Asus MEB User Manual

Socket 370 agp motherboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MEB
R
Socket 370 AGP Motherboard
USER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Asus MEB

Summary of Contents for Asus MEB

  • Page 1 Socket 370 AGP Motherboard USER’S MANUAL...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Asus Contact Information

    WWW: www.asus.com FTP: ftp.asus.com.tw/pub/ASUS ASUS COMPUTER GmbH (Europe) Marketing Address: Harkort Str. 25, 40880 Ratingen, BRD, Germany Telephone: 49-2102-445011 Fax: 49-2102-442066 Email: sales@asuscom.de Technical Support Hotline: 49-2102-499712 BBS: 49-2102-448690 Email: tsd@asuscom.de WWW: www.asuscom.de FTP: ftp.asuscom.de/pub/ASUSCOM ASUS MEB User’s Manual...

  • Page 4: Table Of Contents

    II. FEATURES ..................8 The ASUS MEB Motherboard ............8 Introduction to ASUS Smart Series Motherboards ....9 Parts of the ASUS MEB Motherboard ..........11 III. HARDWARE SETUP ..............12 ASUS MEB Motherboard Layout ............ 12 Hardware Setup Steps ............... 14 1.
  • Page 5 Exit Without Saving ..............57 V. SOFTWARE SETUP ............... 59 VI. SOFTWARE REFERENCE ............73 APPENDIX ................... 97 ASUS CIDB Chassis Intrusion Sensor Module ........ 97 ASUS PCI-L101 Fast Ethernet Card ..........99 Glossary ..................101 ASUS MEB User’s Manual...

  • Page 6: Federal Communications Commission Statement

    You may install an auxiliary fan, if necessary. Canadian Department of Communications Statement This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. ASUS MEB User’s Manual...

  • Page 7: Introduction

    (1) Bag of spare jumper caps (1) Support CD with drivers and utilities (1) This Motherboard User’s Manual ASUS IrDA-compliant infrared module (optional) ASUS CIDB chassis intrusion sensor module (optional) ASUS PCI-L101 Wake-On-LAN 10/100 fast ethernet card (optional) ASUS MEB User’s Manual...

  • Page 8: Features

    II. FEATURES The ASUS MEB Motherboard The ASUS MEB motherboard is carefully designed for the demanding PC user who wants many intelligent features in a small package. • Intel Processor Support: Supports Intel’s Celeron processor designed for the Socket 370 and packaged in Plastic Pin Grid Array (PPGA).

  • Page 9: Introduction To Asus Smart Series Motherboards

    • ACPI Ready: ACPI (Advanced Configuration and Power Interface) is also imple- mented on all ASUS smart series motherboards. ACPI provides more Energy Saving Features for future operating systems (OS) supporting OS Direct Power Management (OSPM) functionality. With these features implemented in the OS, PCs can be ready around the clock, yet satisfy all the energy saving standards.
  • Page 10 Keyboard Power Up: Keyboard Power Up can be enabled or disabled to allow the computer to be powered on by pressing the space bar on the keyboard. • Chassis Intrusion Detection: Supports chassis-intrusion monitoring through the optional ASUS CIDB chassis intrusion sensor module (See APPENDIX) and Intel LDCM. ASUS MEB User’s Manual...

  • Page 11: Parts Of The Asus Meb Motherboard

    II. FEATURES Parts of the ASUS MEB Motherboard Intel 440BX ATX Power AGPset Socket 370 3 DIMM Slots Connectors Switches T: PS/2 Mouse B: PS/2 Keyboard T: USB1 B: USB2 Serial COM1 T: Parallel B:Serial Serial COM2 T: Joystick/Midi B: Out/In/Mic...

  • Page 12: Hardware Setup

    III. HARDWARE SETUP ASUS MEB Motherboard Layout PS/2 CPU_FAN T: Mouse PWR_FAN B: Keyboard Socket 370 T: Port 1 B: Port 2 Thermal Sensor COM1 KBPWR PRINTER JTPWR Intel 440BX COM2 AGPset Line Line Solo-1 Audio MODEM Accelerated Graphics Port...

