- Page 1 IdeaTab S2110A Hardware Maintenance Manual...
- Page 2 First Edition (September 2011) © Copyright Lenovo 2011. All rights reserved. LENOVO products, data, computer software, and services have been developed exclusively at private expense and are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure.
-
Page 3: Table Of Contents
Checking the battery pack ......22 Related service information .......23 Passwords............23 Power settings............ 23 Turning Screen Backlight On/Off .... 23 Lenovo IdeaTab S2110A......24 Specifications ............. 24 FRU replacement notices........26 Screw notices..........26 Removing and replacing an FRU....27 1010 Battery pack......... -
Page 4: About This Manual
This manual is intended only for trained servicers who are familiar with Lenovo products. Use this manual to troubleshoot problems effectively. Before servicing a Lenovo product, make sure to read all the information under “Safety information” on page 1 and “Important service information”... -
Page 5: Safety Information
Safety information Safety information This chapter presents the following safety information that you need to get familiar with before you service a Lenovo computer: • “General safety” on page 2 • “Electrical safety” on page 3 • “Safety inspection guide” on page 5 •... -
Page 6: General Safety
Lenovo IdeaTab S2110A Hardware Maintenance Manual General safety Follow these rules below to ensure general safety: • Observe a good housekeeping in the area where the machines are put during and after the maintenance. • When lifting any heavy object: 1. -
Page 7: Electrical Safety
Safety information Electrical safety Observe the following rules when working on electrical equipments. Important: Use only approved tools and test equipments. Some hand tools have handles covered with a soft material that does not insulate you when working with live electrical currents. Many customers have rubber floor mats near their machines that contain small conductive fibers to decrease electrostatic discharges. - Page 8 Lenovo IdeaTab S2110A Hardware Maintenance Manual • Always look carefully for possible hazards in your work area. Examples of these hazards are moist floors, nongrounded power extension cables, power surges, and missing safety grounds. • Do not touch live electrical circuits with the reflective surface of a plastic dental mirror.
-
Page 9: Safety Inspection Guide
4. Check for cracked or bulging batteries. 5. Remove the cover. 6. Check for any obvious non-Lenovo alterations. Use good judgment as to the safety of any non-Lenovo alterations. 7. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage. -
Page 10: Handling Devices That Are Sensitive To Electrostatic Discharge
Lenovo IdeaTab S2110A Hardware Maintenance Manual Handling devices that are sensitive to electrostatic discharge Any computer part containing transistors or integrated circuits (ICs) should be considered sensitive to electrostatic discharge (ESD). ESD damage can occur when there is a difference in charge between objects. Protect against ESD damage by equalizing the charge so that the machine, the part, the work mat, and the person handling the part are all at the same charge. -
Page 11: Safety Notices: Multilingual Translations
Safety information Safety notices: multilingual translations The safety notices in this section are provided in English, French, German, Hebrew, Italian, Japanese, and Spanish. Safety notice 1 Before the computer is powered on after FRU replacement, make sure all screws, springs, and other small parts are in place and are not left loose inside the computer. - Page 12 Lenovo IdeaTab S2110A Hardware Maintenance Manual Safety notice 2 DANGER Some standby batteries contain a small amount of nickel and cadmium. Do not disassemble a standby battery, recharge it, throw it into fire or water, or short-circuit it. Dispose of the battery as required by local ordinances or regulations.
- Page 13 Safety information Safety notice 3 DANGER The battery pack contains small amounts of nickel. Do not disassemble it, throw it into fire or water, or short-circuit it. Dispose of the battery pack as required by local ordinances or regulations. Use only the battery in the appropriate parts listing when replacing the battery pack.
- Page 14 Lenovo IdeaTab S2110A Hardware Maintenance Manual Safety notice 4 DANGER The lithium battery can cause a fire, an explosion, or a severe burn. Do not recharge it, remove its polarized connector, disassemble it, heat it above 100°C (212°F), incinerate it, or expose its cell contents to water. Dispose of the battery as required by local ordinances or regulations.
- Page 15 Safety information Safety notice 5 If the LCD breaks and the fluid from inside the LCD gets into your eyes or on your hands, immediately wash the affected areas with water at least for 15 minutes. Seek medical care if any symptoms caused by the fluid are present after washing.
