Summary of Contents for Clarion XN3210
- Page 1 Owner’s manual & Installation manual Mode d’emploi et manuel d’installation Manual de instrucciones y de instalación XN 3210 XN 3410 XN AMPLIFIERS AMPLIFICATEURS XN AMPLIFICADORES XN XN3210_3410 manual_060410 R2.ind1 1 9/3/2010 8:49:17 AM...
-
Page 2: Table Of Contents
• Speaker level input. • Low profile construction with aluminum heat sink for efficient heat dissipation. The Clarion XN3410 is a full featured, four-channel amplifier adding the following feature: • Advanced circuitry design featuring bridgeable and mixed mode operation for use in various system configurations including 4, 3, or 2 channel systems. -
Page 3: Description
DESCRIPTION The XN3210 and XN3410 use an unregulated MOSFET power supply for supe- rior sound and output wattage. In addition, a toroid-coil is used to transfer power with minimal performance loss due to heat. To avoid unwanted noise, a double- sided conformal printed circuit board with strategically placed components keeps AM RFI subdued. - Page 4 XN3210 BASS FREQ INPUT GAIN FREQ Hz X-OVER MODE POWER BOOST RANGE HIGH INPUT + CH1 LPF HPF OFF STEREO CH1/2 MONO – CH1 + CH2 MONO – CH2 1. CH1-CH2 RCA Input 6. Crossover Mode Switch 2. Gain Control 7.
-
Page 5: Connections For Power And Speakers
• Output Mode Selector Switch: CH 1/2 and CH 3/4 (XN3410 only) STEREO: Full left and right stereo operation. CH1Mono / CH2 Mono: Single channel input for bridged operation. This is especially useful in high-powered systems. (Uses CH2 and CH4 inputs.) CH1/2 Mono / CH3/4 Mono: Allows for a stereo input to be summed into a mono output. - Page 6 XN3410 - Electrical Connection Remote Turn-On 4 Ω BRIDGED +12V – – FUSE – – 4 Ω BRIDGED CH4 Speaker (-) CH1 Speaker (+) CH1 Speaker (-) CH4 Speaker (+) CH2 Speaker (+) CH3 Speaker (-) CH2 Speaker (-) CH3 Speaker (+) Fig.
-
Page 7: Installation
INSTALLATION This section suggests Mounting and Wiring Precautions for installing the Clarion XN3210 and/or XN3410 amplifier(s). If you do not posses the necessary tools and installation experience, do not attempt to install these amplifiers. Instead, contact your local Clarion Marine Audio dealer to perform the installation. -
Page 8: Xn3410 Wiring And Applications
9. In multiple amplifier systems, it is recommended to use a relay on the remote turn-on lead of the radio. XN3410 WIRING AND APPLICATIONS The Clarion XN3410 4-channel marine audio amplifier can be used in a variety of system applications. Here are some examples to help plan your own installation. Fig. 4... - Page 9 Fig. 5 4-Channel Stereo System, 2-Channel High-Pass, 2-Channel Low-Pass 4 Ω BRIDGED +12V – – FUSE – – 4 Ω BRIDGED CH3 Speaker System CH4 Speaker System CH1 Subwoofer CH2 Subwoofer In this 4-channel system, the XN3410 drives a pair of stereo satellites for the front and a pair of subwoofers.
- Page 10 Fig. 6 2-Channel Stereo System with Low-Pass Bridged Mono Channel 4 Ω BRIDGED +12V – – FUSE – – 4 Ω BRIDGED CH3 Speaker System CH4 Speaker System Subwoofer The XN3410 can also be used to drive a pair of stereo satellites for the front and a single mono subwoofer for the rear.
- Page 11 Fig. 7 2-Channel High Power System (Satellite or Subwoofer) 4 Ω BRIDGED +12V – – FUSE – – 4 Ω BRIDGED Bridged CH1/CH2 Bridged CH3/CH4 Speaker System Speaker System Bridged Left Subwoofer Bridged Right Subwoofer The XN3410 can be set up as a 2-channel high power amplifier to drive a pair of satellites (or subwoofers) XN3210/XN3410 XN3210_3410 manual_060410 R2.ind12 12...
- Page 12 Fig. 8 Mixed Mode System On CH3/CH4, Full Range Speakers On CH1/CH2 4 Ω BRIDGED +12V – – FUSE – – 4 Ω BRIDGED CH3 Speaker CH4 Speaker Speaker Subwoofer Speaker FREQ (Hz) L (mH) C ( F) NOTE: Chart values based on 4 Ohm speakers. The amplifier can be configured for a mixed-mode operation on either channels 1/2 or 3/4 amplifier sections.
-
Page 13: Xn3210 Wiring And Applications
XN3210 WIRING AND APPLICATIONS The Clarion XN3210 2-channel marine audio amplifier can be used in a variety of sys- tem applications. Here are some examples to help plan your own installation. Fig. 9 Bridged - Mono Subwoofer System 4 Ω BRIDGED... - Page 14 Fig. 10 2-Channel Full-Range, Satellite, or Subwoofer Stereo System (Set INPUT SELECT Switch to STEREO) 4 Ω BRIDGED +12V FUSE – – Left Full Range Speaker Right Full Range Speaker Set X-Over Mode as shown. Left Component Right Component Speaker System Speaker System Set X-Over Mode as shown.
- Page 15 Fig. 11 Mixed-Mode Satellite and Subwoofer System (Set INPUT SELECT Switch to STEREO) 4 Ω BRIDGED +12V FUSE – – Left Speaker Right Speaker Subwoofer 4 Ohms FREQ (Hz) L (mH) C (µF) NOTE: Chart values based on 4 Ohm speakers. The amplifier can be configured for a mixed-mode operation.
-
Page 16: Setting The Gain
4. Slowly increase the Gain Control. Stop when you hear a slight distortion of audio. SETTING THE CROSSOVER The Clarion XN3210 and XN3410 feature fully adjustable high and low pass crossovers. To set the crossover, follow these steps. 1. Using the X-Over Mode Switch, select the desired mode: LP for Low Pass, HP for High Pass or OFF for Full Range. -
Page 17: Final System Check
Speakers not connected or are blown. Check speaker connections at amplifier, measure coil impedance. Problem Audio cycles on and off. Solution Thermal protection circuits are shutting amplifier off. Check location for adequate ventilation; consult an authorized Clarion dealer. XN3210/XN3410 XN3210_3410 manual_060410 R2.ind18 18 9/3/2010 8:49:31 AM... -
Page 18: Product Specs
Problem Distorted audio. Solution Gain is not set properly, or damaged speaker cones. Review Setting Gain; inspect each speaker cone for signs of damage (i.e. frozen cone, burning smell, etc.) Problem Audio lacks punch. Solution Speakers wired incorrectly, which causes cancellation of bass frequencies. Check polarity of wires from amplifier to each speaker as defined by the system design.