  • Page 13: Motherboard Settings

    33 System Warning Speaker Connector (4 pins) 28) JTPWR p. 33 Power Supply Thermal Sensor Connector (2 pins) The onboard hardware monitor uses the address 290H-297H so legacy ISA cards must not use this address; otherwise, conflicts will occur. ASUS MEB User’s Manual...

  • Page 14: Hardware Setup Steps

    ATX power supply. Your com- puter will not power on if you set this to Enable and if you do not have the right ATX power supply. KBPWR KBPWR Disable Enable (Default) MEB Keyboard Power Up ASUS MEB User’s Manual...

  • Page 15: Dip Switches (Dip)

    DRAM, chipset, AGP, and the CPU’s I/O buffer. IMPORTANT! Setting this function switch to ON (3.66Volt) may reduce system life. It is strongly recom- mended that you leave this switch on its default setting of OFF (3.50Volt). 3.50Volt 3.66Volt MEB VIO Setting ASUS MEB User’s Manual...
  • Page 16 4.5x(9/2) 2.0x(2/1) 6.0x(6/1) 6.5x(13/2) 7.0x(7/1) 7.5x(15/2) 8.0x(8/1) 5.5x(11/2) MEB CPU : BUS Frequency Multiple Set the DIP switches by the Internal speed of your processor as follows: (BUS Frequency Switches) (Frequency Multiple Switches) Intel CPU Model Speed Mult Freq. Celeron (PPGA) 466MHz 7.0x...

  • Page 17: System Memory (Dimm)

    BIOS shows SDRAM memory on bootup screen. • 8 chips/side modules do not support ECC, only 9 chips/side modules support ECC. • Single-sided DIMMs come in 16, 32, 64,128MB; double-sided come in 32, 64, 128, 256MB. ASUS MEB User’s Manual...

  • Page 18: Dimm Memory Installation

    SIMM modules have the same pin contact on both sides. Lock MEB 168-Pin DIMM Sockets The DIMMs must be 3.3V Unbuffered for this motherboard. To determine the DIMM type, check the notches on the DIMMs (see figure below).

  • Page 19: Central Processing Unit (Cpu)

    CPU. Once completely inserted, close the socket’s lever while holding down the CPU. NOTE: Set the bus frequency and multiple for your Socket 370 processor. Socket 370 CPU (Top) Socket 370 CPU (Bottom) Notch MEB Socket 370 ASUS MEB User’s Manual...
  • Page 20 III. HARDWARE SETUP (This page was intentionally left blank.) ASUS MEB User’s Manual...

  • Page 21: Expansion Cards

    (to gain access, double-click the System icon under the Control Panel program). Ensure that no two devices share the same IRQs or your computer will experience problems when those two devices are in use at the same time. ASUS MEB User’s Manual...

  • Page 22: Assigning Dma Channels For Isa Cards

    Accelerated Graphics Port (AGP) This motherboard provides an accelerated graphics port (AGP) slot to support a new generation of graphics cards with ultra-high memory bandwidth, such as an ASUS 3D hardware accelerator. MEB Accelerated Graphics Port (AGP)

