Please read this instruction sheet thoroughly before beginning installation of your conversion kit. Please
have your DRY Nitrous System manual available if needed for reference at any time during this installation.
If you have any questions or comments, please feel free to contact our Technical Hotline at: 1-800-416-8628 from
7a.m.-5p.m., Monday through Friday, Pacific Time or e-mail us at Edelbrock@Edelbrock.com.
PLEASE complete and mail your warranty card. Be sure to write the model number of this product in the "Part #____"
space. THANK YOU.
Qty.
K 1
K 1
K 1
K 1
K 4
K 2
K 1
K 5
K 1
©2005 Edelbrock Corporation
Brochure #63-0434
BILL OF MATERIALS
Description
Performer Nitrous Solenoid
Dry Nitrous Nozzle
50PSI Adjustable Hobbs Switch
1/8"NPT Brass Nipple
Solenoid Mounting Screws
Various Jets
4AN - 1/8"NPT Filter Fitting
Ratchet Hose Clamps
EFI Vacuum Tee
"WET" TO "DRY" NITROUS SYSTEM CONVERSION KIT
Qty.
Description
K 1
Nozzle Mounting Collar
K 1
1/8"NPT Pipe Plug
K 1
90° 4AN Swivel Adapter
K 1
EFI Solenoid Bracket
K 1
Solenoid Tee
K 1
1/8"NPT Hose Barb
K 3ft 3/16" Hose
K 1
Nitrous Pressure Regulator
K 3
Ring Terminals
Page 1 of 4
EDELBROCK NITROUS SYSTEMS
CATALOG #71884
INSTALLATION INSTRUCTIONS
Rev. 12/05 - DC/mc
Catalog #71884
