Summary of Contents for Electra Accessories EL 370
-
Page 3: Preface
PREFACE Welcome to your new Electra cooker. Its stylish and practical design will enhance your kitchen and make "cooking electric" a pleasure. Features include a radiant hob for responsive, economical cooking with two large and two small radiant rings, full width grill and fan assisted oven and three removable shelves. -
Page 4: Technical Details
TECHNICAL DETAILS MODEL NO. Voltage: Wattage: Height: Width: Depth: This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC. EL 370 230/240 Volts AC 50Hz 9.9/10.8kW 900mm 500mm 600mm... -
Page 5: Table Of Contents
CONTENTS Preface ................... 1 Technical Details . - Page 6 CONTENTS Defrost Feature ................. . 22 Uses of Defrost Feature .
-
Page 7: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT THEM ALL BEFORE INSTALLING OR USING THE COOKER. PLEASE READ CAREFULLY BEFORE INSTALLATION This appliance is heavy and care must be taken when moving it. Ensure that all packaging, both inside and outside the appliance, been... -
Page 8: After Use
Always use oven gloves to remove and replace food in the oven. Similarly always use oven gloves to remove and replace the grill pan handle when grilling. Recommendations Ensure that you support the grill pan when it is in the withdrawn or partially withdrawn position. -
Page 9: Introduction
INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED RATING PLATE Record the model, product and serial numbers on the back cover of this instruction book, from the rating plate. This is situated on the lower front frame of the appliance and can be seen upon opening the oven door. -
Page 10: Reversible Main Oven Door
Overhanging surfaces or a cooker hood should be a minimum of 685mm above the hob. It is important to ensure that the appliance is level after installation. Levelling feet are fitted to the front of the appliance to accommodate uneven floors. REVERSIBLE MAIN OVEN DOOR If you require the oven door to be hinged on the opposite side, you will need to contact your local... -
Page 11: Getting To Know Your Cooker
GETTING TO KNOW YOUR COOKER THE CONTROL PANEL FEATURES Main Oven Temperature Control Main Oven Indicator Neon Top Oven/Grill Control Top Oven/Grill Indicator Neon Hotplate Controls... -
Page 12: The Electronic Minute Minder
ELECTRONIC MINUTE MINDER DECREASE CONTROL & MINUTE MINDER SETTING BUTTON INCREASE CONTROL ) COOKPOT SYMBOL ) CLOCK SETTING SYMBOL ) MINUTE MINDER SYMBOL The electronic minute minder can indicate the time of day, operate as a minute minder and it can be used to time and switch off the main oven. -
Page 13: To Cancel The Minute Minder
2. THE MINUTE MINDER IMPORTANT The minute minder can be used to time a set cooking period. At the end of the cook time the minute minder will automatically switch off the main oven if in use. The minute minder gives an audible reminder at the end of any period of cooking up to 23 hours and 59 minutes. -
Page 14: The Ceramic Hob
THE CERAMIC HOB CAUTION: DO NOT USE THE COOKER IF THE CERAMIC GLASS IS DAMAGED. IF A FAULT OR CRACK BECOMES VISIBLE DURING COOKING, DISCONNECT THE COOKER IMMEDIATELY FROM THE ELECTRICITY SUPPLY AND CONTACT THE SERVICE DEPARTMENT OF YOUR LOCAL ELECTRICITY COMPANY. -
Page 15: Deep Fat Frying
Never use utensils with a skirt, e.g. a bucket. Never use an asbestos mat. Never leave the hotplates ON when not covered with a saucepan. Ensure that hob and saucepans are clean and dry before the start of cooking to reduce cleaning. -
Page 16: The Grill
THE GRILL CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. SELECTING THE GRILL To operate the grill open the grill door and turn the top oven/grill control clockwise so that '0' on the control knob lines up with setting 1, 2 or 3. -
Page 17: Hints And Tips
To correctly locate the grill pan on the shelf, ensure that the cut out on the underside of the handle bracket locates over the front bar of the shelf. To check the progress of the food being grilled, the grill pan should be withdrawn on the shelf to tend the food during cooking, or the carrier shelf can be lifted away from the cooker and rested on a heat resistant work surface. -
Page 18: The Top Oven
THE TOP OVEN USES OF THE TOP OVEN The top oven is the smaller of the two ovens. It is heated by elements in the top and bottom of the oven. It is designed for cooking on one level and for smaller quantities of food. It gives especially good results if used to cook fruit cakes, sweet or savoury flans or quiche. - Page 19 There should always be at least 2.5cm (1") between the top of the food and the element. This gives best cooking results and allows room for rise in yeast mixtures, Yorkshire puddings, etc. When cooking cakes, pastry, scones, bread, etc., place the tins or baking trays centrally on the shelf directly below the element.
