Use this for rotating log files. 5.4.6.3. log-set-output log-set-output output=nil | stderr | file:filename | syslog:sysloglocation [key=key ] [level= debug | info | warning | error] Set the output of the specified logger.

  • Page 71: Patch (Update) Commands

    Command line interface Parameter Name Description Type other-config A list of key/value pairs that specify read/write map parameter additional configuration parameters for the network. 5.4.7.1. network-create network-create name-label=name for network [name-description=descriptive text ] Creates a new network. 5.4.7.2. network-destroy network-destroy uuid=network UUID Destroys an existing network.

  • Page 72: Pbd Commands

    Command line interface Delete the specified patch file from the XenServer Host. 5.4.8.3. patch-pool-apply patch-pool-apply uuid=patch UUID Apply the specified patch to all XenServer Hosts in the pool. 5.4.8.4. patch-precheck patch-precheck uuid=patch UUID host-uuid=host UUID Run the prechecks contained within the specified patch on the specified XenServer Host. 5.4.8.5.

  • Page 73: Pif Commands

    Command line interface Create a new PBD on a XenServer Host. The read-only device-config parameter can only be set on creation as in the following example: To add a mapping of 'path' -> '/tmp', the command line should contain the argument de- vice-config:path=/tmp For a full list of supported device-config key/value pairs on each SR type see Chapter 3, Storage.
  • Page 74 Command line interface Parameter Name Description Type VLAN VLAN tag for all traffic passing through read only this interface; -1 indicates no VLAN tag is assigned bond-master-of The UUID of the bond this PIF is the read only master of (if any) bond-slave-of The UUID of the bond this PIF is the slave read only...

  • Page 75: Pool Commands

    Command line interface Parameter Name Description Type pif-metrics-last-updated Timestamp of the date and time that the read only metrics for this PIF were read, in the form yyyymmddThh:mm:ss z, where z is the single-letter military timezone indicator, for example, Z for UTC (GMT) other-config additional configuration read/write map parameter...
  • Page 76 Command line interface another XenServer Host in the pool. Each XenServer Host is really a pool consisting of a single member by default. When a XenServer Host is joined to a pool, it is designated as a member, and the pool it has joined becomes the master for the pool.

  • Page 77: Storage Manager Commands

    Command line interface Instruct the specified XenServer Host to leave an existing pool. 5.4.11.4. pool-emergency-reset-master pool-emergency-reset-master master-address=address of the pool's master XenServer Host Instruct a member XenServer Host to reset its master address. 5.4.11.5. pool-emergency-transition-to-master pool-emergency-transition-to-master Instruct a member XenServer Host to become the pool master. This command is only accepted by the XenServer Host if it has transitioned to emergency mode, meaning it is a member of a pool whose master has disappeared from the network and could not be contacted for some number of retries.

  • Page 78: Sr Commands

    Command line interface The storage manager objects can be listed with the standard object listing command (xe sm-list), and the parameters manipulated with the standard parameter commands. See Section 5.3.2, “Low-level param commands” for details. SM parameters SMs have the following parameters: Parameter Name Description Type...
  • Page 79 Command line interface Parameter Name Description Type PBDs unique identifier/object reference for the read only set parameter PBDs attached to this SR physical-utilisation physical space currently utilized on this read only SR, in bytes. Note that for sparse disk formats, physical utilisation may be less than virtual allocation physical-size total physical size of the SR, in bytes...

  • Page 80: Task Commands

    Command line interface 5.4.13.4. sr-introduce sr-introduce name-label=name physical-size=physical size type=type content-type=content- type uuid=SR UUID Just places an SR record into the database. The device-config parameters are specified by de- vice-config:parameter_key=parameter_value (for example, device-config:device=/dev/sdb1). Note This command is never used in normal operation. It is an advanced operation which might be useful if an SR needs to be reconfigured as shared after the fact, or to help recover from various failure scenarios.

