Installation Manual
AH-55201
AH-55301
AH-55401
AH-55501
AH-55601
AH-55701
AH-55801
2
Remove the lens cover.
• Press the lens cover removal button (1). Slide the lens cover forward
(2).
Do not attempt to exchange the lens
when the projector is installed
hanging from the ceiling. Injury may
occur if the lens cover and lens fall.
Before exchanging the lens, reset
lens shift to the center position. (The
lens shift is located at the center in
the factory preset.)
When resetting the lens shift to the
center position, press H&V LENS
SHIFT and then press UNDO.
• The lens shift reset screen will be
displayed. Select "Yes" to reset.
2
1
1
Press STANDBY-ON on the projector or on the remote control to
put the projector into standby mode.
• Disconnect the power cord and unplug the power cord from the AC
socket after the cooling fan stops.
STANDBY-ON button
H&V LENS SHIFT
button
3
Turn the lens in the direction of the arrow while pressing the lens
removal lever to pull the lens out.
UNDO button
Power cord
Removal lever
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Eiki AH-55201
Summary of Contents for Eiki AH-55201
- Page 1 • Press the lens cover removal button (1). Slide the lens cover forward (2). Press STANDBY-ON on the projector or on the remote control to put the projector into standby mode. • Disconnect the power cord and unplug the power cord from the AC socket after the cooling fan stops.
- Page 2 Remove the lens cap from a replacement lens. Info If you try to attach the lens to the projector without removing this cap, the optional lens attachment part can be damaged. Slide and attach the lens cover. • The power cannot be turned on unless the lens cover is fully inserted.