- Page 16 Lenovo IdeaTab S2110A Hardware Maintenance Manual Safety notice 6 DANGER To avoid shock, do not remove the plastic cover that protects the lower part of the inverter card. Afin d’éviter tout risque de choc électrique, ne retirez pas le cache en plastique protégeant la partie inférieure de la carte d’alimentation.
- Page 17 Safety information Safety notice 8 DANGER Before removing any FRU, turn off the computer, unplug all power cords from electrical outlets, remove the battery pack, and then disconnect any interconnecting cables. Avant de retirer une unité remplaçable en clientèle, mettez le système hors tension, débranchez tous les cordons d’alimentation des socles de prise de courant, retirez la batterie et déconnectez tous les cordons d’interface.
-
Page 18: Laser Compliance Statement
Lenovo IdeaTab S2110A Hardware Maintenance Manual Laser compliance statement Some models of Lenovo computer are equipped from the factory with an optical storage device such as a CD-ROM drive or a DVD-ROM drive. Such devices are also sold separately as options. If one of these drives is installed, it is certified in the U.S. - Page 19 Safety information A CD-ROM drive, a DVD-ROM drive, or any other storage device installed may contain an embedded Class 3A or Class 3B laser diode. Note the following: DANGER Emits visible and invisible laser radiation when open. Do not stare into the beam, do not view directly with optical instruments, and avoid direct exposure to the beam.
-
Page 20: Important Service Information
To download software fixes, drivers, and BIOS, follow the steps below: 1. Go to http://consumersupport.lenovo.com/. 2. Enter a serial number or select a product or use Lenovo smart downloading. 3. Select the BIOS/Driver/Applications and download. 4. Follow the directions on the screen and install the necessary software. -
Page 21: Important Notice For Replacing A System Board
Important service information Use the following strategy to prevent unnecessary expense for replacing and servicing FRUs: • If you are instructed to replace an FRU, but the replacement does not solve the problem, reinstall the original FRU before you continue. •... -
Page 22: Important Information About Replacing Rohs Compliant Frus
Electronic Equipment Directive (2002/95/EC) is a European Union legal requirement affecting the global electronics industry. RoHS requirements must be implemented on Lenovo products placed on the market after June 2006. Products on the market before June 2006 are not required to have RoHS compliant parts. -
Page 23: General Checkout
General checkout General checkout This chapter presents the following information: • “What to do first” on page 20 • “Power system checkout” on page 21 Before you go to the checkout, make sure to read the following important notes: Important notes: •... -
Page 24: What To Do First
Lenovo IdeaTab S2110A Hardware Maintenance Manual What to do first When you do return an FRU, you must include the following information in the parts exchange form or parts return form that you attach to it: 1. Name and phone number of servicer 2. -
Page 25: Power System Checkout
4. If the voltage is acceptable, do the following: • Replace the system board. • If the problem continues, go to “Lenovo IdeaTab S2110A” on page 24. Note: Noise from the AC adapter does not always indicate a defect. Checking operational charging... -
Page 26: Checking The Battery Pack
Lenovo IdeaTab S2110A Hardware Maintenance Manual Perform operational charging. If the battery status indicator or icon does not light on, remove the battery pack and let it return to room temperature. Reinstall the battery pack. If the charge indicator or icon is still off, replace the battery pack. -
Page 27: Related Service Information
Related service information Related service information This chapter presents the following information: • “Passwords” on page 23 • “Power settings” on page 23 Passwords With this option, you can decide whether or not your chosen password will be visible as you input it. If the checkbox is checked, then the password will be visible. -
Page 28: Lenovo Ideatab S2110A
• “FRU replacement notices” on page 26 • “Removing and replacing an FRU” on page 27 • “Locations” on page 35 • “Parts list” on page 38 Specifications The following table lists the specifications of the Lenovo IdeaTab S2110A: Table 1. Specifications Feature Description Form Factor Size •... - Page 29 Lenovo IdeaTab S2110A Table 1. Specifications (continued) Feature Description MODEM slot • N/A Audio • HD Audio 5.1 channel supported via HDMI output WLAN • Tan 802.11 b/g/n & combo • Atheros b/g/n • On select models Bluetooth • BT2.1 + EDR Camera •...
