Electro-Voice FRi-2082 Specification Sheet
Electro-Voice FRi-2082 Specification Sheet

Electro-Voice FRi-2082 Specification Sheet

Electro-voice speaker system specification sheet
Hide thumbs Also See for FRi-2082:

Advertisement

Quick Links

General Product Description
Two-way full-range passive system in a unique slant sided
enclosure. Includes dual 8-inch woofers and a 1 /25 mm
voice coil compression driver on a 100º x 100º
constant-directivity horn. Cloth coverable steel grille.
Applications
The FRi-2082 uses EV's exclusive RMD
Decoupling) to provide outstanding vocal clarity and
intelligibility in a cost-effective two-way system. The
versatile, compact enclosure features a low profile cabinet
design with integral suspension points and a U-bracket
(included) to allow horizontal or vertical mounting. The
100º x 100º horn pattern allows broad coverage for near
field applications. Five year warranty.
Speaker Description
Part Number
LF Section & Components
HF Section & Components
System Configuration
Powering Configuration
Recommended High-Pass
Frequency (12 dB/octave min.)
Cabinet Type (shape)
Enclosure Materials
Finish
Connectors
Suspension Hardware
Grille
Options
(Ring-Mode
FRi-2082-BLK
Dual 8-inch woofers in vented enclosure
Compression driver with 1-inch titanium diaphragm on a constant-directivity horn
Two-way, Full range
Passive
50 Hz
Low profile slant design
13-ply plywood
Black Acrylic
One barrier strip
(2) 3/8-16 threaded mounting/suspension points, 1 per side
Powder-coated perforated 18GA steel
WH-white acrylic finish
UN-unfinished
FRi-2082
Speaker System
Applications include:
Stadiums
Arenas
Houses of Worship
Discos
Live Music Clubs
Gymnasiums
F
R
i
S P E A K E R
S Y S T E M S