  • Page 23: External Connectors

    This connection is for a standard keyboard using an PS/2 plug (mini DIN). This connector will not allow standard AT size (large DIN) keyboard plugs. You may use a DIN to mini DIN adapter on standard AT keyboards. PS/2 Keyboard (6-pin Female) ASUS MEB User’s Manual...
  • Page 24 5. Serial Port Connectors (Two 9-pin COM1/COM2) The two serial ports can be used for pointing devices or other serial devices. See “Onboard Serial Port” in Chipset Features Setup of BIOS SETUP. COM 1 COM 2 Serial Ports (9-pin Male) ASUS MEB User’s Manual...
  • Page 25 LAN support, your ATX power supply must supply at least 720mA +5VSB. +3.3Volts +3.3 Volts -12.0Volts +3.3 Volts Ground Ground Power Supply On +5.0 Volts Ground Ground Ground +5.0 Volts Ground Ground -5.0 Volts Power Good +5.0 Volts +5V Standby +5.0 Volts +12.0Volts MEB ATX Power Connector ASUS MEB User’s Manual...
  • Page 26 (Pin 5 is removed to prevent inserting in the wrong orienta- tion when using ribbon cables with pin 5 plugged). NOTE: Orient the red markings on the floppy ribbon cable to PIN 1 PIN 1 MEB Floppy Disk Drive Connector ASUS MEB User’s Manual...
  • Page 27 12. Wake-On-LAN Connector (3-pin WOL_CON) These connector connects to LAN cards with a Wake-On-LAN output, such as the ASUS PCI-L101. The connector powers up the system when a wakeup packet or signal is received through the LAN card. IMPORTANT: This feature requires that the WAKE On LAN Power Up Control is set to Enabled (see Power Management Setup under BIOS SETUP) and that your system has an ATX power supply with at least 720mA +5V standby power.
  • Page 28 IrDA. Use the five pins as shown on the Back View and connect a ribbon cable from the module to the motherboard according to the pin definitions. Front View Back View +5V IRRX IRTX (NC) GND IRTX (NC) IRRX MEB Infrared Module Connector ASUS MEB User’s Manual...
  • Page 29 TIP: If the case-mounted LED does not light, try reversing the 2-pin plug. IDELED MEB IDE Activity LED 16. SB-Link™ Connector (6-1 pin SBLINK) If you have a Sound Blaster compatible PCI audio card, you must link it to this connector.
  • Page 30 “chassis signal” lead. This occurs when a panel switch or light detector is triggered. This function requires an optional trigger switch, such as the ASUS CIDB Chassis Intrusion Photo Sensor Module (See APPENDIX) and/or a chassis mounted toggle switch, to be installed.
  • Page 31 It also allows the sharing of microphone and speaker between the onboard audio and the voice modem card. NOTE: Your voice modem card requires a similar connector to use this feature. Modem-In Ground MODEM Ground Modem-Out MEB Modem Card Voice In Connector ASUS MEB User’s Manual...
  • Page 32 Keyboard Lock Message LED Power LED MEB System Panel Connectors 21. Message LED Lead (2-pin MSG.LED) This indicates whether a message has been received from a fax/modem. The LED will remain lit when there is no signal and blink when there is data transfer or waiting in the inbox.
  • Page 33 28. Power Supply Thermal Sensor Connector (2-pin JTPWR) If you have a power supply with thermal monitoring, you can connect its ther- mal sensor cable to this connector. JTPWR Power Supply Thermal Sensor MEB Thermal Sensor Connector ASUS MEB User’s Manual...
  • Page 34 III. HARDWARE SETUP (This page was intentionally left blank.) ASUS MEB User’s Manual...

  • Page 35: Power Connection Procedures

    Shut down the computer?. The power supply should turn off after Windows shuts down. NOTE: The message “You can now safely turn off your computer” will not appear when shutting down with ATX power supplies. ASUS MEB User’s Manual...

  • Page 36: Flash Memory Writer Utility

    To save your current BIOS, type [1] at the Main Menu and then press <Enter>. The Save Current BIOS To File screen appears. Type a filename and the path, for example, A:\XXX-XX.XXX and then press <Enter>. ASUS MEB User’s Manual...
  • Page 37 BIOS update, press Y to start the update. The utility starts to program the new BIOS information into the flash ROM. When the pro- gramming is finished, Flashed Successfully will be displayed. Follow the onscreen instruc- tions to continue. ASUS MEB User’s Manual...

  • Page 38: Managing And Updating Your Motherboard's Bios

    Updating BIOS Procedures (only when necessary) 1. Download an updated ASUS BIOS file from the Internet (WWW or FTP) or a BBS (Bulletin Board Service) (see ASUS CONTACT INFORMATION on page 3 for details) and save to the disk you created earlier.

  • Page 39: Bios Setup

    Reset button on the system case. You can also restart by turning the system off and then back on again. But do so only if the first two methods fail. When you invoke Setup, the CMOS SETUP UTILITY main program screen will appear with the following options: ASUS MEB User’s Manual...

  • Page 40: Load Defaults

    To set the date, highlight the “Date” field and then press either <Page Up>/<Page Down> or <+>/<–> to set the current date. Follow the month, day and year format. Valid values for month, day and year are: Month: (1 to 12), Day: (1 to 31), Year: (up to 2079). ASUS MEB User’s Manual...
  • Page 41 IDE hard disks; set it to Large for drives over 528MB that do not support LBA. Large type of drive can only be used with MS-DOS and is very uncommon. Most IDE drives over 528MB support the LBA mode. ASUS MEB User’s Manual...
  • Page 42 If you are using a VGA or any higher resolution card, choose EGA/VGA. Halt On (All Errors) This field determines which types of errors will cause the system to halt. Choose from All Errors; No Errors; All,But Keyboard, All,But Diskette; and All,But Disk/Key. ASUS MEB User’s Manual...

