DRAM Voltage [Auto]
Allows you to set the DRAM voltage. The values range from 1.185V to 2.135V with a 0.005V
interval.
According to Intel CPU spec, DIMMs with voltage requirement over 1.65V may damage
the CPU permanently. We recommend you install the DIMMs with the voltage requirement
below 1.65V.
VCCIO Voltage [Auto]
Allows you to set the VCCIO voltage. The values range from 0.735V to 1.685V with a 0.005V
interval.
PCH Voltage [Auto]
Allows you to set the Platform Controller Hub volage. The values range from 0.7350V to
1.6850V with a 0.005V interval.
VCCSA Voltage [Auto]
Allows you to set the VCCSA voltage. Configuration options: [Auto] [+0.10V]
CPU PLL Voltage [Auto]
Allows you to set the CPU and PCH PLL voltage. Configuration options: [Auto] [+0.10V]
•
•
CPU Manual Voltage
CPU Offset Voltage
DRAM Voltage
VCCIO Voltage
PCH Voltage
3-12
The values of the CPU Manual Voltage, CPU Offset Voltage, iGPU Manual Voltage,
iGPU Offset Voltage, DRAM Voltage, VCCIO Voltage, and PCH Voltage items are
labeled in different color, indicating the risk levels of high voltage settings.
The system may need better cooling system to work stably under high voltage
settings.
Black
0.800V–
1.285V
0.005V–
0.065V
1.18500V–
1.57500V
0.73500V–
1.10000V
0.73500V–
1.10000V
Yellow Pink
1.290V– 1.350V–
1.345V 1.405V
0.070V– 0.130V–
0.125V 0.185V
1.58000V– 1.65500V–
1.65000V 1.72500V
1.10500V– 1.16000V–
1.15500V 1.20500V
1.10500V– 1.16000V–
1.15500V 1.20500V
Red
1.410V–
1.990V
0.190V–
0.635V
1.73000V–
2.13500V
1.21000V–
1.68500V
1.21000V–
1.68500V