-
Page 20: The Main Fan Oven
THE MAIN FAN OVEN USES OF THE FAN OVEN PREHEATING The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. Without preheating, however, you may find you need to add an extra 5 - 10 minutes on the recommended cooking times. For recipes needing high temperatures, e.g. -
Page 21: To Fit The Main Oven Shelves
TO FIT THE MAIN OVEN SHELVES The shelves should be fitted with the straight rods uppermost on the frame and the forms towards the back of the oven. If not fitted correctly the anti-tilt and safety stop mechanism will be affected. Back of Oven Straight Rods HINTS AND TIPS... -
Page 22: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatu by 10°C to suit individual preferences and requirements. FOOD Biscuits Bread Bread rolls/buns Cakes: Small & Queen Sponges Victoria Sandwich Madeira Rich fruit... -
Page 23: Roasting Chart
ROASTING CHART ROASTING CHART INTERNAL TEMPERATURES - Rare: 50-60°C; Medium: 60-70°C; Well Done: 70-80°C MEAT Beef Beef, boned Mutton and Lamb Pork and veal Chicken Turkey and goose Duck Pheasant Rabbit Potatoes with meat Potatoes without meat The roasting temperatures and times given in the chart should be adequate for most joints, but slight adjustments may be required to allow for personal requirements and the shape and texture of the meat. -
Page 24: Defrost Feature
DEFROST FEATURE USES OF DEFROST FEATURE This fan oven function defrosts most foods faster than more conventional methods. It is particularly suitable for delicate frozen foods which are to be served cold e.g. cream filled gateaux, cakes covered with icings or frostings, cheesecakes, biscuits, scones, etc. -
Page 25: Care And Cleaning
CARE AND CLEANING ALWAYS SWITCH OFF THE SUPPLY AT THE MAIN WALL SWITCH AND ALLOW THE COOKER TO COOL BEFORE CLEANING. CLEANING MATERIALS Before using any cleaning materials on your cooker, check that they are suitable and that their use is recommended by the manufacturer. -
Page 26: Cleaning The Outside Of The Cooker
TO REMOVE DISCOLOURATIONS OR WHITE AND SILVER MARKS These marks sometimes give the impression of being in or underneath the hob glass. They can almost always be removed provided they have not become excessively burnt on. Follow the instructions under 'To Remove more Stubborn Marks' above. If this is unsuccessful, make up a paste of one part water to three parts Cream of Tartar and leave on the discoloured areas overnight. -
Page 27: Cleaning Inside The Grill/Oven Compartments
CLEANING INSIDE THE GRILL / OVEN COMPARTMENTS The sides of the main oven are coated with special Stayclean linings. The Stayclean linings should not be cleaned manually. The vitreous enamel main oven base, back panel, interior main oven door and top oven/ grill compartment can be cleaned using normal oven cleaners or aerosol oven cleaners with care. -
Page 28: Something Not Working
SOMETHING NOT WORKING? We strongly recommend that you carry out the following checks on your appliance before calling a Service Engineer. It may be that the problem is a simple one, which you can solve yourself without the expense of a service call. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the appliance is under guarantee. -
Page 29: Guarantee
GUARANTEE Your Electra cooker is covered by the terms of your Electricity Company's guarantee for the period of one year. In the event of a defect please contact the Service Department of your local Electricity Company. It is suggested that you record the model number, product number, serial number and date of purchase on the following page. -
Page 30: Service Call Record
SERVICE CALL RECORD How to obtain Remember that you may be charged for a service call (even during the guarantee After Sales Service period) if nothing is found to be wrong with the cooker. So always check the quickly instructions to make sure you have not missed anything. Make a note of your nearest Electricity Company Service Depot and their telephone number here: The receptionist will need the answer to certain questions, so to save you time and... - Page 32 MODEL NO. PART NO. 311338904 EL 370...