  • Page 81: Template Commands

    Command line interface Parameter Name Description Type name-description The description string of the Task read only resident-on The unique identifier/object reference of read only the host on which the task is running status current status of the Task read only progress if the Task is still pending, this field read only...
  • Page 82 Command line interface Template parameters Templates have the following parameters: Parameter Name Description Type uuid The unique identifier/object reference for read only the template name-label The name of the template read/write name-description The description string of the template read/write user-version string for creators of VMs and templates to read/write put version information...
  • Page 83 Command line interface Parameter Name Description Type You can tune a VCPU's pinning with xe vm-param-set uuid=<VM UUID> VCPUs-params:mask=1,2,3 A VM created from this template will then run on physical CPUs 1, 2, and 3 only. You can also tune the VCPU priority (xen scheduling) with the cap and weight parameters;...
  • Page 84 Command line interface Parameter Name Description Type allowed-VIF-devices list of VIF identifiers available for use, read only set parameter represented by integers of the range 0-15. This list is informational only, and other devices may be used (but may not work). HVM-boot-policy read/write HVM-boot-params...
  • Page 85 Command line interface Parameter Name Description Type 1970 Z (beginning of Unix/POSIX epoch) for a template memory-actual The actual memory being used by a VM read only based on this template; 0 for a template VCPUs-number The number of virtual CPUs assigned read only to a VM based on this template;...

  • Page 86: Update Commands

    Command line interface Parameter Name Description Type possible-hosts list of hosts that could potentially host the read only HVM-shadow-multiplier multiplier applied to the amount of shadow read/write that will be made available to the guest dom-id domain ID (if available, -1 otherwise) read only recommendations An XML specification of recommended...
  • Page 87 Command line interface VBD parameters VBDs have the following parameters: Parameter Name Description Type uuid The unique identifier/object reference for read only the VBD vm-uuid The unique identifier/object reference for read only the VM this VBD is attached to vm-name-label The name of the VM this VBD is attached read only vdi-uuid...
  • Page 88 Command line interface Parameter Name Description Type links each of the running tasks using this object (by reference) to a current_operation enum which describes the nature of the task. unpluggable true if this VBD will support hot-unplug read/write attachable true if the device can be attached read only other-config additional configuration...

  • Page 89: Vdi Commands

    Command line interface 5.4.19. VDI commands Commands for working with VDIs (Virtual Disk Images). A VDI is a software object that represents the contents of the virtual disk seen by a VM, as opposed to the VBD, which is a connector object that ties a VM to the VDI. The VDI has the information on the physical attributes of the virtual disk (which type of SR, whether the disk is shareable, whether the media is read/ write or read only, and so on), while the VBD has the attributes which tie the VDI to the VM (is it bootable, its read/write metrics, and so on).
  • Page 90 Command line interface Parameter Name Description Type location location information read only managed true if the CDI is managed read only xenstore-data data to be inserted into the xenstore tree read only map parameter (/local/domain/0/backend/vbd/<domid>/ <device-id>/sm-data) after the VDI is attached.

  • Page 91: Vif Commands

    Command line interface 5.4.19.5. vdi-forget vdi-forget uuid=UUID of VDI Unconditionally removes a VDI record from the database without touching the storage backend. In normal operation, you should be using vdi-destroy instead. 5.4.19.6. vdi-import vdi-import uuid=UUID of VDI filename=filename of raw VDI Import a raw VDI.
  • Page 92 Command line interface The VIF objects can be listed with the standard object listing command (xe vif-list), and the parameters manipulated with the standard parameter commands. See Section 5.3.2, “Low-level param commands” for details. VIF parameters VIFs have the following parameters: Parameter Name Description Type...