  • Page 43: Bios Features Setup

    Be- cause of conflicts with new operating systems, for example, during installation of new software, you may have to set this to Disabled to prevent write errors. ASUS MEB User’s Manual...
  • Page 44 This allows the enabling or disabling of the S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) system which utilizes internal hard disk drive monitor- ing technology. This feature is normally disabled because system resources used in this feature may decrease system performance. ASUS MEB User’s Manual...
  • Page 45 The default setting is System, where the system prompts for the User Password every time you start your system. The other option is Setup, where the system goes through its startup routine unless the Setup utility is called, when the system prompts for the Supervisor Password. ASUS MEB User’s Manual...

  • Page 46: Chipset Features Setup

    SDRAM MA Wait State (Normal) This controls the leadoff clocks for CPU read cycles. Leave on default setting. Snoop Ahead (Enabled) Enabled will allow PCI streaming. Leave on default setting. Host Bus Fast Data Ready (Disabled) Leave on default setting. ASUS MEB User’s Manual...
  • Page 47 When Enabled, this field allows you to connect your floppy disk drives to the onboard floppy disk drive connector instead of a separate controller card. If you want to use a different controller card to connect the floppy disk drives, set this field to Disabled. ASUS MEB User’s Manual...
  • Page 48 Because each IDE device may have a different Mode timing (0, 1, 2, 3, 4), it is necessary for these to be independent. The default setting of Auto will allow autodetection to ensure optimal performance. ASUS MEB User’s Manual...

  • Page 49: Power Management Setup

    “Power” will appear in the “Control Panel.” Choose “Advanced” in the Power Management Field. Video Off Option (Suspend -> Off ) This field determines when to activate the video off feature for monitor power management. The settings are Always On and Suspend -> Off. ASUS MEB User’s Manual...
  • Page 50 4 seconds. Suspend allows the button to have a dual function where pressing less than 4 seconds will place the system in sleep mode. Regardless of the setting, holding the ATX switch for more than 4 seconds will power off the system. ASUS MEB User’s Manual...
  • Page 51 NOTE: If any of the monitored items are out of range, an error message will appear: “Hardware Monitor found an error, enter POWER MANAGEMENT SETUP for details”. You will then be prompted to “Press F1 to continue, DEL to enter SETUP”. ASUS MEB User’s Manual...

  • Page 52: Pnp And Pci Setup

    9, 10, 11, 12, 14 or 15 for this slot. If using manual settings, each slot must have a unique IRQ number. PCI Latency Timer (32 PCI Clock) The default setting of 32 PCI Clock enables maximum PCI performance for this motherboard............................ASUS MEB User’s Manual...
  • Page 53 USB devices, you may set this feature to Disabled to save an extra IRQ# for expansion cards. VGA BIOS Sequence (PCI/AGP) You can select the search order for your VGA card(s). PCI/AGP will detect PCI VGA cards before AGP, and AGP/PCI will detect AGP cards before PCI VGA. ASUS MEB User’s Manual...

  • Page 54: Load Bios Defaults

    <Enter>. The system displays a confirmation message on the screen. Press <Y> and then <Enter> to confirm. Press <N> and then <Enter> to abort. This feature does not affect the fields on the Standard CMOS Setup screen. ASUS MEB User’s Manual...

  • Page 55: Supervisor Password And User Password

    (2) Short the solder points, (3) Turn ON your computer, (4) Hold down <Delete> during bootup and enter BIOS setup to re-enter user preferences. CLRTC Short solder points to Clear CMOS MEB Clear RTC RAM ASUS MEB User’s Manual...

  • Page 56: Ide Hdd Auto Detection

    The auto-detection feature can only detect one set of parameters for a particular IDE hard drive. Some IDE drives can use more than one set. This is not a problem if the drive is new and empty. ASUS MEB User’s Manual...

