Precautions Precautions 1. Setting up Ensure that the mains supply in your house complies with that indicated on the identification sticker located at the back of your play. Install your player horizontally, on a suitable base (furniture), with enough space around it for ventilation (7~10cm). Make sure the ventilation slots are not covered. Do not stack other, or heavy devices on top of the player.
TABLE OF CONTENTS Before You Start Accessories General Features....................6 Disc Type and Characteristics ................7 Description-Front Panel ..................8 Display Indicators ..................10 Description-Rear Panel ..................11 Tour of the Remote Control................14 Easy Remote Control/ Choosing a Connection ..................20 Remote Control/Batteries (AA Size) Batteries (AA Size) (DVD-S427 only) Playing a Disc....................22 Using the Search &...
General Features Disc Type and Characteristics Excellent Sound Repeat This DVD player is capable of playing the following types of discs with the Dolby Digital, a technology You can repeat a song or movie simply by corresponding logos: developed by Dolby Laboratories provides pressing the REPEAT button.
Description-Front Panel Description-Front Panel Front Panel Controls 1. STANDBY / ON DVD-S127 • When the unit is first plugged in, the indicator lights. When STANDBY/ON is pressed on again, the light goes out and the player is turned on. OPEN/CLOSE 2.
Display Indicators Description-Rear Panel DVD-S427 S-VIDEO VIDEO OUT SELECT SCART Rear Panel Front Panel Display 1. DIGITAL AUDIO OUT JACKS • Use either an optical or coaxial digital cable to connect to a compatible Dolby Digital, receiver. 1. Angle indicator. You can select multiple angles of a scene recorded by different cameras. Use to connect to an A/V Amplifier that contains a Dolby Digital, MPEG-2 or DTS decoder.
Page 7
Description-Rear Panel Description-Rear Panel Rear Panel DVD-S127/DVD-S227 1. DIGITAL AUDIO OUT JACKS • Use either an optical or coaxial digital cable to connect to a compatible Dolby Digital, receiver. Use to connect to an A/V Amplifier that contains a Dolby Digital, MPEG-2 or DTS decoder. 2.
Tour of the Remote Control Tour of the Remote Control DVD-S127/DVD-S227 DVD Function Buttons 1. DVD POWER Button 16. PLAY/PAUSE Button • Begin/Pause disc play. 2. NUMBER Buttons 17. SKIP Buttons 3. STEP Button • Use to skip the title, chapter, or track. •...
Page 9
Tour of the Remote Control Tour of the Remote Control DVD-S327 DVD Function Buttons 1. DVD POWER Button 17. TV POWER Button 2. NUMBER Buttons 18. 3D Button 3. STEP Button 19. OPEN/CLOSE Button 4. VOLUME Buttons 20. CHANNEL Buttons 5.
Page 10
Tour of the Remote Control Tour of the Remote Control DVD-S427 DVD Function Buttons 1. DVD POWER Button 18. TV POWER Button I.REPLAY SLOW 2. I.REPLAY Button 19. SLOW Button • This function is used to replay the previous 10 seconds of 20.
Choosing a Connection Choosing a Connection The following show examples of connections commonly used to connect the DVD player with a Connection to a TV (For Video) TV and other components. TV (Normal, Widescreen, Projection or RGB, etc..) Before Connecting the DVD Player •...
Playing a Disc Playing a Disc Step Motion Play. (Except CD) Before Play DVD-S427 : If turning JOG DIAL, you can view one by one. DVD-S127/DVD-S227/DVD-S327 : Press the STEP button on the remote during play. • Turn on your TV and press the TV/VIDEO button to select the video - Each time the button is pressed, a new frame will appear.
Using the Search & Skip Functions Using the Display Function During play, you can search quickly through a chapter or track or use the skip When Playing a DVD function to jump to the next selection. During play, press the DISPLAY button Searching through a Chapter or Track on the remote.
Repeat Play Program Play & Random Play Repeat the current track, chapter, title, a chosen section (A-B), or all of the disc. Program Play (DVD/VCD/CD/MP3) Press the MODE button. When playing a DVD Use the LEFT/RIGHT buttons to select PROGRAM. Press the REPEAT button on the remote.
S.FIT Play Digest Play Screen Fit Play Digest Play During play, press the DIGEST button. During play, press S.FIT button on remote control. - You'll see the 9 individual windows representing each of the - Allows you to eliminate the black bars in the top and bottom of the chapters on the TV screen.
Using the Disc View Function Slow Repeat play This feature allows you slowly repeat scenes containing sports, dancing, Track View (VCD) musical instruments being played etc. so you can study them more closely. Displays the beginning view of each track and the track number.
Selecting the Audio Language Selecting the Subtitle Language You can select a desired subtitle quickly and easily with the SUBTITLE button. You can select a desired language quickly and easily with the AUDIO button. Using the SUBTITLE button Using the AUDIO button Press the SUBTITLE button.
Changing the Camera Angle Using the Instant Replay Function When a DVD contains multiple angles of a particular scene, you can select the Angle function. Using the Instant Replay function (DVD) If you miss a scene, you can see it again using this function.
Using the Bookmark Function Using the Zoom & 3D Sound Functions Using the Zoom Function (DVD/VCD) The Bookmark function lets you select parts of a DVD or VCD (MENU OFF mode) so that you can quickly find the section at a later time. During play or pause mode, press the ZOOM button on the remote.
MP3 Play MP3 Play When an MP3 Disc is inserted into the DVD PLAYER, the first song file of the first folder plays. CD-R MP3 disc requirements MP3 Play Function When playing CD-R MP3 discs, please follow the recommendations below: •...
Using the Setup Menu Setting Up the Language Features The Setup menu lets you customize your DVD player by allowing you to select various If you set the player menu, disc menu, audio and subtitle language in advance, they will come up automatically every time you watch a movie.
Setting Up the Language Features Setting Up the Parental Control The Parental Control function works in conjunction with DVDs that have been assigned a Using the Audio Language rating - which helps you control the types of DVDs that your family watches. There are up to 8 rating levels on a disc.
Surround Sound Speaker Setup Setting Up the Audio Options (DVD-S427 only) Press the SETUP button in play or stop mode. With the unit in Stop mode, press the SETUP button. Press the UP/DOWN buttons to select Audio Options. Then press the ENTER button. Use the UP/DOWN buttons to select Audio Options.
“NTSC” if the screen only has one NTSC-video entrance. If this is not the case, you can choose to leave “PAL 60Hz” as is. NOTE NOTE For SAMSUNG 4 TVs SCART Output • How to make the SETUP 1. RGB : Sends RGB signal from the AV JACK(SCART terminal).
• Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. • If the problem still cannot be solved, please contact your nearest authorized service center.