-
Page 30: Fru Replacement Notices
This section presents notices related to removing and replacing parts. Read this section carefully before replacing any FRU. Screw notices Loose screws can cause a reliability problem. In the Lenovo computer, this problem is addressed with special nylon-coated screws that have the following characteristics: •... -
Page 31: Removing And Replacing An Fru
Lenovo IdeaTab S2110A Removing and replacing an FRU This section presents exploded figures with the instructions to indicate how to remove and replace the FRU. Make sure to observe the following general rules: 1. Do not attempt to service any computer unless you have been trained and certified. -
Page 32: 1010 Battery Pack
Lenovo IdeaTab S2110A Hardware Maintenance Manual 1010 Battery pack DANGER Only use the battery specified in the parts list for your IdeaTab. Any other battery could ignite or explode. Figure 1. Removal steps of battery pack Pull out the SIM card slot cover with a fingertip in the direction shown by the... -
Page 33: 1020 Sim Card/Micro Sd Card
Lenovo IdeaTab S2110A 1020 SIM card/Micro SD card Figure 2. Removal steps of SIM card/Micro SD card Pull out the SIM card slot cover the card slot cover in the direction shown by arrow Remove the SIM card or Micro card in the direction shown by arrows... -
Page 34: 1030 Back Camera
Lenovo IdeaTab S2110A Hardware Maintenance Manual 1030 Back camera For access, remove these FRUs in order: • “1010 Battery pack” on page 28 Figure 3. Removal steps of back camera Detach the back camera connector and remove it. -
Page 35: 1040 System Board
Lenovo IdeaTab S2110A 1040 System board Important notices for handling the system board: When handling the system board, bear the following in mind. • Be careful not to drop the system board on a bench top that has a hard surface, such as metal, wood, or composite. - Page 36 Lenovo IdeaTab S2110A Hardware Maintenance Manual Figure 4. Removal steps of system board Detach Switch board FPC connector Remove the three screws Detach Volume FFC connector , LVDS cable connector , Touch FPC connector , and Speaker connector...
- Page 37 Lenovo IdeaTab S2110A Figure 4. Removal steps of system board Lift the system board in the direction shown by arrow . Disconnect the Vibrator motor connector . Then remove the system board. Step Screw (quantity) Color Torque M2X2.3L, flat-head, nylok-coated (4) Black 1.0 ~ 1.5 kgfcm...
-
Page 38: 1050 Lcd
Lenovo IdeaTab S2110A Hardware Maintenance Manual 1050 LCD For access, remove these FRUs in order: • “1010 Battery pack” on page 28 • “1030 Back camera” on page 30 • “1040 System board” on page 31 Figure 5. Removal steps of all parts... -
Page 39: Locations
Lenovo IdeaTab S2110A Locations Front view Front camera... -
Page 40: Right-Side View
Lenovo IdeaTab S2110A Hardware Maintenance Manual Right-side view Speaker Volume +/- Top view Power button... -
Page 41: Back View
Lenovo IdeaTab S2110A Back view Flash Back camera Left-side view Speaker Combo audio jack Micro HDMI port Micro SD card slot/SIM card slot (On select models) -
Page 42: Parts List
Lenovo IdeaTab S2110A Hardware Maintenance Manual Parts list This section presents the following service parts: • “Overall” on page 39 • “AC adapters” on page 41 • “USB Cable” on page 41 • “SD Card” on page 41 Notes: • Each FRU is available for all types or models, unless specific types or... -
Page 43: Overall
Lenovo IdeaTab S2110A Overall... - Page 44 Lenovo IdeaTab S2110A Hardware Maintenance Manual Table 1. Parts list—Overall FRU no. CRU ID SYSTEM BOARD 90000609 VOLUME BOARD 90000676 SWITCH BOARD 90000677 SPEAKER MODULE LEFT 90000672 SPEAKER MODULE RIGHT 90000673 VOLUME BUTTON 90201530 BACK CAMERA 90201513 SWITCH BOARD FPC...
-
Page 45: Sd Card
Lenovo IdeaTab S2110A AC adapters Table 2. Parts list—3-pin AC adapters CRU ID S2 18AW AA 12V1.5A Adapter 36200114 USB Cable Table 3. Parts list—USB Cable CRU ID USB CABLE 90201534 SD Card SD/SIM Card Slot is available to support SD card. -
Page 46: Trademarks
Lenovo IdeaTab S2110A Hardware Maintenance Manual Trademarks Legend, Lenovo, Lenovo 联想 , 联想 , IdeaPad, IdeaTab and other Lenovo logos are trademarks of Lenovo in Mainland China and/or other countries/territories. Other product names, service names, trade names or brands are trademarks of their respective owners.