  • Page 57: Save & Exit Setup

    Select this option to exit the Setup utility without saving the modifications you specify during the current session. To exit without saving, highlight the “Exit Without Sav- ing” option on the main screen and then press <Enter>. ASUS MEB User’s Manual...
  • Page 58 IV. BIOS SETUP (This page was intentionally left blank.) ASUS MEB User’s Manual...

  • Page 59: Software Setup

    V. SOFTWARE SETUP ASUS MEB User’s Manual...
  • Page 60 V. SOFTWARE SETUP Operating Systems ................61 MEB Support CD (Windows 98) ............61 Support CD Contents ............... 62 Installing ESS Audio Driver (with onboard audio) ......63 Installing AudioRack32 (with onboard audio) ......... 64 Installing Software Wavetable (with onboard audio) ...... 65 Installing PCCillin ................

  • Page 61: Operating Systems

    For Windows 95, you must use OSR 2.0 or later. For Windows NT 4.0, you must use Service Pack 3.0 or later. MEB Support CD (Windows 98) Insert the support CD or double-click your CD drive icon in My Computer to bring up the autorun menu or run Setup.exe in the root directory of the Support CD.

  • Page 62: Support Cd Contents

    (NOTE: Will not run with LDCM installed.) Please refer to the user’s manual in Adobe Acrobat PDF format located in the “ASUSLM” directory on the ASUS Support CD or see the PC Probe section in this user’s manual.

  • Page 63: Installing Ess Audio Driver (With Onboard Audio)

    2. Select Search for the best driver for your device and 1. Click here. then click here. 3. Browse to E:\AUDIO\W95 (assuming E is your CD-ROM drive) 4. Click here. and then click here. 5. Click here. ASUS MEB User’s Manual...

  • Page 64: Installing Audiorack32 (With Onboard Audio)

    Insert the Support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the autorun screen. 1. Click here. 2. Click here. 3. Click here. 4. Click here to start AudioRack32. ASUS MEB User’s Manual...

  • Page 65: Installing Software Wavetable (With Onboard Audio)

    Insert the Support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the autorun screen. 1. Click here. 2. Click here. 3. Select Install ESS Software Wavetable and then click here. ASUS MEB User’s Manual...

  • Page 66: Installing Pccillin

    4. Click here. 6. Insert a floppy disk and then click here. 5. Click Express Install and then click here. 7. Once the Emergency Clean disk is created, click here. Follow the onscreen instructions to complete installation. ASUS MEB User’s Manual...

  • Page 67: Installing Adobe Acrobat Reader

    Insert the Support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the autorun screen. 1. Click here. 2. Click here. 4. Click here. 3. Click here. 5. Click here. ASUS MEB User’s Manual...

  • Page 68: Installing Asus Pc Probe

    Insert the Support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the autorun screen. NOTE: ASUS PC Probe will not run if Intel’s LDCM utility is installed. To uninstall Intel’s LDCM utility, see section on Uninstalling Programs.

  • Page 69: Ldcm Local Setup

    Insert the Support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the autorun screen. NOTE: LDCM will not run if ASUS’ PC Probe utility is installed. To uninstall PC Probe, see section on Uninstalling Programs.
  • Page 70 V. SOFTWARE SETUP LDCM Local Setup (Cont’d) 7. Click here. 8. Click here. 9. Click here. 10. Click here. 11. Click here and then click Finish to restart. ASUS MEB User’s Manual...

  • Page 71: Ldcm Administrator Setup

    Insert the Support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the autorun screen. NOTE: LDCM will not run if ASUS’ PC Probe utility is installed. To uninstall PC Probe, see section on Uninstalling Programs.

  • Page 72: Uninstalling Programs

    1. Double-click here to open the Add/Remove Programs Properties dialog box. 2. Select the program you wish to remove and click here. 3. Click here. ASUS MEB User’s Manual...

  • Page 73: Software Reference

    VI. SOFTWARE REFERENCE ASUS MEB User’s Manual...
  • Page 74 Release Notes ................... 83 ASUS PC Probe ................... 85 Starting ASUS PC Probe ..............85 Using the ASUS PC Probe ............... 86 Intel LANDesk Client Manager ............88 Main Client Manager Window ............88 Using the Taskbar icons ..............89 Using the Select Computer Dialog Box ...........

