Eiki XGA Specification Sheet

XGA "Powerhouse" Projector
XGA "Powerhouse" Projector
6,500 ANSI Lumens bright at 90% uniformity
and a 1300:1 contrast ratio.
Native XGA. Compatible with UXGA through
VGA. Video scaling.
Works on 120V AC power (15 amp circuit).
No special wiring required!
Projects images up to 33.3' wide (500" diagonal).
Wide choice of lenses.
Some lenses feature memory. Improved Lens
Installation System.
Compatible with most video signal input,
including DVI, RGB, Y/C, DVD, HDTV.
Outstanding Features
1. Compatibility up to UXGA (1600x1200) & HDCP.
2. Touch-pad menu navigation on remote control.
3. Accepts computer USB Mouse for projector control.
4. 3 fixed inputs, 2 module bays.
5. Operable through 360° pitch rotation.
6. RF Wireless/Wired remote control.
7. Built-in mechanical shutter. Custom warm-up screen image option.
8. PIN code security for Remote and Local control.
9. Key Lock, PJ Lock and USB Lock Security.
10. Utilizes existing Powerhouse lenses (but different Throw:Width).
Note: compared-to the LC-X6, the LC-X6A lacks the following:
Warp and Blending Module • Audio Input and Output • Local Control Touch Pad • Some Accessories
6500 ANSI lumens
LC-X6A 6500 ANSI lumens
LC-X6A
Get the rich color imaging of 3-panel LCD technology
in a 54.5 lb. highly configurable large venue projector.
Displays video 4:3 & 16:9 in NTSC/PAL/
SECAM/NTSC 4.43/PAL-M/PAL-N.
Improved progressive scan with HDTV at 1080i
and 2-3 pulldown support.
3 fixed inputs, two modular bays. Wide range
of available modules.
Supplied software permits the preconfiguring
of color adjustments.
Optional Network Control module permits
network monitoring and control.
Stackable Cabinet Design.
3 Year / 6000 Hr.* Warranty.
Shown with optional
lens installed, connection
cover removed.
2345
Projectors. . . and more!