  • Page 93: Vlan Commands

    Command line interface Parameter Name Description Type single-letter military timezone indicator, for example, Z for UTC (GMT) 5.4.20.1. vif-create vif-create vm-uuid=UUID of the VM device=see below network-uuid=UUID of the network the VIF will connect to [mac=MAC address ] Create a new VIF on a VM. Appropriate values for the device field are listed in the parameter allowed-VIF-devices on the spec- ified VM.
  • Page 94 Command line interface VM selectors Several of the commands listed here have a common mechanism for selecting one or more VMs on which to perform the operation. The simplest way is by supplying the argument vm=name or uuid . VMs can also be specified by filtering the full list of VMs on the values of fields.
  • Page 95 Command line interface Parameter Name Description Type suspend-VDI-uuid The VDI that a suspend image is stored on read only VCPUs-params configuration parameters for the selected read/write map parameter VCPU policy. You can tune a VCPU's pinning with xe vm-param-set uuid=<VM UUID> VCPUs-params:mask=1,2,3 The selected VM will then run on physical CPUs 1, 2, and 3 only.
  • Page 96 Command line interface Parameter Name Description Type destroy (no coredump and leave VM halted). console-uuids virtual console devices read only set parameter platform platform-specific configuration read/write map parameter allowed-operations list of the operations allowed in this state read only set parameter current-operations A list of the operations that are currently in read only set parameter...
  • Page 97 Command line interface Parameter Name Description Type config parameter includes the key/value pair auto_poweron: true start-time Timestamp of the date and time that the read only metrics for the VM were read, in the form yyyymmddThh:mm:ss z, where z is the single-letter military timezone indicator, for example, Z for UTC (GMT) install-time...
  • Page 98 Command line interface Parameter Name Description Type z, where z is the single-letter military timezone indicator, for example, Z for UTC (GMT) actions-after-shutdown action to take after the VM has shutdown read/write actions-after-reboot action to take after the VM has rebooted read/write possible-hosts potential hosts of this VM...
  • Page 99 Command line interface Lists CDs attached to the specified VMs. The VM or VMs on which this operation should be performed are selected via the standard selection mech- anism (see VM selectors). Optional arguments can be any number of the VM parameters listed at the be- ginning of this section.
  • Page 100 Command line interface Copy an existing VM, but without using storage-level fast disk clone operation (even if this is available). The disk images of the copied VM are guaranteed to be "full images" - that is, not part of a copy-on-write (CoW) chain.
  • Page 101 Command line interface The VM or VMs on which this operation should be performed are selected via the standard selection mech- anism (see VM selectors). Optional arguments can be any number of the VM parameters listed at the be- ginning of this section. 5.4.22.13.
  • Page 102 Command line interface Note The older directory-based XVA format does not fully preserve all the VM attributes. In particular, imported VMs will not have any virtual network interfaces attached by default. If networking is re- quired, create one using vif-create and vif-plug. If the metadata is [true], then a previously exported set of metadata can be imported without their associated disk blocks.
  • Page 103 Command line interface 5.4.22.20. vm-reboot vm-reboot [ vm-selector=vm selector value...] [force=true ] Reboot the specified VMs. The VM or VMs on which this operation should be performed are selected via the standard selection mech- anism (see VM selectors). Optional arguments can be any number of the VM parameters listed at the be- ginning of this section.
  • Page 104 Command line interface Start the specified VMs. The VM or VMs on which this operation should be performed are selected via the standard selection mech- anism (see VM selectors). Optional arguments can be any number of the VM parameters listed at the be- ginning of this section.

  • Page 105: Troubleshooting

    Chapter 6. Troubleshooting If you experience odd behavior, application crashes, or have other issues with a XenServer Host, this chapter is meant to help you solve the problem if possible and, failing that, describes where the application logs are located and other information that can help your Citrix Solution Provider and Citrix track and resolve the issue.

  • Page 106: Troubleshooting Connections Between Xencenter And The Xenserver Host

    Troubleshooting and aggregate them correctly. The syslogd daemon is a standard part of all flavors of Linux and Unix, and third-party versions are available for Windows and other operating systems. Procedure 6.1. To write logs to a remote server Set the syslog_destination parameter to the hostname or IP address of the remote server where you want the logs to be written: xe host-param-set uuid=<XenServer Host UUID>...

  • Page 107: Index

    Index FlexVol, NetApp, 16 Hardware virtualization AMD-V, 3 AMD-V (AMD hardware virtualization), 3 Intel VT, 3 HBA (see Host bus adapter) Host (XenServer Host) commands, xe CLI, 55 CD commands, xe CLI, 53 Host bus adapter, 15 CLI (see command line interface) Command line interface (CLI) basic xe syntax, 47 Intel VT (Intel hardware virtualization), 3...
  • Page 108 Index requirements for creating, 3 CD commands, 53 command types, 49 console commands, 54 event commands, 54 SAN (see Storage Area Network) host (XenServer Host) commands, 55 Shared network attached storage (NFS), 13 log commands, 63 Shared storage, 4 low-level list commands, 51 Storage Area Network, 14 low-level parameter commands, 50 Storage Manager commands, xe CLI, 71...