  • Page 75: Audiorack32

    The Audio Recorder is a separate application from the AudioRack32. It can be used to add effects and edit files recorded with the Digital Audio Player or by the Audio Recorder itself. The Audio Recorder can be launched from the AudioRack32’s Digital Audio Player or on its own. ASUS MEB User’s Manual...

  • Page 76: The Command Center

    Track or File Name: shows the name of the current track or file in the playlist. Time Index: displays the amount of time elapsed for the track or file in hours, minutes, seconds, and tenths of a second. ASUS MEB User’s Manual...

  • Page 77: The Miniature Mode

    AudioRack32, invoke the Always on Top command, select active components (DAT, MIDI, or CD), or exit the AudioRack32. The Stop, Pause, and Play buttons affect components that are currently active ASUS MEB User’s Manual...

  • Page 78: The Audio Mixer

    Modules that your hardware may provide for are: Master, Line, Wave, Mic, CD, MIDI, and Aux B. ASUS MEB User’s Manual...

  • Page 79: The Digital Audio Player

    Digital Audio Player. The display tells you the file name, size, number of bits per sample, sample rate, and whether the file was recorded in stereo or mono. Click again to return to the image of the tape deck. ASUS MEB User’s Manual...

  • Page 80: The Midi Player

    FM, producing richer timbre and greater depth of instru- ment voices. FM synthesis is a lower quality technology compared with Wave table synthesis. This card supports Wave table synthesis therefore ESFM is not supported on this card. ASUS MEB User’s Manual...

  • Page 81: The Compact Disk Player

    Auto Repeat. goes back one second in the MIDI file. opens the Set Playlist dialog box. goes forward one second in the MIDI file. ejects the CD from the CD-ROM drive. ASUS MEB User’s Manual...

  • Page 82: The Audio Recorder

    To the right of the text boxes is a box displaying the icon associated with the particu- lar file. If a file has no icon associated with it, it is given a default icon. ASUS MEB User’s Manual...

  • Page 83: Release Notes

    AudioRack can only display six of them at a time. You may configure the settings by modifying the file “auddrive.ini” in the Windows directory. Under the section [MixerRak], you can enable or disable the display of each input by setting its corre- sponding binary value to 1(enable) or 0(disable). ASUS MEB User’s Manual...
  • Page 84 VI. SOFTWARE REFERENCE (This page was intentionally left blank) ASUS MEB User’s Manual...

  • Page 85: Asus Pc Probe

    Monitor” or “Hide”. You can select whether you want the splash screen to show the next time it opens. Click ASUS PC Probe from the Start button to run the utility if you exit the utility or did not set it to “Run when Windows Starts.”...

  • Page 86: Using The Asus Pc Probe

    VI. SOFTWARE REFERENCE Using the ASUS PC Probe Fan Rotation Status Analog view of PC’s fan rotation Digital view of PC’s fan rotation PC’s Fan warning threshold adjustment PC Temperature Status Temperature Warning threshold adjustment Analog view of PC’s temperature Digital view of PC’s temperature...
  • Page 87 ASUS PC Probe. The icon appears dimmed when off or un- available. When there is a problem, the icon’s head mirror flashes red, the PC speaker beeps, and the ASUS PC Probe monitor is displayed. ASUS MEB User’s Manual...

  • Page 88: Intel Landesk Client Manager

    Windows registry. From this point on, when you run Client Manager or open the Select Computer dialog box, Client Manager checks to see if these computers (listed in the registry) are available and healthy. Main Client Manager Window ASUS MEB User’s Manual...

  • Page 89: Using The Taskbar Icons

    Opens the File Transfer dialog box Tools | Transfer Files Tools | Reboot Reboots the computer Tools | DMI Explorer Opens the DMI Explorer Opens the Set Access Rights dialog box Tools | Set Access Rights ASUS MEB User’s Manual...

  • Page 90: Using The Select Computer Dialog Box

    Removes a computer from the list of discovered computers Wakes up a sleeping computer Shows all discovered computers Shows only available computers Shows only unhealthy computers Shows a simple list view Shows a detailed list view ASUS MEB User’s Manual...

