Hunter 22434 Parts Manual

Hardware
(Drawn to Scale)
x 1
x 2
x 4
x 2
x 3
x 3
x 1
x 2
x 11
x 16
x 16
Balancing
x 1
Kit
x 3
Wire
x 4
Connector x 10
x 3
Low Profile
Washer
3" Wood Screw
Flat Washer
Hanger
Bracket
Assembly
1.5" Wood Screw
Low Profile Screw
Canopy Screw
Setscrew
Mounting Isolator
Screw, Blade
Iron Armature
Screw, Blade
Blade
Assembly
Assembly
Blade
Grommet
Screw, Switch
Housing Assembly
Switch
Housing
Thumbscrew
Assembly
Screw,
Machine, 6-32
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
Using this Parts Guide, make sure all Using this Parts Guide, make sure all
parts are included in the box. parts are included in the box.
If parts are missing, DO NOT RETURN If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 888-830-1326 for assistance. THIS ITEM TO THE STORE, call 888-830-1326 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY. THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS. REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS.
Model # 22434

Parts List

Asm. Dwg. # 93889-01
Finish White
Item # Item Name Qnty Part #
1 Canopy Assembly 96794-03
2 Hanger Bracket Assembly
3 Canopy
61 Washer, Installers Choice
68 Flat Washer
62 Screw, Canopy
63 Screw, Low Profile
65 Wood Screw
7 Hanger Ball / Downrod Assembly
8 Setscrew
28 Switch / Housing Assembly 1 98950-03
44 Blade Iron Set 1 93451-05
46 Blade Set 1 74438-09
47 Screw, Blade Iron Armature 11 63755-05
150 Glass Globe / Shade 3 73978-01
155 Silencer Band 3 07538-01
60 * Hardware Kit 1 93889-00-860
66 Blade Grommet
67 Screw, Blade Assembly
69 Screw, Machine, 6-32
70 Wire Connector
71 Mounting Isolator
156 Thumbscrew 10 03077-08
202 Bulb 4 77646-04
75 Balancing Kit 1 07570-01
86 Remote Control Receiver 1 85068-02
87 Remote Control Transmitter 1 85094-01
Hunter Fan Company • 2500 Frisco Avenue • Memphis, TN 38114 • www.hunterfan.com •
22435 22436
93889-02 93889-03
Antique Brass Bright Brass
Part # Part #
96794-05 96794-01
98950-05 98950-01
93451-05 93451-05
74438-13 74438-13
63755-05 63755-05
73978-02 73978-02
07538-01 07538-01
93889-00-861 93889-00-862
03077-08 03077-08
77646-04 77646-04
07570-01 07570-01
85068-02 85068-02
85094-01 85094-01
98000-01-303 12-25-2008 • 2008
©