  • Page 91: To Select A Computer

    You may need to change your list view to display all computers. 2. Click the Wake Up Computer button on the toolbar to wake up the selected computer(s) or press <Alt>+<W>. ASUS MEB User’s Manual...

  • Page 92: Displaying The Properties Of A Client Computer

    System information is not stored in this same database, that information is not avail- able for a computer with a status of Unavailable. Remember that some items may not be current if the properties have changed while the computer was off the net- work. ASUS MEB User’s Manual...

  • Page 93: Understanding The Computer Status Icons

    Warning, or Critical) is not known. Normal (Mobile) A computer that includes support for mobile PC features, such as mobile battery. Mobile computers display the same array of health icons (above) used for non-mobile computers. ASUS MEB User’s Manual...

  • Page 94: Introducing The Asus Dmi Configuration Utility

    VI. SOFTWARE REFERENCE Desktop Management Interface (DMI) Introducing the ASUS DMI Configuration Utility This motherboard supports DMI within the BIOS level and provides a DMI Con- figuration Utility to maintain the Management Information Format Database (MIFD). DMI is able to auto-detect and record information pertinent to a computer’s system such as the CPU type, CPU speed, and internal/external frequencies, and memory size.

  • Page 95: Using The Asus Dmi Configuration Utility

    VI. SOFTWARE REFERENCE Using the ASUS DMI Configuration Utility NOTE: The following screen displays are provided as examples only and may not reflect the screen contents on your system. Edit DMI (or delete) Use the (left-right) cursors to move the top menu items and the (up-down) cursor to move between the left hand menu items.
  • Page 96 You can load the BIOS defaults from a MIFD file and can clear all user modified and added data. You must reboot your computer in order for the defaults to be saved back into the Flash BIOS. ASUS MEB User’s Manual...

  • Page 97: Appendix

    APPENDIX The ASUS CIDB Chassis Intrusion Sensor Module The optional ASUS CIDB is a module for providing audio alarm and logging when there is an intrusion into the chassis of a computer system. The module detects a chas- sis intrusion by either light striking its photo sensor or by contact when its switch connectors are shorted by chassis-mounted momentary toggle switches.

  • Page 98: Setting Up The Asus Cidb

    APPENDIX Setting up the ASUS CIDB Enable Disable CR2032 3V JP1: Enable/Disable Lithium Cell the Photo Sensor Buzzer best range +5 volt standby (sensitive) 0 (not sensitive) from power supply CON: Sensitivity adjustment for the photo sensor, (0) is least sensitive...

  • Page 99: Asus Pci-L101 Fast Ethernet Card

    Motherboard type Other If you are using the ASUS PCI-L101 on an ASUS motherboard, leave the jumper on its defaut setting of “ASUS.” If you are using another brand of motherboard, set the jumper to “Other.” Connect the Wake on LAN (WOL) output signal to the motherboard’s WOL_CON in order to utilize the wake on LAN feature of the moth-...

  • Page 100: Software Driver Support

    A: To enable Wake-On-LAN function, your system requires Ethernet LAN adapter card that can activate Wake-On-LAN function, a client with Wake-On-LAN capa- bility, and software such as LDCM Rev. 3.10 or up that can trigger wake-up frame. ASUS MEB User’s Manual...

  • Page 101: Glossary

    PIO (Programmable I/O) IDE requires that the CPU be involved in IDE access and waiting for mechanical events. Bus master IDE transfers data to/from the memory without interrupting the CPU. Bus master IDE driver and bus master IDE hard disk drives are required to support bus master IDE mode. ASUS MEB User’s Manual...
  • Page 102 Data (SIMD), which is built into the new Intel Pentium PP/MT (P55C) and Pentium II (Klamath) CPU as well as other x86-compatible microprocessors. The MMX in- structions are designed to accelerate multimedia and communications applications, such as 3D video, 3D sound, video conference. ASUS MEB User’s Manual...
  • Page 103 PIO mode, which only uses the rising edge of IDE command signal to transfer data, the DMA/33 uses both rising edge and falling edge. Hence, the data transfer rate is double of the PIO mode 4 or DMA mode 2. (16.6MB/s x2 = 33MB/s). ASUS MEB User’s Manual...
  • Page 104 With USB, the traditional complex cables from back panel of your PC can be eliminated. ASUS MEB User’s Manual...
